User Manual
BOP HD8 / BOP HD16
User Manual
BOP HD8 / BOP HD16
Edition 1.0
Ref.: IR1212828 A 21.08.2009
Dokumentenvorlage Erstellt von/am: R&D/ 16.03.2009 IR11263E
Edition 1.0
I + M E A C T I A G m b H
I + ME ACTIA
Informatik und Mikro-Elektronik
GmbH
Dresdenstrasse 17/18
D-38124 Braunschweig
Germany
Tel.: ++ 49 (0) 531 38701-0
Fax: ++ 49 (0) 531 38701-88
www.ime-actia.com
Page 1/87

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BOP HD8 and is the answer not in the manual?

Questions and answers

Summary of Contents for I+ME ACTIA BOP HD8

  • Page 1 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H I + ME ACTIA Informatik und Mikro-Elektronik GmbH Dresdenstrasse 17/18 D-38124 Braunschweig Germany Tel.: ++ 49 (0) 531 38701-0 Fax: ++ 49 (0) 531 38701-88 www.ime-actia.com...
  • Page 2 Page Date Reason of Change Name © 2009 I+ME ACTIA GmbH All Rights reserved. Any reproduction or distribution of this document, or parts of this document is prohibited without a written authorisation of I+ME ACTIA GmbH. Ref.: IR1212828 A 21.08.2009 Edition 1.0...
  • Page 3: Table Of Contents

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H Content 1. Introduction ......................7 1.1 This manual......................7 1.2 Warranty......................8 1.3 For safety......................8 1.4 Intended use ....................8 1.5 Function......................9 1.6 Used Symbols and notation.................9 2.
  • Page 4 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.3.1. Error file err.txt..................41 6.3.1.1 How to open the error file ..............41 6.3.1.2 How to delete the error file ..............41 6.3.1.3...
  • Page 5 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.10.3 Gateway .................... 63 6.4.10.4 Nameserver1 / Nameserver2 ..............63 6.4.10.5 Broadcast destination address............... 63 6.4.10.6 Alarm rx OFF/ON................. 63 6.4.11.
  • Page 6 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H Ref.: IR1212828 A 21.08.2009 Edition 1.0 Page 6/87...
  • Page 7: Introduction

    BOP HD8 / BOP HD16 I + M E A C T I A G m b H NTRODUCTION HIS MANUAL This manual describes the I+ME ACTIA video protection system BOP HD. Variants: BOP HD8 (8 x video in) BOP HD16...
  • Page 8: Warranty

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H ARRANTY The term of warranty fort he video protection system BOP HD is 24 months from date of purchase unless otherwise agreed. During the term of warranty we will repair all defects the reasons of which are proven to be defects of material or manufacturing.
  • Page 9: Function

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H UNCTION The ACTIA video protection system BOP HD records the video and audio data of the attached cameras, microphones and peripheral devices (e.g. GPS) as well as additional information from the vehicle.
  • Page 10 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H Ref.: IR1212828 A 21.08.2009 Edition 1.0 Page 10/87...
  • Page 11: General System Describtion - Bop Hd

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H – BOP HD ENERAL SYSTEM DESCRIBTION The BOP HD is a digital video protection system especially for the use in public transport such as buses and trains.
  • Page 12 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H To analyse the data the BOP Reviewer Software from I+ME ACTIA could be used. Main components BOP HD with - CPU and graphics processor...
  • Page 13: Front Side - Bop Hd

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H - BOP HD RONT SIDE At the front panel all control elements and gauges are arranged. The Ethernet connector for configuration and maintenance is also placed at the front panel. Normally after the integration the BOP HD must not dismounted for maintenance and configuration.
  • Page 14: Operating Status Display

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H At an error the red service LED is flashing and the event is stored into the error file. The change of the operation mode is receipted by a short concurrent flash of the LED`s “Record”...
  • Page 15: Lan Interface

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 2.1.3. LAN INTERFACE The Ethernet interface at the front panel is used for system configuration (by use of the web interface)
  • Page 16: Reset Switch

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 2.1.5. R ESET SWITCH Danger of data loss By restarting the BOP HD via the reset switch data can be lost.
  • Page 17: Rear Panel - Bop Hd

    AMERA ADAPTERS Up to 8 (16) cameras can be attached to the BOP HD. A large range of cameras are available at I+ME ACTIA. We advise to use only cameras which are released by I+ME ACTIA. You obtain detailed information from your specialist dealer or directly from I+ME ACTIA.
  • Page 18: Usb Ports

    Additional an integrated video processor makes it possible to display several video signals at the same time on the monitor. A large range of monitors are available at I+ME ACTIA. We advise the only use of monitors which are released by I+ME. You obtain detailed information from your specialist dealer or directly from I+ME ACTIA.
  • Page 19: Plug 1 - 18 Pin

    ICROPHONES Two microphones can be attached for recording of audio data. Microphones are available at I+ME ACTIA. We advise to use only microphones which are released by I+ME. You obtain detailed information from your specialist dealer or directly from I+ME ACTIA.
  • Page 20: Plug 2 - 21 Pin

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 2.2.6. P 2 – 21 PIN Plug 2 is engaged with connector for power supply (clamp 30 and 31) ignition (clamp 15)
  • Page 21: Can-Interface

    BOP Reviewer Software. It’s possible to use the inputs IN 4 and IN 5 for analysing of analogue signals. Please contact I+ME ACTIA for further information. Ref.: IR1212828 A 21.08.2009 Edition 1.0...
  • Page 22: Installation

    During connection of peripherical devices, regard their specifications, advices for mounting and information about the handling of. If you have any question about the installation of the ACTIA video protection system, please ask your specialist dealer or contact I+ME ACTIA. Ref.: IR1212828 A 21.08.2009 Edition 1.0...
  • Page 23: Assembly

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H SSEMBLY Observe the following notes during selection of the mounting place of the BOP HD. The BOP HD may not be directly exposed to climatic influence.
  • Page 24: Connection Diagramm

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H ONNECTION DIAGRAMM Ref.: IR1212828 A 21.08.2009 Edition 1.0 Page 24/87...
  • Page 25: Interfaces / Integration Of The Bop Hd

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H BOP HD NTERFACES NTEGRATION OF THE Ref.: IR1212828 A 21.08.2009 Edition 1.0 Page 25/87...
  • Page 26: Plug 1 - 18Pin

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 1 – 18PIN For Customer specific Cables, please contact I+ME ACTIA. Type of plug: TYCO 966140-1F Description Note MIC 12V...
  • Page 27: Plug 2 - 21Pin

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 2 – 21PIN Several sets of connection leads are available at I+ME ACTIA. Type of plug: TYCO 966140-6F Description Note...
  • Page 28: Connection Of The Power Supply

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H ONNECTION OF THE OWER SUPPLY Specification of the power supply Input voltage 10-32 VDC (typical 12VDC or 24VDC) max. current: 8A at 12VDC...
  • Page 29: Connection Of Cameras

    AMERAS Beware of faulty function On cameras, which are not obtained from I+ME ACTIA or which are not approved by I+ME ACTIA, the specification must be obtained. Ask your specialist dealer or I+ME ACTIA whether the desired camera could be used.
  • Page 30: Connection Of Microphones

    ONNECTION OF MONITORS Beware of faulty function If monitors are used which are not obtained from I+ME ACTIA or which are not approved by I+ME ACTIA the specifications must be obtained. Ask your specialist dealer or I+ME ACTIA whether the desired monitors could be used.
  • Page 31: Gps Receiver

    RECEIVER For recording of GPS Position Information a GPS receiver could be connected. Connection at USB port Only GPS receivers, which are approved by I+ME ACTIA should be used. Ask your specialist dealer or I-ME ACTIA for further information. IBIS 3.14...
  • Page 32: Commissioning / Configuration

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H OMMISSIONING ONFIGURATION Beware of faulty function If the configuration is faulty, the system could work incorrect. Therefore -> Commissioning and system modifications only by authorized and trained staff.
  • Page 33: External Access

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H XTERNAL ACCESS 4.1.1. V IDEO TREAMING By using the RTSP protocol an external access to the video channels is possible (password protected).
  • Page 34: Operation Of The Bop Hd

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H BOP HD PERATION OF THE After commissioning the BOP HD is set to the mode >PAUSE< or >RECORD< by the key- switch.
  • Page 35: Data Storage - Assemble And Change

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H ATA STORAGE ASSEMBLE AND CHANGE The data storage is locked electromagnetically and can only be removed whether the BOP HD is set to >OFF< via the key-switch.
  • Page 36: Data Storage - Storage And Transport

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H ATA STORAGE STORAGE AND TRANSPORT The BOP HD data storage is equal to the requirements of the automotive industry. The integrated hard disks are shock damped mounted. For all the robust design, damage can not be excluded by improper handling.
  • Page 37 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H Ref.: IR1212828 A 21.08.2009 Edition 1.0 Page 37/87...
  • Page 38: The Bop Hd Web Interface

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H BOP HD W NTERFACE Live pictures Maintenance Configuration Configuration load/save Firmware update Passwords Format the data storage Access to the data storage by >/hdd<...
  • Page 39: Start Of The Bop Hd Web Interface

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H BOP HD W TART OF THE NTERFACE Connect the front or rear Ethernet interface of the BOP HD via a network cable to your PC (see also chapter 2.1.3, 2.2.4 and 8.7).
  • Page 40: Live Pictures

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H IVE PICTURES In the [Live View] mode it is possible to display a video channel directly at the web browser. Precondition is the installation of the newest VLC media player at the PC.
  • Page 41: Maintenance

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H AINTENANCE On the [Maintenance] tab you have access to the error file and the log files. 6.3.1. E RROR FILE At the error file err.txt all events are legged which make an error while data recording.
  • Page 42: Design Of The Error File

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.3.1.3 ESIGN OF THE ERROR FILE First line The first line informs about the date of creation of the error file or the last delete of the error file.
  • Page 43: Log Txt

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.3.2. L OG FILE In the log files all important system events are logged. To interpret these information additional background knowledge is necessary.
  • Page 44: Configuration

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H ONFIGURATION At the [Configuration] tab the peripherical devices and the behaviour of the BOP HD is defined. Beware of malfunction The configuration affects to the behaviour of the BOP HD.
  • Page 45: Info Line

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.1. I NFO LINE The info line shows Date and time when the configuration was saved last. 6.4.2. D ATE AND TIME The BOP HD contains a real time clock (RTC).
  • Page 46: Pc Date And Time

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.2.1 PC D ATE AND TIME Actual date and time at the connected PC. 6.4.2.2 BOP HD-RTC D ATE AND TIME Actual date and time on the BOP HD real time clock.
  • Page 47: General Settings

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.3. G ENERAL SETTINGS The general settings particularly influence the alarm data recording, error messages and the shut down delay of the BOP HD.
  • Page 48: Shutdown Delay

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.3.4 HUTDOWN DELAY The video protection system BOP HD does not shut off directly with the drop out of the ignition.
  • Page 49: Maximum Buffer Time

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.3.7 AXIMUM BUFFER TIME The maximum buffer time specifies how long the data will be stored on the ring buffer. All data which are older as the specified period will be deleted automatically.
  • Page 50: Error Signaling Time

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.3.9 RROR SIGNALING TIME The error signalling time specifies how long an error is showed by the service LED and the relay 4.
  • Page 51: Video Settings

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.4. V IDEO SETTINGS The video settings (settings of the codec) have affect to all video sources. 6.4.4.1 RAME SIZE...
  • Page 52: Compression / Quality

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.4.3 OMPRESSION UALITY The compression and therefore the picture quality follow the data rate. A smaller data rate causes a higher compression.
  • Page 53: Streaming Mode

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H Adaptive Frame Rate can reduce compression artefacts. Compression artefacts are caused by low data rates and much movement on video file. Adaptive Frame Rate will reduce the frames per second to minimise compression artefacts.
  • Page 54: Video Out #1 Mapping

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.4.8 IDEO OUT MAPPING The multi picture view of Video Output 1 also can be recorded. no record of multi picture view...
  • Page 55: Video Output 1

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.6. V IDEO OUTPUT All the Video Inputs can be shown automatically in a cycle on the Video Output 1. A reverse camera and a door camera can be defined with a display priority.
  • Page 56: Cycling Control

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.6.2 YCLING CONTROL The single steps of the sequence are separated by a comma. The whole sequence will be repeated if >automatic cycling< is activated.
  • Page 57: Non-Cycling Video Input (Standard Video In)

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.6.3 CYCLING VIDEO INPUT TANDARD VIDEO IN The Non-Cycling Video Input is the Input which is shown when automatic cycling is not activated.
  • Page 58: Video Output 2

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.7. V IDEO OUTPUT 6.4.7.1 UTOMATIC CYCLING Equal to Video Output 1. See Chapter 6.4.6.1 6.4.7.2 YCLING CONTROL Equal to Video Output 1 with the restriction that only quad screen can be shown in Multipicture view.
  • Page 59: Relays

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.8. R ELAYS The Relays can signal events or the system state to other devices. Default Relay Function: Relay 1: BOP Active Relay. Close when BOP is active. Only open if BOP is out of service Relay 2: While Recording Relay.
  • Page 60: Alarm Signaling

    1 Relay should be used 6.4.9. IBIS BOP HD can be connected to the IBIS-BUS by using the BOP HD IBIS interface. Please ask your specialist dealer or I+ME ACTIA for further information. 6.4.9.1 IBIS TIME ADJUSTMENT This setting activates the time synchronisation to the IBIS-BUS time.
  • Page 61: Automatic System Restart

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.9.2 UTOMATIC SYSTEM RESTART To synchronise the system time with the real time clock, a restart has to be done. This can be done automatically to a specified time.
  • Page 62: Network Access Parameters

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.10. N ETWORK ACCESS PARAMETERS The Network Access Parameters define the parameters of the Ethernet interface on the front and rear panel.
  • Page 63: Gateway

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.10.3 ATEWAY Special Network setting. Please contact your Network Adminidrator. 6.4.10.4 1 / N AMESERVER AMESERVER Special Network setting. Please contact you Network Adminidrator.
  • Page 64: Error Log And Alarm Video File Transfer

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.4.11. E RROR LOG AND ALARM VIDEO FILE TRANSFER After an alarm or an error, special files can be transferred to an ftp server automatically.
  • Page 65: Reload / Save / Save + Restart

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H ALARM video transfer OFF/ON Only all files of the log directory will be transferred. All files of the log and the alarm directory will be transferred.
  • Page 66: Configuration Load/Save - Firmware Upload

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H – F ONFIGURATION IRMWARE UPLOAD At the Tab [Configuration Load/Save – Firmware upload] a system configuration can be saved or reloaded from the PC. Also a firmware update can be done.
  • Page 67: How To Load A Configuration / How To Load A Configuration With Restart

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.5.2. H OW TO LOAD A CONFIGURATION OW TO LOAD A ONFIGURATION WITH RESTART Click [Browse] and select the configuration file on your pc. After that click [->BOP HD] to save the configuration on the BOP HD or click [->BOP HD + restart] to save and restart.
  • Page 68 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H jimg Image file VSS4 Video surveillance system 4 2-5-91 Firmware Revision country or customer code Ref.: IR1212828 A 21.08.2009 Edition 1.0...
  • Page 69: Administrator

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H DMINISTRATOR Access to the BOP web interface is saved by password. On the tab [Admin] passwords can be changed, a direct connection to the HDD is supported and the HDD can be formatted.
  • Page 70: Passwords

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.6.1. P ASSWORDS Beware of unauthorised access As a protection against unauthorised access, all passwords should be changed and saved confident. If passwords are lost, please contact your specialist dealer or directly I+ME ACTIA.
  • Page 71: Access To The Data Storage

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.6.2. A CCESS TO THE DATA STORAGE By the link >/hdd/< you have read only access to the main folder /hdd. This folder contains among other things the recorded video and audio data.
  • Page 72: Structure And Content

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.6.2.2 TRUCTURE AND CONTENT Folder - alarm The alarm folder contains all files which are stored at an alarm. Folder - audio* The folders audio1 and audio2 containing the audio data of the corresponding audio sources.
  • Page 73: How To Format The Data Storage

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 6.6.3. H OW TO FORMAT THE DATA STORAGE Warning of lost data Formatting the HDD will delete all data on the HDD.
  • Page 74: Data Analysis

    HD. The BOP HD hast to be put into >PAUSE< mode. BOP R EVIEWER OFTWARE The BOP Reviewer Software of I+ME ACTIA realizes a comfortable way to analyse the footage of BOP HD. To use the BOP Reviewer Software a PC has to fulfil the following requirements: ®...
  • Page 75 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H Ref.: IR1212828 A 21.08.2009 Edition 1.0 Page 75/87...
  • Page 76: Annex

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H NNEX BBREVIATIONS AND LOSSARY Abbreviation Comment BOP HD Best Of Protection – High Definition BOP HD 8 BOP HD with 8 x video in...
  • Page 77: Technical Data - Video Protection System Bop Hd

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H – BOP HD ECHNICAL DATA VIDEO PROTECTION SYSTEM 8.2.1. S YSTEM DATA Key switch PAUSE RECORD Interfaces 2 x Ethernet (10/100 Megabit and 10/100/1000 Megabit)
  • Page 78: Technical Data

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 8.2.2. T ECHNICAL DATA Camera supply 12 VDC / max. 6A Monitor interface BNC / 75 Ohm / 1Vss / FBAS / PAL or NTSC Microphone interface 12 VDC / max.
  • Page 79: Ethernet - Interfaces

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 8.2.3. E THERNET INTERFACES Front Panel Ethernet Interface Configuration via the web interface Data transmission / system update Specification IEEE802.3 BaseT with automatically transfer rate detection 10/100 MBit without auto crossing;...
  • Page 80: Recording Time

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 8.2.4. R ECORDING TIME The recording time can be estimated by following formula. Capacity of the data storage (in GByte) Recording time = ------------------------------------------------------------ x 1.9...
  • Page 81: Dimensional Drawings

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H IMENSIONAL DRAWINGS Ref.: IR1212828 A 21.08.2009 Edition 1.0 Page 81/87...
  • Page 82: Error Messages The File Err Txt

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H RROR MESSAGES THE FILE ERR In this Chapter the most important error messages of the err.txt file are described. The possible reason and solutions are named.
  • Page 83 User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H Error on Power supply Message: Jun 20 09:12:46 bop81 user.err syslog: (0265:03) uncontrolled POWER-OFF or RESTART or HDD access failure Reason: - external power supply has been interrupted.
  • Page 84 Jun 12 05:05:40 bop81 daemon.err klogd: SJA1000.iocINIT: ### CLOCK measure error, set on 24MHz Reason: - CAN Chip not initialised correctly Action: - hardware error. Please contact I+ME ACTIA. This error can cause USB malfunction Ref.: IR1212828 A 21.08.2009 Edition 1.0 Page 84/87...
  • Page 85: Certificates And Approvals

    A lot of Equipment is available for BOP HD: Assembling Accessories Cameras Microphones Monitors GPS-Modules BOP Reviewer Software … Further information about the BOP HD Accessories you can obtain by your specialist dealer or directly by I+ME ACTIA. Ref.: IR1212828 A 21.08.2009 Edition 1.0 Page 85/87...
  • Page 86: Network And Browser Settings At The Pc / Notebook

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H PC / N ETWORK AND BROWSER SETTINGS AT THE OTEBOOK The following information describes the necessary settings on a PC or a Notebook with Windows XP, to get a connection between computer and the Ethernet Interface on the front panel.
  • Page 87: Microsoft Internet Explorer

    User Manual BOP HD8 / BOP HD16 I + M E A C T I A G m b H 8.7.2. M ICROSOFT NTERNET XPLORER Start the Internet Explorer Open [Extras] [Internet Options] [Connection] and select [LAN settings] Select [Extended] and wire in the address at >exceptions< >192.168.72.200< or >192.168.72.*<...
