22_____ MHz Transverter, __________ MHz IF, S/N__________
Power Out:
Noise Figure and Gain:
DC Power Requirement:
IF Option:
IF Drive Level Maximum:
Keying Option:
Aux. Connection Output Option:
Antenna Option:
External preamplifier option:
Operational Overview:
The DEM 222-28 is a 222 MHz to 28 MHz transmit and receive converter. It will operate
with most High Frequency transceivers that are available on the market today. The 222-28 has a
linear output power of approximately 25 watts. At full compression, the output power may reach 35
watts, but would be recommended for CW or FM operation only. On the receive side, a GaAs-FET
preamplifier, a high level mixer (+17 dBm Local Oscillator), and a 3 chamber helical filter provide a
sensitive, yet over-load proof front end with superior out of band rejection. The DEM 222-28 has a
built in transmit / receive relay with provisions for external switching so that adding a high power
amplifier to your 222 MHz system is easy. Options have been provided for a key line input of PTT
Low (ground) or PTT High (+Voltage). Auxiliary contacts are included for either transmit or receive
with a common line for many applications. The 28 MHz IF levels are adjustable on both transmit
and receive and have a dynamic range of approximately 25dB. This is very useful for adjusting
your maximum output power and setting the "S" meter level on your IF receiver. IF connections
are via BNC connectors. The control, power, and auxiliary connections are via RCA jacks, and the
222 MHz connectors are BNC, UHF or Type 'N' (users choice). The 222-28 is housed in a 7.4" x
4.7" x 2.2" aluminum die cast enclosure with an external 7" x 4" x 3/4" heat sink to provide cool
operation under any condition.
This transverter, when assembled, has your requested options installed and will be
configured to your transceivers specifications. It is important to fully understand the functions of
your transceiver before interfacing the transverter. Please review your owners manual for any
details regarding transverter operation. If necessary, you may consult us regarding interfacing.
We have not interfaced every transceiver on the market, but could help you in making the correct
decision regarding yours.
/Built/222-28.doc
DEM Part Number 222-28
25 W linear, 35 watts maximum; adjustable
0.8dB nominal, +17dB nominal (25 adjustable IF Attenuator)
12 - 15.5 VDC, 13.8 nominal, 8 amps Maximum
Common
-20dBm
100 mW
PTT - to ground
TX
RX
Common
YES
1
Split
1-10W
Other____________
TTL - Positive Voltage
High
Low
Separate TX & RX
NO
Rev. H 10/11/2005
Open

Advertisement

loading
Need help?

Need help?

Do you have a question about the 222-28 and is the answer not in the manual?

Questions and answers

Summary of Contents for demi 222-28

  • Page 1 BNC connectors. The control, power, and auxiliary connections are via RCA jacks, and the 222 MHz connectors are BNC, UHF or Type 'N' (users choice). The 222-28 is housed in a 7.4" x 4.7" x 2.2" aluminum die cast enclosure with an external 7" x 4" x 3/4" heat sink to provide cool operation under any condition.
  • Page 2 224 MHz or below 222 MHz. 11. To test the transmit section, place your transceiver in the CW mode. It is recommended to test the transverter in the CW mode because most transceivers have carrier level controls in this /Built/222-28.doc Rev. H 10/11/2005...
  • Page 3 NOTE: Leaving Q4 connected to the shared pad will offer some minimal attenuation. If you find this level of attenuation un-acceptable, use solder wick and lift the Drain lead of Q4 up so it is disconnected from the circuit. /Built/222-28.doc Rev. H 10/11/2005...
  • Page 4 Connector Solder lug RG/188 coax from PCB "ANT" PCB MOUNTNG AREA 5. Route the TX cable (old antenna coax) from the antenna position on the PCB to the BNC connector and solder. /Built/222-28.doc Rev. H 10/11/2005...
  • Page 5 Leads flat to trace, 4 places Solder full length of lead, 4 places Some spring back is OK PCB Trace Figure 2 Typical side view of four leaded surface mounted device, lead bending close to body /Built/222-28.doc Rev. H 10/11/2005...
  • Page 6 F2 TOKO 1146A CR4 MPN3404 F4 TOKO 1166 K1 G5V-2 Y1 Crystal 194.000 MHz 5th Overtone HC 18/U CR7 1N4000 Type K2 G6Y IC1 MAV11 PTC-50 Thermistor IC2 MAR3 IC5 RA30H2127M 222-28 Common IF Input Circuit Option /Built/222-28.doc Rev. H 10/11/2005...
  • Page 7 This option is used for common IF input for the 222-28 transverter. There are two versions of this option. It is a pin switch designed for High and Low Power. The Low Power version is used with a transceiver that has a less than 250 mW transverter port. If the transverter port has less than 0 dBm, the transverter will require the TXIF gain stage to be installed.
  • Page 8 All switching functions are controlled by a Signal to Ground or a +1.5-15VDC that is provided by a transceiver on transmit. The transverter is in RX mode during standby. Isolated auxiliary contacts are provided for switching external equipment such as mast mounted pre-amps, power-amps, or T/R switches. /Built/222-28.doc Rev. H 10/11/2005...
  • Page 9 /Built/222-28.doc Rev. H 10/11/2005...
  • Page 10 /Built/222-28.doc Rev. H 10/11/2005...
  • Page 11 /Built/222-28.doc Rev. H 10/11/2005...
