PN6280_Hardware Design

Progress - NAVIA PN6280

Hardware Design

User Manual

V1.0

RUSSIA

2019

Table of Contents

Need help?

Do you have a question about the PN6280 and is the answer not in the manual?

Questions and answers

Summary of Contents for Navia PN6280

Page 2 This document contains proprietary technical information which is the property of JSC NIIMA PROGRESS and NAVIA LLC. Copying of this document and giving it to others and the using or communication of the contents thereof, are forbidden without express authority. Offenders are liable to the payment of damages.
Page 3: Table Of Contents
4.2 T ......................25 EMPERATURE HARACTERISTIC 4.3 A ....................... 26 BSOLUTE AXIMUM OWER 4.4 R ..................... 26 ECOMMENDED PERATING ONDITIONS 4.5 P ........................26 OWER ONSUMPTION 4.6 P ..........................27 OWER EQUENCE Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 4 6.2.1 Module confirmation and moisture ..................... 35 6.2.2 SMT reflow attentions ......................... 36 6.2.3 SMT stencil design and the problem of less tin soldering ............37 6.2.4 SMT attentions ........................... 37 SAFETY INFORMATION ........................39 Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 5: Introduction
PN6280_Hardware Design 1. Introduction PN6280 is a LGA encapsulated HSPA wireless internet access module, which has the advantages of fast Internet access speed, small size, light weight and high reliability. It can be widely used in various products and devices with wireless internet access function.
Page 6: Specifications
 Antenna：Main Antenna  Weight ：Approx 3.5g 1.4 Interfaces   GPIO  PCM: Digital audio interface  SIM: Support 1.8V/3V  UART: High speed UART  USB 2.0: High Speed ,480Mbps Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 7: Package Information
A N T G N D SI M Po w er K ey P C M U SB U A R T I I C O th er Figure 2-1 PN6280 Pin View Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 8: Pin Definition
Ground U1RXD UART1 receive data input DVDD18 Open U1TXD UART1 transmit output DVDD18 Open Ground Host to set the module into sleep or wake WAKEIN DVDD18 Open up the module from sleep Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 9 NETLIGHT DVDD18 Open status GPIO52 General input/output PIN DVDD18 Open GPIO51 General input/output PIN DVDD18 Open Ground Ground MAIN_ANT Main antenna Open Ground Ground VBAT VBAT Power supply 3.3～4.2V VBAT VBAT Ground Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 10 Open UART0_DTR UART0 Data terminal ready DVDD18 Open Ground TX_EN TX Enable signal DVDD18 Open GPIO17 General input/output PIN DVDD18 Open Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 11 Notes：All IO ports module provides need to be out of floating in the boot process. If the IO is pulled up by the external voltage before booting, it may cause the module not to start normally. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 12: Package Information
DO:DIGITAL OUTPUT ANT:ANTENNA DIO:DIGITAL INPUT OUTPUT NC:NOT CONNECT 2.3 Package Information 2.3.1 Dimensions The PN6280 mechanical dimensions are described as following figure (Top view, Back view, Side view). Figure 2-2 Mechanical Dimensions Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 13: Product Labeling
Table 2-3 Description of label Item Description Pin1 mark Logo of companies Module name (model) QR code---include IMEI number WEEE IMEI number SN number Module description (2G/3G module) QR code---include SN number CE certification mark Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 14: Module Size
PN6280_Hardware Design 2.3.3 Module size Figure 2-4 Module Size (Unit: mm) 2.3.4 Recommend decal Figure 2-5 Recommend pad (front view, unti: mm) Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 15: Interface Circuit Design
Notes: According to the environment, please select capacitor as large value as possible; and add 100pF, 33pF capacitors if requiring. Add Zener close to our module. The Zener should be 5.1V/500mW, Ir<100uA @Vr=4.2V. Ta=25℃. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 16: Power Pin Description
PWRKEY is grounded directly. If you do not need to power on the boot, you can control the PWRKEY to achieve. Typical circuit is shown in figure 3-2. Figure 3-2 Control module boot circuit Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 17: Hardware Reset
Figure 3-3 System Reset Interface 3.2 USIM 3.2.1 Pin description PN6280 supports and be able to automatically detect 3.0V and 1.8V USIM card. USIM card interface signal as shown in table 3-1. Table 3-1 (U)SIM Pin Description Pin NO. Pin Name...
Page 18: Usim Application
The USB interface of the module conforms to the USB2.0 specification and electrical characteristics. Support the low-speed, full-speed and high-speed three operating modes. The data exchange between the main processor (AP) and the module is mainly completed through the USB interface. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 19 MCU, the position of the DM / DP signal near the module needs to reserve a test point and the DM/DP requires a series 0R resistor. The resistor is placed near the module and the test point is placed between module and resistor. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 20: Pcm Interface
3.4 PCM Interface PCM application PN6280 provides a digital audio interface (PCM) that can be used as a PCM master device to transmit digital voice signals. PN6280 only acts as a master device. PCM sync, PCM CLK are as output pins and PCM sync output 16kHz synchronization signals, the PCM data support 8-bit or 16 bit data format.
Page 21: Iic Interface
PN6280_Hardware Design 3.5 IIC Interface PN6280 module does not have a dedicated IIC interface. If you need to use the IIC interface for communication, you should use the GPIO port to simulate the IIC interface, and it is recommended to use an external pull-up resistor of 4.7K by VIO18.
Page 22: Uart Application
2 wires mode connection. Module interface level is 1.8V. If the AP interface level does not match, you must increase the level conversion circuit. PN6280 Figure 3-8 Connect to AP method(4lines) PN6280 Serial Port Serial Port RING RING Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 23: Interactive Application Interface
If it is unused, left open Note：If need to use more GPIO ports, you can refer to table 2-1; User can read and write GPIO port state through the AT command. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 24: Led Interface
Figure 3-10 LED Circuit 3.8.2 LED state description NETLIGHT/GPIO54 is used as the enable pin. Table 3-4 lists the LED status. Table 3-4 LED Status LED Status Module Status Always On Searching Network/Call Connect Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 25 PN6280_Hardware Design 300ms ON, 300ms OFF Data Transmit 800ms ON, 800ms OFF Registered network Power off / Sleep Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 26: Electrical Characteristics
Using the DCDC supply, please ensure the ability of DCDC over 2.0A. We don’t suggest the LDO as the power supplier. 4.2 Temperature Characteristic Table 4-2 Temperature characteristic State Min. Nom. Unit ℃ Working ℃ Storage Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 27: Absolute Maximum Power
Digital power input for IO Note: All the GPIOs of module are 1.8V. 4.5 Power Consumption Table 4-5 Power Consumption Parameter Conditions Min. Average Max. Unit Standby current Flight mode Suspend state Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 28: Power Sequence
2G only WCDMA only USB+Fltght mode 21.8 GSM900,MAX Power DCS1800，MAX Power WCDMA@CH3012,MAX Power WCDMA@CH10700,MAX Power Peak current Max power mode burst current 4.6 Power Sequence Figure 4-1 Power up time sequence diagram Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 29: Digital Interface Characteristics
The ESD test results are shown in the following table. ESD parameter（Tem：25℃，humidity：45%）. Table 4-7 ESD Performance PIN Name Contact discharge Air discharge ±4KV ±8KV VBAT Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 30 Notes: For ESD protect, please add ESD methods according to upper ways. High speed circuits like USB, TF and SIM card should be added ESD with low capacity value. ESD components include varistors and TVS. For better performance, please use TVS. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 31: Rf Features
30dBm ±2dB 0dBm ±5dB DCS1800 27dBm ±3dB 5dBm ±5dB E-GSM900(8-PSK) 0dBm ±5dB DCS1800(8-PSK) 26dBm +3/-4dB -56dBm ±5dB UMTS2100 24dBm +1/-3dB -56dBm ±5dB UMTS900 24dBm +1/-3dB Table 5-3 Receive Sensitivity Frequency Receive sensitivity Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 32: Data Link
<-109dBm DCS1800 <-109dBm UMTS2100 <-109dBm UMTS900 <-109dBm 5.2 Data Link PN6280 supports GPRS/EDGE CLASS 12and HSDPA/HSDPA R8. The actual application depends on the local network operator. Table 5-4 Data Link Version Function Max supported Theoretical max peak rate PN6280 GPRS 85.6kbps...
Page 33 To ensure the high performance of the module, the interference must be under control. Suggestions: keep speaker, LCD, CPU, FPC wire routing, audio circuits, and power supply away from the antenna, and add appropriate filtering and shielding protection, or adding filtering devices on the traces. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 34 (e.g. certified CE, FCC, etc.) and should be placed as close as possible to the module. The RF path from the module pad to the antenna feed point should be controlled by 50 ohms impedance Storage and Production. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 35: Storage And Production
6.2 Production The module is a humidity sensitive device. If the device needs reflow soldering, disassembly and maintenance, we must strictly comply with the requirements of humidity sensitive device. If module is Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 36: Module Confirmation And Moisture
5. Module is placed naked in the air under 168 hours but not temp 30°C and humidity < 60%. Baking condition confirmation The moisture proof level of the smart module is level 3. And the baking conditions are as follows. Table 6-2 Baking conditions 40°C/ 5%RH Baking conditions 120°C/ 5%RH Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 37: Smt Reflow Attentions
 Modules can’t be vibrate larger, namely customer requirements as far as possible in orbit (chain) furnace, furnace, avoid on the barbed wire furnace, in order to ensure smooth furnace. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 38: Smt Stencil Design And The Problem Of Less Tin Soldering
"a furnace vehicle" to ensure the welding quality. Other production proposals are as follows:  The solder pastes use brands like Alfa.  The module must use the SMT machine mount (important), and do not recommend manually placed or manual welding. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 39 Note: customer’s board deformation must be controlled well. By reducing the number of imposition or increasing patch clamp to reduce the deformation. Module thickness of the stencil is recommended to be thickened, and the rest position can be maintained by 0.1mm. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
Page 40: Safety Information
The users and product manufacturers should abide by the national law of wireless modules and devices. If not, JSC NIIMA PROGRESS and NAVIA LLC will not respond the related damages. Copyright © JSC NIIMA PROGRESS and NAVIA LLC...
