Parts:
1,Previous song
2,Volum+
3.Volum –
4,Next song
5,Audio line in jack
6,USB charge port
Initial set up via Bluetooth
1.
Turn on the Bluetooth™ Speaker by pressing up top control panel.
2.
Wait for approximately 20 seconds,the speaker will go into pairing mode and will produce a "beep"tone.The bottom red led light will flash.
3.
Turn on a device such as an ipod,iphone or mp3 device and go to:Setting>General>Bluetooth.Click on the bluetooth GP-508 will then appear on the device.Click on the GP-508. The device is now connected and paired with the speaker.If the device prompts for a pair
code,enter:"0000"
4.
If pairing is not successful within 150seconds,the system will search for the last paired device.To restart the pairing process,turn off the speaker and repeat step 1.If the initial set up connection is succesful,the next time the speaker is turned on,the speaker will
automatically pair to the last device it was connected with.
5.
Touch V+ for 1 second to increase the volume.When maximum volume has been reached, a tone indicator will sound.
6.
Touch V- for 1 second to decrease the volume.When minimal volume has been reached ,a tone indicator will sound.
7.
Touch
for 1 second to listen to the next song.
8.
Touch
for 1 second to listen to the previsous song.
NOTE:
1.
The bluetooth speaker only connects to one device at a time.Turn off the bluetooth speaker in order to pair the device with another bluetooth device.
2.
The maximum transmission between the bluetooth speaker and a device is 10 meters or 32 feet.
3.
Interference may occur during playback when using the bluetooth function near other wireless devices. If playback through bluetooth is problematic,move the bluetooth speaker
and the playback device to a different location,or use the 3.5mm audio cable jack instead of the bluetooth function.
WARNING:
The built-in rechargeable battery is not replaceable.Do not remove or replace battery.Dispose of unit properly.Do not dispose unit in trash or fire.
BLUE TOOTH SPEAKER MANUAL
Charge:
Fully charge the speaker before use.
Connect the speaker to the PC via provided USB cable. It is powered by internal rechargeable battery and it can using the converting cable for charging function by USB
port. When the bottom RED LED flash approximately 15 times, it means the battery is low, please recharge the speaker. The solid RED LED will appear when speaker is
on charged. The RED LED goes out when charge is finished
Advertisement
Summary of Contents for EpiCentre iWorld GP-508
- Page 1 BLUE TOOTH SPEAKER MANUAL Parts: Charge: Fully charge the speaker before use. Connect the speaker to the PC via provided USB cable. It is powered by internal rechargeable battery and it can using the converting cable for charging function by USB port.
- Page 2 Specification Connecting with an audio cable Output:： 3Wx1pcs The bluetooth connection can be switched to a wired connection by plugging in the 3.5mm audio jack. Signal To Noise Ratio: >80dB The volume key function will be disabled in the wired connection mode.Simply unplug the 3.5mm audio jack to Frequency Response: 20Hz-20kHz Distortion:...
- Page 3 FCC Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
