PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B

1.37 [34.7]
1.13 [28.6]
.955 [24.26]
A
1 FOR METRIC RING ACCELEROMETER (MODEL M624B01, ETC) USE MOUNTING BOLT
MODEL M081A67, M6 X 1.00-6g X 1.12 [28.5] LONG
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.03
XXX ±.010

ANGLES 2 DEGREES
FILLETS AND RADII
.003 - .005
2
2.08 [52.9]

1.11 [28.2]
DIMENSIONS IN MILLIMETERS
KRM
[ IN BRACKETS ]
TITLE
DECIMALS X ± 0.8
XX ± 0.25

ANGLES 2 DEGREES
FILLETS AND RADII
0.07 - 0.13
2
REV
C REVISED NOTE 1; REVISED TITLE; 2.08 WAS 2.06
ELECTRICAL CONNECTOR
5/8-24 UNEF - 2A
2-PIN (MIL-C-5015)
MOUNTING BOLT
MODEL 081A67
1/4-28 UNF - 2A
X 1.12 [28.5] LONG
(SUPPLIED)
1
DRAWN CHECKED
1/4/18 KRM 1/4/18
OUTLINE DRAWING
RING ACCELEROMETER
1
REVISIONS
DESCRIPTION
SIGNAL/
POWER
A B
ENGINEER
GCD 1/4/18
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE: 1.25X
1
DIN
47631
B
GROUND
A
19620
SHEET 1 OF 1
