User Guide
PARTS DESCRIPTION
PROPER INSTALLATION
IMPROPER INSTALLATION
ELETROMAGNETIC NEON TRANSFORMER
Neon Stone is resin-type neon transformer in compliance with EN61050 which unique
structure provides extended life-time and stable running even after its warranty
period. The reliable resin body is made under high pressure vacuum using special
epoxy resin with granula silica which guarantee thermal conductivity and also
provides maximum protection against all weather conditions. Furthermore, the
protective lid features bipolar knife switch which resolves safety issues when the lid is
open. All of our products are manufactured and tested under higher standards of
quality and secure control. All you have to do is set it and forget it.
TERMINAL FOR SECONDARY
MOUNTING BRACKET
YES.
R
NO.
Daehantrans Co., Ltd.
#7-11 Songdo-Dong, Yeonsu-Gu, Incheon, Korea
Tel. +82 32 858 0491 Fax. +82 32 832 8421 www.daehantrans.com
SAFETY COVER
TERMINAL FOR GROUND
YES.
WALL
NO.
1
SPACE FOR PROTECTION DEVICE
TERMINAL FOR PRIMARY
TERMINAL FOR SECONDARY
Advertisement
Table of Contents
Summary of Contents for DAEHAN Neon Stone
- Page 1 ELETROMAGNETIC NEON TRANSFORMER User Guide Neon Stone is resin-type neon transformer in compliance with EN61050 which unique structure provides extended life-time and stable running even after its warranty period. The reliable resin body is made under high pressure vacuum using special epoxy resin with granula silica which guarantee thermal conductivity and also provides maximum protection against all weather conditions.
- Page 2 ELETROMAGNETIC NEON TRANSFORMER User Guide DANGER! HIGH VOLTAGE PRESENT DO NOT ATTEMPT TO ALTER OR REPAIR THIS POWER SUPPLY. THIS MAY CAUSE INJURY AND WILL VOID WARRANTY. HAZADOUS VOLTAGES WILL CAUSE SHOCK, BURN, OR DEATH. TURN OFF POWER BEFORE SERVICING. SERVICING SHOULD BE PERFORMED ONLY BY QUALIFIED PERSONNEL.
