Summary of Contents for Signcomplex SC-XB10B-2P
- Page 1 L-1122,18-V1.0 Bare Board Rapid Solderless Connector SC-XB10B-2P/SC-XB8B-2P/SC-BB10B-2P/SC-BB8B-2P Wire-to-board Connector SC-XB8-2P SC-XB10-2P Board-to-board Connector SC-BB8-2P SC-BB10-2P...
- Page 2 LED strip won’t be loose and fall off easily. Stable connection makes the electrical performance safer. Dimensions (unit: mm) Wire-to-board Connector Board-to-board Connector SC-XB8B-2P SC-BB8B-2P 11.3 11.3 Wire-to-board Connector Board-to-board Connector SC-XB10B-2P SC-BB10B-2P 11.3 11.3 Wire-to-board Connector with Wires Wire-to-board Connector with Wires SC-XB8B-2P-15CM SC-XB10B-2P-15CM 11.3 11.3 black wire and black wire...
- Page 3 L-1122,18-V1.0 Installation First, if you have a connector of LED strip, please check whether your connector can match with the LED strip or not, such as the width and distance of bonding pad of LED strip, etc. Check whether your power supply is turned off or not, do not operate or install the connector with the power supply As shown on Figure 1, if the LED strip has to be cut for connection, please cut upon the scissors mark.
- Page 4 Protection grade of this connector is IP20, so it needs anti-corrosion environment. This connector is applicable to the flexible LED strip whose LED qty is less than 78/m. Yijia Industrial Park, Fuqian Road, Guanlan Town, LongHua, Shenzhen, Guangdong, China Tel:+86-755-27608650 Fax:+86-755-27608651 www.signcomplex.com sales@signcomplex.com...
