Hiberr YU-E20 User Manual

SPECIFICATIONS

SYSTEM:
① Frequency preparation: PLL
② Frequency range: Optional (60 frequencies for selection )
③ AF Response:80Hz~15Khz(±3dB)
④ Distortion:≤1%
⑤ Operating Temperature Range: -10℃ ~+40℃

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE
*Piece suddenly goes dead
The unit is dead
*No power supply
*Transmitter is not switched ON
No receiption
*Transmitter and receiver donot work though all
LEDs andconnections seem ok
The hand mic is
*2x1.5V battery inserted wrong
not working
*2x1.5V battery is weak
*Input Gain of the Amplifier orMixer very high
Distorted sound
*Gain on the hand mic is toohigh
*Transmission distance between the transmitter
No"RF" signal
andreceiver is very far
on the receiver
*Defective or broken antenna
*Transmitter and receiver have different frequencies
*Two transmitters using the same frequency
Noise / Distortion
interference from other transmitter
*Battery of the transmitter isweak

IMPORTANT NOTICE

·
Please kindly read and keep this manual carefully.
· Take attention of the full items show on the manual.
·
Must cut off the power while cleaning the equipment.
· It is better using the original accessories, such as adapter and cable.
·
While it is thunderstorm weather or don't use the equipment for a long
time, please unplug the receiver from equipment.
·
Do not place the receiver and transmitter near the source of heat, such as
radiator, oven and also keep them away from water.
contact details
WEB：www.hiberr.com
Facebook: https://www.facebook.com/hiberr.mic
E-Mail: service@hiberr.com
RECEIVER :
① Sensitivity: 12dBμv(80dB S/N)
② Sensitivity adjust range: 12~32dBμv
③ Audio output level: 0~0.5V/600Ω
Audio output:0~0.5V/5k
TRANSMITTER :
① RF output power: 11mW (10mW~30mW)
② Spurious rejection:<-50dB
③ Battery: 2*1.5V AA (common)
2*1.2V AA(rechargeable)
①Cartridge: dynamic
SOLUTION
*Check the power supply
*Connect power adapter
*Switch ON the transmitter
*Make sure that the transmitter and receiver are on the same
frequency
*Receiving antennas are not pulled out, extend the antennas
*Reverse the Polarity
*Reverse the battery
*Reduce the gain in the Mixer or Amp and adjust the volume
control on the transmitter
*Reduce the gain in the Hand mic
*Reduce the distance betweentransmitter and receiver
*Check antenna and replace it if necessary
*Make sure the transmitter and receiver are of the same
frequency
*Switch off the other transmitters
*Avoid using two transmitter of the same frequency
*Replace the battery

CLEANING AND MAINTENANCE

·
Do not spill the liquid into the device, otherwise it will
damage the electronic components of the device.
·
Disconnect the power before cleaning
· Clean the device with a soft cloth.
·
No solvent or cleaner is allowed for cleaning.
PROFESSIONAL WIRELESS
MICROPHONE SYSTEM
USER'S MANUAL
YU-E20

OPERATING INSTRUCTIONS

Please read the instruction manual carefully before
operating the appliance and keep the instruction manual properly.
