I : MANUALE DI INSTALLAZIONE ED USO
OPERATORE PORTE PER ASCENSORI
EN : INSTRUCTION BOOK FOR USE AND INSTALLATION
DOOR OPERATOR FOR ELEVATORS
D : INSTALLATIONS- UND BEDIENUNGSHANDBUCH
AUFZUGSTÜRANTRIEB
F : MODE D'INSTALLATION ET D'EMPLOI
OPERATEUR PORTES POUR ASCENSEURS
Versione 0.1
01.06.2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPER 02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GMV OPER 02

  • Page 1 Versione 0.1 Imp. n" 01.06.2006 I : MANUALE DI INSTALLAZIONE ED USO OPERATORE PORTE PER ASCENSORI EN : INSTRUCTION BOOK FOR USE AND INSTALLATION DOOR OPERATOR FOR ELEVATORS D : INSTALLATIONS- UND BEDIENUNGSHANDBUCH AUFZUGSTÜRANTRIEB F : MODE D’INSTALLATION ET D’EMPLOI OPERATEUR PORTES POUR ASCENSEURS...
  • Page 2 Indice 01 > cap. 1 Dispositivo oper 02 05 > cap. 2 Principio di funzionamento 06 > cap. 3 Regolazioni 07 > cap. 4 Funzionamento 08 > cap. 5 Caratteristiche elettriche 09 > cap. 6 Posizione della piastrina per sostituzione cinghia Poly VJ cap.
  • Page 3 1. DEVICE OPER 02 OPER 02 is designed to control automatic elevator doors driven by a dc motor. The device carries out the following functions: · Passive operation, one or two controls All the adjustments are carried out by a trimmer ·...
  • Page 4 CARD LAYOUT AND CONNECTION TO THE OUTSIDE CIRCUITS FIG. 1 WARNING: The door closing control from the panel is to be permanent, i.e. it must drop only when the door opening one is given.
  • Page 5 1.1 OPERATOR INSTALALTION The operator is delivered with a preliminary wiring in order to facilitate the installation operations. The operator package shall include the screws and brackets required for assembly. The supply does not include – expect if expressly requested. The booth door sill, the booth parameter or the programming keyboard.
  • Page 6 3. Attachment of the booth wings. After attaching the booth wings (See Figure 4), make sure that the space between the wings and the booth shoulder between the door sill and the wing itself (See Fig. 3). Should said space not be correct (5 mm), locate the wings into the exact position by means of the purposely-allocated shims.

  • Page 7: Operating Principles

    2. OPERATING PRINCIPLES 2.1 CONNECTIONS I circuiti esterni sono collegati tramite connettori estraibili a morsetti. La suddivisione dei circuiti nei vari connettori è stata realizzata in modo tale da semplificare le operazioni di cablaggio. CONNECTOR X1 CODE DESCRIPTION Motor connection M1, M2 Opening slow-down monostable input Input common...

  • Page 8: Signaling Led's

    CONNECTOR X4 CODE DESCRIPTION Photocell projector (red) Photocell Sensor Common Photocell receptor (transparent) 2.2 SIGNALING LED'S CODE DESCRIPTION Sensor control ON = Contact closed When the magnetic passes on sensors RA and RC, LED HXC issues a pulse. When the magnetic band is on sensor EC, LED HXC remains lit. Intervention of the sensitive edge Intervention of the photocell 3.

  • Page 9: Operation

    3. 2 CARD CONTROLS Card OPER02 contains also two push-buttons for the operation in Test mode. When power supply is connected to the card, if both the push-buttons are kept under pressure for at least 1 second, the card moves into test mode, thus ignoring the control panel controls. If the push-buttons are pressed again for 1 second, the card shall resume the standard operating mode.

  • Page 10: Electrical Features

    The values of Acceleration, Deceleration, Closing Slow Speed, maintaining Current at End of Closing are fixed and unchangeable. The Closing Sensor contact (FC1-FC2) opens when the doors are completely closed, when monostable EC is read. The Max torque level is adjusted by Trimmer II If –...

  • Page 11: Maintenance

    6. PLATE POSITION TO REPLACE BELT POLY VJ Once the position of the plate is ascertained, loosen the pulley on the opposite side of the plate to loosen the toothed belt. Once the belt is loose, extract belt Poly Vj by letting it slide in your hands.
  • Page 12 ITALY GMV S.p.A. Via Don Gnocchi, 10 20016 Pero (MI) Tel. +39 02 339301 Fax +39 02 3390379 e-mail: info@gmv.it www.gmv.it...
