- Page 1 FSC-DB006 USB Bluetooth Dev Board User Guide Type：Dev Board User Guide Version：V1.1 Date：2019.08.29 Shenzhen Feasycom Technology Co.,Ltd. Telephone: 86-755-27924639 www.feasycom.com...
-
Page 2: Usb To Uart
FSC-DB006 DISCOVERY LITE Front Image USB To UART Diode for preventing Chipset(CP2102) I‐PEX burning down Demo Model: FSC‐BT671 Same Package Modue can be LED Indicator: fixed here.Such as Power on:slow shining; BT630,BT611 and so on Connected:keep lighting ... - Page 3 FSC-DB006 dimension , location map and schematic ...
- Page 4 FSC-BT630 have Ceramic antenna ，Add I-PEX： Landscape resistor vertical resistor（I‐PEX） P1．Test Environment 1.Installed the Serial Port Driver, can get the COM NO of the Device Management from the Computer . ...
- Page 5 Remarks: The Serial Port No should be same as the COM No displaying here 2. APP Download (Android & iOS) 1) Android APP , please download from our www.feasycom.com or contact the sales man. 2) IOS APP , download from appstore or contact the sales man. P2. Using Steps： Connect to the computer’s USB Port,LED Indicator : slow shinning, this means the module is under being search & connect status.(Take our FSC‐BT671, as an example)） ...
- Page 6 If module connect to the smart phone successfully, the LED Indicator is keeping lighting all the time 2, Open Feasycom Serial Port Tool Via PC,no need to install the software， ,setting as below showing. ...
- Page 7 Serial Port TX/RX Data Byte/Packet: CRC32 3, Serial Port Status Default Turn 1 Choose the right com on no via device 2, Transfer 4, Click New This area can check the module basic info,such as name,version,mac,etc When you click the below area, the at command will display in the window, need to click the New Line ...
- Page 8 1) Android System ： Open BTComm APP,search the target Bluetooth device,click auto‐ connect,glide the interface can get the newest searching devices. Connect Successfully Default Device Received Data Feasycom RSSI： Signal Data going to send Value Send Button ...
- Page 9 Received data Send Button Transmitted data 2）IOS System：Open BLE Assistant APP, search the target Bluetooth device,click auto‐ connect, glide the interface can get the newest searching devices. Connected Successfully RSSI：Signal Default VAlue Device ： Feasycom Data input here Send button ...
- Page 10 Received data Received data Sent data Sent data P3、FAQ Q1：Power On Module, RX Command ,no feedback ： 1> Check the indicator Light : Flash or not 2>Make sure the COM NO : Correct or not a) Baud Rate Parameter: 115200 b) Serial Port Close or Open c) COM NO, whether is same as the device management of computer displaying d) RXD Pin connect to Module TXD Pin, TXD Pin connect to Module RXD Pin. e) whether click this button. Q2: Check the module whether under connection status Remarks: If the module already connected to the smart phone, the module received AT command information will be sent to the smart phone as the common data information, will not execute the AT Command. ...
- Page 11 Q3: If already follow the steps as above showing, still can not identify the AT Command, better to make the module connect the smart phone APP, using the APP to send “12345” to the module, using the OSC to monitor the TXD of the module, whether there coming out the wave shape. Send the data to the module, using the OSC to monitor the RXD of the module, whether there coming out the wave shape,meanwhile,check the smartphone get the data or not. Q4：Android Smart Phone why can not use the BLE: 1. Some old android smart phone not support BLE(We suggest to use our Bluetooth dual mode module) ...
