Summary of Contents for MLR E-ZLIFT DELUXE
- Page 1 USER MANUAL PLEASE READ ALL INSTRUCTIONS FIRST!! Do not over tighten 1/4” bolts...10ft lbs is max torque!!!
- Page 2 Improper installation or use may void all warranties. MLR Fabricating LLC , must be notified of a failure within the warranty period and will then supply instructions to Customer .
- Page 3 ASSEMBLY INSTRUCTIONS 1) Remove from cartons & place on flat surface. 2) Place lift so that logos are to the outside. 3) Install 2 bridge assemblies with 1/4" x 1-3/4” bolts flat washers & lock nuts provided, match up numbers. (snug bolts only for now) 4) Connect hoses to 90 degree fittings on cylinder.
- Page 4 E-Z Lift Operating Instructions 1) Choose a spot that is as flat as possible. 2) Lift goes under car with hose attachment point to rear. 3) Place Lift on Ground & position car over lift with hose to rear. 4) Try to center lift left to right as close as possible on frame rails. 5) For starting front to rear alignment put front lift points about 2 inches behind bend in frame rail.
-
Page 5: Handle Assembly
HANDLE ASSEMBLY...
