Summary of Contents for Axiris ArduIN-9
- Page 1 ArduIN-9 Main & Expansion Board User Manual February 2013...
-
Page 2: Table Of Contents
ArduIN-9 Table of Contents Features Technical Specifications Safety Precautions ArduIN-9 Main Board Board Overview IN-9 Tubes Connectors (K10, K11, K12, K13) Connector for Expansion Board & Calibration (K14) Voltage Adjustment for the IN-9 Tubes (P1) Solder Pads (K2-K9) Driving the IN-9 Tubes... -
Page 3: Features
Arduino Uno 3 Safety Precautions SAFETY PRECAUTIONS DO NOT TOUCH THE ARDUIN-9 MAIN BOARD OR ARDUIN-9 EXPANSION BOARD WHEN IT IS POWERED UP. SOME COMPONENTS HEAT UP DURING OPERATION. DO NOT MOUNT OR PLACE THE ARDUIN-9 MAIN BOARD OR ARDUIN-9 EXPANSION BOARD CLOSE TO INFLAMMABLE MATERIALS. -
Page 4: Arduin-9 Main Board
ArduIN-9 4 ArduIN-9 Main Board Board Overview Mark Label Description K2, K3 Solder pads for connector, see Arduino Uno DIGITAL pins K6, K7 Solder pads for connector, see Arduino Uno DIGITAL pins Voltage adjustment for the IN-9 tubes Power connector... -
Page 5: In-9 Tubes Connectors (K10, K11, K12, K13)
ArduIN-9 IN-9 Tubes Connectors (K10, K11, K12, K13) Mark Description Cathode of tube #1 Anode (grid) of tube #1 Cathode of tube #2 Anode (grid) of tube #2 Cathode of tube #3 Anode (grid) of tube #3 Cathode of tube #4 Anode (grid) of tube #4 Connect the IN-9 tubes to these connectors. -
Page 6: Solder Pads (K2-K9)
You can solder the supplied connectors the way you like. If you're planning to stick the ArduIN-9 onto your Arduino Uno, then mount the supplied connectors according to the Uno's connectors. If you're going to use the ArduIN-9 without Arduino Uno, you can use the solder pads specifically for your application. -
Page 7: Arduin-9 Expansion Board
ArduIN-9 5 ArduIN-9 Expansion Board Board Overview Mark Label Description PWM inputs Connection with main board K3, K4, Connectors for the IN-9 tubes (numbered #5 to #8). K5, K6 PWM Inputs (K2) Mark Description PWM input for tube #5 PWM input for tube #6... -
Page 8: Connection With Main Board (K1)
ArduIN-9 Connection with Main Board (K1) Mark Description 12 VDC Ground Voltage doubler input IN-9 supply voltage K1 must be connected to main board connector K14. IN-9 Tubes Connectors (K3, K4, K5, K6) Mark Description Cathode of tube #5 Anode (grid) of tube #5... -
Page 9: Disclaimer
ArduIN-9 6 Disclaimer Axiris products are not designed, authorized or warranted to be suitable for use in space, nautical, space, military, medical, life-critical or safety-critical devices or equipment. Axiris products are not designed, authorized or warranted to be suitable for use in applications where failure or malfunction of an Axiris product can result in personal injury, death, property damage or environmental damage.
