Kodak EasyShare ZD710 User Manual

Kodak EasyShare ZD710 User Manual

Zoom digital camera
Hide thumbs Also See for EasyShare ZD710:

Advertisement

Installing the software

Attaching the lens cap and strap

www.kodak.com/go/zd710support
Before connecting any cables, install the
software that was included with your camera.
Follow the on-screen instructions.
After installing the software, return to this
Getting Started Guide.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyShare ZD710 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kodak EasyShare ZD710

  • Page 1: Installing The Software

    Installing the software Before connecting any cables, install the software that was included with your camera. Follow the on-screen instructions. After installing the software, return to this Getting Started Guide. Attaching the lens cap and strap www.kodak.com/go/zd710support...
  • Page 2: Loading The Battery

    Loading the battery Kodak lithium digital camera battery CRV3 (non-rechargeable) Kodak Ni-MH rechargeable digital camera battery (KAA2HR) www.kodak.com/go/easysharecenter AA batteries (rechargeable or non-rechargeable)
  • Page 3: Turning On The Camera

    Turning on the camera Setting the language and date/time NOTE: To change the date/time and language in the future, use the Menu button. www.kodak.com/go/zd710support Language: to change. to accept. Date/Time: At the prompt, press OK. to change. for previous/next field.
  • Page 4: Taking A Picture/Video

    Press the Shutter button halfway to focus and set exposure. When the AF/AE indicator turns green, press the Shutter button completely down. Videos Press the Shutter button completely down and release. To stop recording, press the Shutter button again. www.kodak.com/go/easysharecenter...
  • Page 5: Transferring Pictures/Videos

    Play/Pause. 2X, 4X forward 2X, 4X reverse Adjust the volume. Press and hold for 4 seconds to jump to a bookmark Kodak EasyShare printer dock or camera dock (May be sold separately.) For dock compatibility, visit www.kodak.com/go/dockcompatibility. To purchase accessories, visit www.kodak.com/go/zd710accessories.
  • Page 6 • taken pictures • transferred pictures to your computer Keep learning! Finish reading this book, so you can take and share your best pictures! Visit www.kodak.com/go/zd710support and www.kodak.com/go/easysharecenter for: • the extended user’s guide • interactive troubleshooting and repairs • interactive tutorials •...
  • Page 7: Front View

    Front view Low-light assist, Self-timer light Shutter button Flash button Focus (Close-up/Landscape) button Drive (Self-timer/Burst) button Power/Favorites switch Speaker www.kodak.com/go/zd710support Flash Open Flash switch 10 Neck strap post 11 Microphone 12 Lens 13 DC-In (3V) for optional AC adapter...
  • Page 8: Back View

    4 Tripod socket 5 Dock connector 6 LCD 7 Help/Info button 8 EVF (Electronic viewfinder) EVF/LCD button 10 Zoom (Wide Angle/Telephoto) 11 Share button 12 Joystick/OK button 13 Mode dial 14 USB, A/V Out 15 Optional SD card 16 Battery compartment www.kodak.com/go/easysharecenter...
  • Page 9: Doing More With Your Camera

    Turn on the camera. CAUTION: A card can only be inserted one way; forcing it may cause damage. Inserting or removing a card while it is being accessed by the camera may damage pictures, card, or camera. www.kodak.com/go/zd710support...
  • Page 10: Using Optical Zoom

    If you are using no zoom (1X, wide angle), you can be as close as 24 in. (60 cm) to your subject. (For Close-up/Macro mode, see As you zoom in, you need to move further from ■ your subject. www.kodak.com/go/easysharecenter page 12).
  • Page 11: Using The Flash Button

    Zoom position Wide angle Telephoto www.kodak.com/go/zd710support Doing more with your camera Turn on the camera to open the flash. Press the flash button repeatedly to scroll through flash modes. The current flash mode appears on the LCD/EVF.
  • Page 12: Using The Focus Button

    Wide angle: 4.7–27.6 in. (12–70 cm) Telephoto: 3.9–6.9 ft (1.2–2.1 m) Camera uses infinity auto-focus. Auto-focus framing marks are not available in Landscape. The camera focuses when the Shutter button is pressed halfway down. www.kodak.com/go/easysharecenter (see...
  • Page 13: Using The Drive Button

    Press the Shutter button completely down. ■ NOTE: Only the 2- and 10-second options are available in video mode. www.kodak.com/go/zd710support Doing more with your camera Place camera on a tripod or flat surface. In any Still mode, press the Drive button.
  • Page 14: Capture Modes

    Point-and-shoot simplicity when taking pictures under special Scene conditions. High-ISO People in low-light scenes. Digital Image Minimizing the effects of camera shake and subject movement. Stabilization “Stitching” 2 or 3 pictures into 1 panoramic scene. Panorama page 16.) Program, Aperture priority, www.kodak.com/go/easysharecenter...
  • Page 15: Using The Help/Info Button

    Focus Date stamp Mode Album name AF control setting PASM setting Aperture Shutter speed www.kodak.com/go/zd710support Doing more with your camera To turn on/off picture-taking mode status icons, histogram review mode status icons, histogram, and picture/video information any menu Help (Press...
  • Page 16: P, A, S, And M Modes

    ISO speed. Exposure compensation acts as an exposure meter, recommending the proper combination of aperture and shutter speed to produce an acceptable exposure. To prevent camera shake, use a tripod for slow shutter speeds. Press to select settings. to select settings. to select settings. www.kodak.com/go/easysharecenter to select settings.
  • Page 17 If a picture is light, decrease the setting; if it’s dark, increase it. ISO speed—control sensitivity to light. If you can’t use a flash, increase the ISO. 3200 available only at 1.2, 2.1, and 2.2 MP. Higher ISO can produce unwanted “noise.” www.kodak.com/go/zd710support Doing more with your camera PASM Options White—selectable...
  • Page 18: Working With Pictures/Videos

    This feature is only available immediately after you delete a single picture/video. Press Review. View previous/next. Magnify 1X - 8X. View other parts of the picture. Return to 1X. Press Review. View previous/next. Press Delete. Follow the screen prompts. www.kodak.com/go/easysharecenter...
  • Page 19: What The Review Icons Mean

    Email tag Perfect Touch tech. Mode indicator Album Scroll arrows Video length Protected Favorite tag Email tag Mode indicator Album Scroll arrows www.kodak.com/go/zd710support Working with pictures/videos Sound tag Picture number Image storage location Battery level Video number Image storage location...
  • Page 20: Solving Camera Problems

    ■ www.kodak.com/go/zd710support Insert a new or charged battery. If practical, connect the camera to a Kodak 3-volt AC adapter (sold separately), then try again. Confirm that the battery in camera is charged. Turn camera off, then on again. (Lens does not extend in Favorites mode.)
  • Page 21 If the LCD breaks, do not touch the glass or liquid. Contact Kodak customer support. ■ The use of an accessory that is not recommended by Kodak may cause fire, electric shock, or injury. For approved accessories, visit www.kodak.com/go/accessories. ■...
  • Page 22 Warranty service will include all labor as well as any necessary adjustments and/or replacement parts. If Kodak is unable to repair or replace a Product, Kodak will, at its option, refund the purchase price paid for the Product provided the Product has been returned to Kodak along with proof of the purchase price paid.
  • Page 23: Upgrading Your Software And Firmware

    In countries other than the United States and Canada, the terms and conditions of this warranty may be different. Unless a specific Kodak warranty is communicated to the purchaser in writing by a Kodak company, no warranty or liability exists beyond any minimum requirements imposed by law, even though defect, damage, or loss may be by negligence or other act.
  • Page 24: Waste Electrical And Electronic Equipment Labeling

    In Europe: For human/environmental protection, it is your responsibility to dispose of this equipment at a collection facility established for this purpose (separate from municipal waste). For more information, contact your retailer, collection facility, or appropriate local authorities; or visit www.kodak.com/go/recycle. (Product weight: 282 g.) Australian C-Tick N137 Canadian DOC statement DOC Class B Compliance—This Class B digital apparatus complies with Canadian ICES-003.
  • Page 25: China Rohs

    China RoHS Korean Class B ITE Russian GOST-R Eastman Kodak Company Rochester, NY 14650 AIO-40 www.kodak.com/go/zd710support Appendix...
  • Page 26 Appendix Eastman Kodak Company Rochester, New York 14650 © Eastman Kodak Company, 2007 Kodak and EasyShare are trademarks of Eastman Kodak Company. 4J6236_en www.kodak.com/go/easysharecenter...
