JB-1.2, JB-1.XL
Quick Start Guide
0-2 INCHES
STEP 1
STEP 2
Determine location for JB-1 on the roof surface.
USE THE LID AS A GUIDE, and place the top of the lid
0-2" from the bottom of the 2nd course of shingles and
trace the outline of the lid on the 1st course of shingles.
STEP 3
Within the Drill Zone, add the appropriately sized hole(s) into
the attic. Apply sealant to the underside following the sealant
guide. After fittings, connections are complete, finish by installing
the lid.
WATCH INSTALLATION VIDEO
Advertisement
Table of Contents
Summary of Contents for EZ JB-1.2
- Page 1 JB-1.2, JB-1.XL Quick Start Guide 0-2 INCHES STEP 1 STEP 2 Determine location for JB-1 on the roof surface. USE THE LID AS A GUIDE, and place the top of the lid 0-2” from the bottom of the 2nd course of shingles and trace the outline of the lid on the 1st course of shingles.
- Page 2 JB-1.2, JB-1.XL Installation Manual PV Junction Box for Composition/Asphalt Shingle Roofs A. Step-by-Step Instructions Determine location for JB-1 on the roof surface. USE THE LID AS A GUIDE, and place the top of the lid 0-2” from the bottom of the 2nd course of shingles and trace the outline of the lid on the 1st course of shingles.
- Page 3 B. Materials Included JB-1.2 JB-1.XL (1) JB-1.2 Body (1) JB-1.XL Body (1) JB-1.2 Lid (1) JB-1.XL Lid (1) Neutral Bar and Din Rail (1) Neutral Bar and Din Rail (6) #8 x 3/4” Phillips pan head screw (6) #8 x 3/4” Phillips pan head screw (6) #10 x 1-1/4”...
- Page 4 • System Marking: Intertek Symbol and File # 5019942 • Periodic Re-inspections: If re-inspections yield loose components, loose fasteners, or any corrosion between components, components that are found to be affected are to be replaced immediately. STOP WARNING! IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS AND SAFETY WARNINGS PRIOR TO INSTALLATION NOTE: SAVE THESE INSTRUCTIONS This manual contains important instructions that shall be followed during installation and maintenance of the system.
- Page 5 Lethal voltages are present during the installation, operation and service of this equipment. Proper precautions must be taken at all items to ensure the safety of the service personnel. At all times follow state and federal occupational safety and health administration (OSHA) guidelines and regulations. Utilize proper Personal Protective Equipment (PPE) as required per national and local regulations as well as for installation best practices.
