Summary of Contents for Stern Engineering TUBULAR
- Page 1 TUBULAR & EVER HAND DRYER I N S T A L L A T I O N A N D M A I N T E N A N C E G U I D E I N S T A L L A T I O N A N D M A I N T E N A N C E G U I D E...
- Page 2 The tradenames, trademarks, logos and service marks presented in this document, including their design, are the property of Stern Engineering Ltd or other third parties and you are not permitted to use them without the prior written consent of Stern Engineering Ltd or such...
-
Page 3: Instructions For Safe Use
INSTRUCTIONS FOR SAFE USE TECHNICAL DATA ∙ This appliance is not intended for use by persons (including 110-120 Vac, 50/60 Hz, 12.2-13.4 A, 1.34-2Kw children) with reduced physical, sensory or mental capabilities, Operating Voltage 220-240 Vac, 50/60 Hz, 6.1-6.7 A, 1.34-2Kw or lack of experience and knowledge, unless supervised or unless they have been given instruction concerning the use of Motor Thermal... -
Page 4: Pack Contents
1 x Hand dryer and attachments Hose + 2 clamps 1 x Allen key 2.5mm 1 x Allen key 3mm 1 x Allen key 7mm Tubular HD 350030 1 x Hand dryer unit 4 x Screws & Ancors Tubular HD AISI316 350040... - Page 5 4 x Screws & Ancors Hose + 2 clamps 1 x Allen key 2.5mm 1 x Allen key 3mm 1 x Allen key 7mm Tubular DP HD 350020 Tubular DP HD AISI 316 350010 1 x Hand dryer unit 4 x Screws & Ancors...
- Page 6 PACK CONTENTS TECHNICAL DATA EVER HD EVER HD 1 x Hand dryer and attachments 1 x Allen key 2.5mm 1 x Allen key 3mm Hose + 2 clamps 1 x Allen key 7mm EVER HD 230510 1 x Hand dryer unit 4 x Screws &...
-
Page 7: Installation
Continue with STEP 2: INSTALLING THE MOTOR (pages 10-11) and the bottom of the HD. O-RING STEP 1 –INSTALL THE ROUGH IN PART - TUBULAR HD DP O-RING Slide the gasket, disk and hexagonal nut In the brick or concrete wall, a hole must be carved into the wall to make space for the... - Page 8 INSTALLATION INSTALLATION CONNECTING OPEN WIRE CABLES (NOT PROVIDED) Please note that since the connector is water proof, some friction might apply. 1. O-RING VISIBLE –NOT CONNECTED PROPERLY Loosen the screws to remove the 2. ONLY THE GROOVES ARE VISIBLE – CONNECTED exising cable.
-
Page 9: Settings Adjustment
INSTALLATION SETTINGS ADJUSTMENT CHANGING THE FILTER DETECTION DELAY OUT TIME RANGE TEMPORARY OFF DELAY IN TIME Press button to release the filter housing. press FUNCTION remove and clean or replace filter. Click the filter housing back into place. SELF ADJUSTMENT SECURITY TIME MODE RESET... -
Page 10: Limited Warranty
The ideal sensor range for the specific location will If a defect is found in normal use, Y. Stern Engineering Ltd. will, at its discretion, repair, be set automatically. Once the self adjustment has taken place, the hand dryer provide a replacement part or product, or make appropriate adjustments. -
Page 11: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING TUBULAR HD / TUBULAR DP HD / EVER HD TUBULAR HD / TUBULAR DP HD / EVER HD PROBLEM INDICATION CAUSE SOLUTION ILLUSTRATION PROBLEM INDICATION CAUSE SOLUTION ILLUSTRATION Check the air filter The connector should for blockage and... -
Page 12: Spare Parts List
SPARE PARTS LIST Description Sensor for Ever HD 08004034 Sensor for Tubular HD 08004051 Sensor for Tubular DP HD 08004040 Hand Dryer (cover & filter included) 560010 Filter for Hand Dryer 08530022 Full motor and PCB 94010017 PCB for HD 240V 94010017.3... - Page 13 777 Passaic Avenue, Clifton NJ,07012, USA Tel: +1-973 773 8011 | Fax: +1-973-779-8768 Toll Free: 1-800-4364410 info@sternfaucets.com | tech@sternfaucets.com 09.22 01500546-A...
