- Page 1 OWnEr’s MAnuAL LED LCD MOnITOr (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 34WQ75C 34WQ75X www.lg.com 34WQ73A Copyright © 2022 LG Electronics Inc. All rights reserved.
-
Page 2: Table Of Contents
TabLE of CoNTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICEnsE ............2 OPEn sOurCE sOFTWArE nOTICE The terms HDMI and HDMI High-Definition Multimedia Interface, InFOrMATIOn ..........3 and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 3: Open Source Software Notice Information
Supported Drivers and Software LG Electronics will also provide open source code to you on CD-rOM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. - Page 4 product and button Description How to use the Joystick button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ down with your finger. basic functions Press the joystick button once with your finger power on to turn on the monitor.
- Page 5 moving and Lifting the monitor Installing on a Table • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm (3.94 When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or inches) away from the wall to ensure sufficient ventilation.
- Page 6 adjusting the Stand Height adjusting the angle Place the monitor mounted on the stand base in an upright position. Place the monitor mounted on the stand base in an upright position. Handle the monitor with both hands for safety. Adjust the angle of the screen. The angle of the screen can be adjusted forward or backward from -5°...
- Page 7 using the Kensington Lock Installing the wall mount plate The connector for the Kensington security system is located at the back of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website NoTE at http://www.kensington.com.
- Page 8 Wall Mount Plate Back of the Monitor NoTE • A non-VEsA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non-standard screws. Wall Mount Plate •...
-
Page 9: Using The Monitor
uSING THE moNITor Displayport Connection Transmits digital video and audio signals from your PC to the monitor. • Illustrations in this manual may differ from the actual product. NoTE Press the joystick button, go to Settings Input, and then select the input option. •... - Page 10 Connecting LaN Connecting aV Devices (34wQ75C,34wQ75X) LaN connection HDmI Connection Connect the router or switch to the monitor. HDMI transmits digital video and audio signals from your AV device to the monitor. NoTE NoTE • • The LAn cable is sold separately.
- Page 11 Connecting peripherals CauTIoN Cautions When using a usB Device uSb Device connection • A usB device with an automatic recognition program installed, or that uses its own driver, may not be recognized. The usB port on the product functions as a usB hub. •...
-
Page 12: User Settings
uSEr SETTINGS NoTE • Your monitor’ s OsD (On screen Display) may differ slightly from that shown in this manual. • When beep Guide is activated, pressing the joystick button will take you to Settings right away. activating the main menu Press the joystick button on the right back of the monitor. - Page 13 main menu features main menu Description Input sets input mode. power off power off Turns off the monitor. Settings Configures the screen settings. Exit Input picture mode sets the picture mode. Exit Exits the main menu. picture mode menu Settings To view the OsD menu, press the joystick button on the right back of the monitor and then enter the Settings.
- Page 14 Quick Settings Settings > Quick Settings Description brightness Adjusts the contrast and brightness of the screen. Contrast Adjusts the volume. Volume NoTE • You can adjust mute / unmute by moving the joystick button to in the Volume menu. The user can adjust it to red, green, or blue by customization. Custom warm sets the screen color to a reddish tone.
- Page 15 Input Settings > Input Description Input List selects the input mode. When automatic input switch is set to on, display will automatically switch to new input when connected. auto Input Switch Enables auto Input Switch. Disables auto Input Switch. Adjusts the aspect ratio of the screen. full wide Displays the video in widescreen, regardless of the video signal input.
- Page 16 picture NoTE • The picture mode that can be set depends on the Input signal. [picture mode on SDr (Non-HDr) signal] Settings > picture Description Custom Allows the user to adjust each element. Vivid Heightens contrast, brightness and sharpness to display vivid images. HDr Effect Optimizes the screen for high dynamic range.
- Page 17 [picture mode on HDr signal] Settings > picture Description Custom Allows the user to adjust each element. Vivid Optimized the screen for HDr vivid colors. Cinema Optimized the screen for HDr video. This mode is optimized for FPs games.It is suitable for very dark FPs games. picture mode This mode is optimized for rTs Game.
- Page 18 Settings > picture Description brightness Adjusts the contrast and brightness of the screen. Contrast Sharpness Adjusts the sharpness of the screen. High Optimizes the screen for crystal clear images. Best for high-definition video or games. Optimizes the screen for comfortable viewing, with images at the middle level between the low and high modes. Best for uCC middle or sD videos.
- Page 19 Settings > picture Description sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use fast. When there is a lot of motion, it is recommended that you use faster. setting to faster may cause image sticking.
- Page 20 Settings > picture Description mode 1, mode 2, The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image mode 3 becomes. Gamma mode 4 If you do not need to adjust the gamma settings, select mode 4. set your own color temperature.
- Page 21 Sound Settings > Sound Description Adjusts the volume level. Volume NoTE • You can adjust mute / unmute by moving the joystick button to▼in the Volume menu. MaxxAudio® by waves, recipient of a Technical GrAMMY Award® is a suite of studio-quality sound tools for a superior listening experience. waves maxxaudio®...
- Page 22 General Settings > General Description Language sets the menu screen to the desired language. uSb Selection select the usB upstream cable connection port to use usB hub of the monitor. Conserve energy by using luminance compensation algorithm. High saves energy using the high-efficiency SmarT ENErGY SaVING feature. saves energy using the low-efficiency SmarT ENErGY SaVING feature.
- Page 23 Settings > General Description You can customise the main menu to access your preferred menu easily. Displays the screens of two input modes on one monitor. user-defined Key picture mode sets the picture mode. KVm Switch select the usB upstream cable connection port to use usB hub of the monitor. This feature disables the configuration and adjustment of menus.
-
Page 24: Troubleshooting
TroubLESHooTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. • Is the power LED on? Check the power cable connection and press the power button. •... - Page 25 Do you see an "unrecognized monitor, plug and play (VESa DDC) monitor found" message? • Have you installed the display driver? Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function.
-
Page 26: Product Specification
proDuCT SpECIfICaTIoN Color Depth 10-bit color is supported. Max resolution 3440 x 1440 @ 60 Hz resolution DP / usB-C / HDMI (2.0) 3440 x 1440 @ 60 Hz recommended resolution HDMI (1.4) 3440 x 1440 @ 50 Hz Power rating 100-240V ~ 50/60 Hz 2.1 A On mode: 48 W Typ. - Page 27 factory Support mode (preset mode, pC) Displayport / uSb-C preset mode Horizontal frequency (kHz) Vertical frequency (Hz) polarity (H/V) remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 66.587 59.934 1720 x 1440 88.739 59.92 3440 x 1440...
- Page 28 HDmI preset mode Horizontal frequency (kHz) Vertical frequency (Hz) polarity (H/V) remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 66.587 59.934 1720 x 1440 88.739 59.92 3440 x 1440 73.631 49.953 3440 x 1440 88.841...
- Page 29 HDmI Timing (Video) factory support mode Horizontal frequency(kHz) Vertical frequency(Hz) remarks (preset mode) 480p 31.5 720p 45.0 1080p 67.5 2160p...
- Page 30 beep Guide menu Location menu Location menu Location Quick settings Input (PBP Off) - Input List - HDMI 2 2 1 2 Input (PBP On) - Input List - sub Input List - 2 1 2 3 DisplayPort Quick settings - Brightness Input (PBP Off) - Input List - DisplayPort 2 1 3 Input (PBP On) - Input List - sub Input List - usB-C...
- Page 31 menu Location menu Location menu Location Picture Picture - Picutre Adjust - Black Level 3 2 5 Picture - Color Adjust - Color Temp - Manual 3 4 2 5 Picture - Picture Mode Picture - Picutre Adjust - Black Level - High 3 2 5 1 Picture - Color Adjust - Color Temp - Manual 3 4 2 5 1 slider...
- Page 32 menu Location menu Location menu Location Picture - Picture reset - Yes 3 5 2 General - Language - Korean 5 1 17 General - Automatic standby - Off 5 5 4 sound General - usB selection General - Input Combaility Version sound - Volume General - usB selection - HDMI 1 5 2 1...
- Page 33 Supplier’s Declaration of Conformity Trade name responsible Party LG Electronics usA, Inc. Address 111 sylvan Avenue, north Building, Englewood Cliffs,nJ 07632 E-mail lg.environmental@lge.com The model and serial number of the product are located on the back and on one side of the product. record them below in case you ever need service.
