INDICATOR - TOTALIZER
TRANSMITTER
OPERATION AND MAINTENANCE MANUAL
*MODEL CN08-2 DIGITAL INDICATOR-TOTALIZER
VISIT OUR WEBSITE:
DIGITAL
MODEL TR28-2
PARTS LIST
FEATURING:
*ENCAPSULATED ELECTRONICS
*SOLID STATE CONSTRUCTION
*CURRENT OUTPUT SIGNAL
*PULSE OUTPUT SIGNAL
*SEALED HOUSING
3255 WEST STETSON AVENUE
HEMET, CALIFORNIA 92545 U.S.A.
PHONE:
951-652-6811
FAX:
951-652-3078
www.mccrometer.com
1
30119-41
Rev. 1.6/02-07

Advertisement

loading

Summary of Contents for Water Specialties TR28-2

  • Page 1 30119-41 Rev. 1.6/02-07 DIGITAL INDICATOR - TOTALIZER TRANSMITTER MODEL TR28-2 OPERATION AND MAINTENANCE MANUAL PARTS LIST FEATURING: *MODEL CN08-2 DIGITAL INDICATOR-TOTALIZER *ENCAPSULATED ELECTRONICS *SOLID STATE CONSTRUCTION *CURRENT OUTPUT SIGNAL *PULSE OUTPUT SIGNAL *SEALED HOUSING 3255 WEST STETSON AVENUE HEMET, CALIFORNIA 92545 U.S.A.

  • Page 2: Warranty

    30119-41 Rev. 1.6/02-07 WARRANTY This Warranty shall apply to and be limited to the original purchaser consumer of any McCrometer product. Meters or instruments defective because of faulty material or workmanship will be repaired or replaced, at the option of McCrometer, free of charge, FOB the factory in Hemet, California, within a period of one (1) year from the date of delivery.

  • Page 3: Specifications

    Transmitter provides flow rate indication, totalization DIGITAL INDICATOR-TOTALIZER-TRANSMITTER of flow volume and a current output signal proportional INDEX to the rate of flow when mounted on our meters. The TR28-2 is for installation on propeller meters. I. DESCRIPTION II. SPECIFICATIONS: ACCURACY Rate ±0.25% of reading.
  • Page 4 REMOVE the existing digital indicator by removing 2. A battery is built into the Model TR28-2 as a the four mounting screws. Lift the unit slightly, turn it backup for the rate and totalizer only in case of a over, and disconnect the two lead sensor from the bot- power failure.
  • Page 5 If the meter indicator-totalizer and remote in- to slide the base cup and digital transmitter out of the strument do not operate, check the TR28-2 by opening bonnet, allowing access to the programming buttons. and closing the lid twice. If no response, then follow all (See Programming Guide, Literature #30110-17.)
  • Page 6 First, you must know what mA signal is rent with transmitter in system (from 70.0 - 350 mA or expected from the transmitter. more), but when TR28-2 is tested separately it works fine. These shorts are difficult to find. They can be Model TR28-2 current transmitter has...
  • Page 7 Rev. 1.6/02-07 The preferred method of checking the pulse output is to use a McCrometer Model IN16 at- tached to the pulse output of the TR28-2. The McCrometer IN16 will count each time the transmitter sends a pulse. A voltmeter can also be used to check the pulse output.
  • Page 8 MODEL IN16 JUNCTION BOX REMOTE TOTALIZER RESET WIRE (IF DESIRED) (SEE IN16 DATA SHEET) Isolated Pulse Output MODEL TR28-2 Left Pin Right Pin Black (-) White (+) PULSE OUTPUT WIRING WHEN USED WITH AUXILIARY EQUIPMENT WHITE (+) AUXILIARY EQUIPMENT BLACK (-)
  • Page 9 INDICATOR - TOTALIZER - TRANSMITTER SOLID STATE CONSTRUCTION CURRENT OUTPUT PULSE OUTPUT SIGNAL ONE PULSE PER TOTALIZER COUNT DIGITAL DISPLAYS TR28-2 SIDE VIEW RED (+) AND GREEN (-) 4-20 mA (LOOP POWERED) BLACK (-) AND WHITE (+) FOR PULSE OUTPUT (ONE CONTACT PER...
  • Page 10 30119-41 Rev. 1.6/02-07 TESTING TRANSMITTER OUTPUT AND POWER SUPPLY VOLTAGE TR28-2 TRANSMITTER (4-20 mA OUTPUT) WIRED TO A MODEL IN60 ANALOG OUT INPUT NOTE: Connections for measuring the amount of current flowing in the 4-20 mA loop. RESET INPUT 4-20 mA There should be 4.0 mA with no water flowing through meter and 20.0 mA at full scale.
  • Page 11 30119-41 Rev. 1.6/02-07 WIRING DIAGRAM FOR TR28-2 TO IN41 TR28-2 TRANSMITTER (4-20 mA OUTPUT) WIRED TO A MODEL IN41 10" CHART RECORDER 24 VDC RECORDER MAIN PCB POWER SUPPLY TB-2 Isolated Pulse 4-20 mA Output Output Left Pin Right Pin...
  • Page 12 30119-41 Rev. 1.6/02-07 DIGITAL INDICATOR - TOTALIZER - TRANSMITTER MODEL TR28-2 PARTS LIST Part Number Description 5-4316-D-2 Digital Indicator-Totalizer Bonnet Assembly 1-1551-38 O-ring, Digital Indicator-Totalizer Bonnet 1-1115-10-10B Screw, Bonnet Mounting (each) 5-TR28-2 Digital Indicator-Totalizer Assembly (Items 5 to 9) 3-1910-28-2...
  • Page 13 30119-41 Rev. 1.6/02-07 DIGITAL INDICATOR - TOTALIZER - TRANSMITTER MODEL TR28-2 FOR ELECTRONIC PROPELLER METERS...
