CRATE AUDIO PA6FX User Manual

C R AT E A U D I O
PA6FX / PA8FX
Box Mixer with Digital Effects
Congratulations!
You are now the proud owner of one of the most versatile and economical powered mixers available, the Crate Audio
PA6FX/PA8FX Box Mixer with Digital Effects. These compact units feature Crate's legendary performance and high quality con-
struction in rugged and easy to operate packages. Each mixer features a combination 1/4" and XLR-type balanced input jack
on every channel. The Master control section features a three-band EQ, DSP Return, Main Level control, an Effects Loop with
Return Level control, Aux In, Monitor Out with Level control, Tape In/Out jacks and a rotary DSP Effects Selector. The internal
power amplifier is capable of delivering 150 watts into 4 ohms and 220 watts into 2 ohms. Rear-panel Line In/Line Out jacks
and dual 1/4" speaker outputs give you even greater flexibility and performance from these small but power-packed units!
Your PA6FX/PA8FX is designed by musicians and built using only the best components. Extensive testing and Crate's Five-
Year Warranty assure you that your new mixer is the absolute best it can be. In order to get the most out of it, we strongly
urge you to read this guide before using the mixer.
