Model 3501B122KG
Piezoresistive Accelerometer
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: 716-684-0987
E-mail: info@pcb.com
Web: www.pcb.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PCB Piezotronics 3501B122KG
Summary of Contents for PCB Piezotronics 3501B122KG
- Page 1 Model 3501B122KG Piezoresistive Accelerometer Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 716-684-0001 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
- Page 2 Piezotronics, user servicing or repair is critical test. not recommended and, if attempted, may void the factory warranty. Routine PCB Piezotronics maintains an ISO- maintenance, such as the cleaning of 9001 certified metrology laboratory and electrical connectors, housings, and offers calibration services, which are...
- Page 3 50% of the general contact numbers are: replacement cost returned item(s). PCB will provide a price PCB Piezotronics, Inc. quotation replacement 3425 Walden Ave. recommendation for any item whose Depew, NY14043 USA repair costs would exceed 50% of...
-
Page 4: China Rohs Compliance
PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 汞 镉 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 铅 (Pb) (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接... - Page 5 Component Name Hazardous Substances Lead Mercury Cadmium Chromium VI Polybrominated Polybrominated (Pb) (Hg) (Cd) Compounds Biphenyls Diphenyl (Cr(VI)) (PBB) Ethers (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
- Page 6 3500/3600 Series Piezoresistive Shock Accelerometer Operating Guide Introduction display a slight linear decrease in sensitivity as temperature increases. TZS – Thermal Zero Shift, the change in ZMO due to This Operating Guide contains information that will familiarize the user with the basic operation and installation of temperature.
- Page 7 3500/3600 Series Piezoresistive Shock Accelerometer Operating Guide check the mounting torque after each measurement. It’s performed. These are violent events. Because of the critical nature of these and similar test applications, PCB MEMS DC also recommended that a thread locking adhesive be Accelerometers have been designed and manufactured with the applied to any threads, if applicable.
- Page 8 3500/3600 Series Piezoresistive Shock Accelerometer Operating Guide the shunt resistor are accurately known. Among other sources immediate dynamic instrumentation needs with a Factory of variability, temperature can change the value of the Representative. resistors, and therefore the Shunt Calibration output. The user should be aware that because the sensors are full bridge transducers, all legs are active and will have temperature coefficients typical of piezoresistive sensors (approximately...
- Page 9 Model Number Revision: C PIEZORESISTIVE ACCELEROMETER ECN #: 46956 3501B122KG Performance ENGLISH OPTIONAL VERSIONS Sensitivity(± 50 %)(at 10 VDC excitation) 0.20 mV/g 0.02 mV/(m/s²) Optional versions have identical specifications and accessories as listed for the standard model Sensitivity 0.02 mV/V/g 0.002 mV/V/(m/s²)
- Page 10 REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION .11 [2.8] 5 without the written consent of PCB Piezotronics Inc. RELEASED TO DRAFTING 45768 INTEGRAL CABLE SPECIFICATIONS 3/8 HEX 1 ESD SENSITIVE Ø...
