FCC STATEMENT (For customers in USA)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Note:
This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.This
equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15 of the FCC rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such
changes or modifications should be made, you could be required to stop operation of the equipment.
EN-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CyperPix E660P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kobian CyperPix E660P

Summary of Contents for Kobian CyperPix E660P

  • Page 1 FCC STATEMENT (For customers in USA) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Read This First

    This User Manual is a general reference guide for the product. The product and accessories that come with your digital camera may be different from those described in this manual. This is due to the fact that different retailers often specify slightly different product inclusions and accessories to suit their market requirements, customer demographics, and geographical preferences.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Read and understand all Warnings and Cautions before using this product. Warnings If foreign objects or water have entered the camera, turn the power OFF and remove the batteries and the AC power adapter. Continued use in this state might cause fire or electric shock. Consult the store of purchase. If the camera has fallen or its case has been damaged, turn the power OFF and remove the batteries and the AC power adapter.
  • Page 4 Cautions Insert the batteries paying careful attention to the polarity (+ or –) of the terminals. Inserting the batteries with their polarities inverted might cause fire and injury, or damage to the surrounding areas due to the battery rupturing or leaking. Do not fire the flash close to anyone’s eyes.

  • Page 5: Notes On Battery Usage

    Notes on Battery Usage When you use the batteries, carefully read and strictly observe the Safety Instructions and the notes described below: Different battery types and surrounding temperatures may affect the battery performance. Avoid using batteries in extremely cold environments as low temperatures can shorten the battery life and reduce camera performance.

  • Page 6: Table Of Contents

    Contents INTRODUCTION...8 Package Contents ... 9 GETTING TO KNOW YOUR CAMERA...10 Front View... 10 Rear View ... 11 Mode Dial... 12 LCD Monitor Information... 13 PREPARING THE CAMERA...16 Installing the Batteries ... 16 Using the AC Adapter (Optional Accessory)... 17 Inserting and Removing an SD Memory Card (Optional Accessory) ...
  • Page 7 TRANSFERRING FILES FROM YOUR DIGITAL CAMERA TO COMPUTER ... 51 Step 1: Install the USB driver ... 52 Step 2: Connect the digital camera to your computer ... 53 Step 3: Download images or movie clips ... 54 EDITING SOFTWARE INSTALLATION ...55 Installing Photo Explorer ...

  • Page 8: Introduction

    INTRODUCTION Thank you for purchasing the new digital still camera! Equipped with a 6.0 Megapixels CCD sensor, your camera delivers high quality, 2816 x 2112 resolution images. Other features provided by the camera include the following: 6.0 Megapixels A high-resolution CCD sensor provides 6.0 megapixels for high quality images.

  • Page 9: Package Contents

    Carefully unpack your kit box and ensure that you have the following items. In the event that any item is missing or if you find any mismatch or damage, promptly contact your dealer. Common Product Components: Digital Camera User's Manual Software CD-ROM...

  • Page 10: Getting To Know Your Camera

    GETTING TO KNOW YOUR CAMERA Front View 1. Shutter release button 2. Flash 3. Power switch 4. Mode dial 5. Self-timer LED EN-10 6. Microphone 7. PC / AV terminal 8. DC input terminal 9. Lens...

  • Page 11: Rear View

    Rear View 1. LED indicator Zoom in (telephoto) button Zoom out (wide-angle) button Playback button Menu button Delete button Arrow button (Up) Self-timer button Arrow button (Right) Focus button 8. Strap holder Arrow button (Down) Exposure compensation button Arrow button (Left) Flash button button Display button...

  • Page 12: Mode Dial

    Mode Dial You can select from seven shooting modes and setup mode according to shooting conditions to achieve the desired effect. Mode Program Portrait Landscape Sports Night Setup Video Auto EN-12 Description Select this mode to permit the shutter speed and aperture to be set manually. Select this mode to make people stand out with the background out-of-focus.

  • Page 13: Lcd Monitor Information

    LCD Monitor Information Camera Mode 1. Mode indication ] Program Mode ] Portrait Mode ] Landscape Mode ] Sport Mode ] Night Mode ] Setup Mode ] Movie Mode ] Auto Mode 2. Flash mode ] Auto ] Red eye ] Flash on ] Flash off 3.
  • Page 14 Movie Mode 1. Movie mode 2. Flash mode 3. Recordable movie time available 4. Memory status 5. Battery power and AC adapter indicator 6. Focus area 7. Zoom bar Image Playback 1. Playback mode 2. Number of image 3. Memory status 4.
  • Page 15 Movie Playback 1. Playback mode 2. Movie mode 3. Number of movie 4. Memory status 5. Battery power and AC adapter indicator 6. Index number of total number 7. Elapsed time 8. Date 9. Time 10. Play/Pause indicator 100-0001 100-0001 100-0001 00:05 00:05...

  • Page 16: Preparing The Camera

    You can use 2 AA size batteries (alkaline or Ni-MH rechargeable) to power the camera. Make sure that the power of the digital camera is off before inserting or removing the batteries. 1. Make sure the camera is turned off.

  • Page 17: Using The Ac Adapter (Optional Accessory)

    Using the AC Adapter (Optional Accessory) Use of the AC adapter is recommended if you intend to use the LCD monitor for a long time or connect the camera to a PC. 1. Make sure your camera is off. 2. Connect one end of the AC adapter to the camera DC input terminal labeled "DC IN 3V". 3.

  • Page 18: Inserting And Removing An Sd Memory Card (Optional Accessory)

    Inserting and Removing an SD Memory Card (Optional Accessory) The digital camera comes with 11MB of internal memory, allowing you to store captured still images or video clips in the digital camera. Moreover, you can also expand the memory capacity by using an optional SD (Secure Digital) memory card so that you can store more files.

  • Page 19: Attaching The Camera Strap

    Attaching the Camera Strap Attach the strap as shown in the illustration. EN-19...

  • Page 20: Getting Started

    GETTING STARTED Turning the Power On/Off Press the power switch until the digital camera turns on. To turn the power off, press the power switch again. EN-20 Power switch...

  • Page 21: Choosing The Screen Language

    Choosing the Screen Language Follow the steps below to choose the desired language. 1. Rotate the mode dial to the power switch. 2. [Set-up1] is displayed. 3. Use the four-way controller ( ) to select [Language], then press button. 4. Use the four-way controller ( 5.

  • Page 22: Setting The Date And Time

    Setting the Date and Time Follow the steps below to set the date display style, current date and time. 1. Rotate the mode dial to the power switch. 2. [Set-up1] is displayed. 3. Use the four-way controller ( ) to select [Date & Time] and the four-way controller ( button.

  • Page 23: Formatting An Sd Memory Card Or Internal Memory

    Formatting an SD Memory Card or Internal Memory The term “Formatting” means preparing an “SD memory card” to record images; this process is also called “initialization”. This utility formats an SD memory card or the internal memory and erases all stored images and data.

  • Page 24: Using The Lcd Monitor

    Using the LCD Monitor Your camera is equipped with a 2.4” full color TFT LCD monitor to help you compose images, replay recorded images/movie clips or adjust menu settings. The mode icons, text and numbers displayed on the monitor may vary according to the current settings.

  • Page 25: Photography Mode

    PHOTOGRAPHY MODE Shooting Images 1. Rotate the mode dial to camera on by pressing the power switch. 2. Compose the image on the LCD monitor screen so that the main subject is within the focus frame. 3. Press the shutter release button down halfway to focus the image. When you press the shutter release button down halfway, the camera’s Auto Focus feature automatically focuses the image.

  • Page 26: Setting Image Resolution And Quality

    Setting Image Resolution and Quality As you get to know the digital camera, you can set the image resolution (number of vertical and horizontal pixels) and image quality (compression ratio) based on the types of images you want to shoot.These settings affect the number of images that can be stored in the internal memory, or on an SD memory card.

  • Page 27: Using The Zoom Function

    Using the Zoom Function This camera is equipped with 3x optical zoom. The lens moves during the optical zoom photography, allowing you to capture telephoto and wide-angle shots. By using the optical zoom function; images appear closer by pressing the button, or smaller away by pressing the The zoom bar indicates the current level of magnification.

  • Page 28: Using The Flash

    (person) to look at the digital camera or get as close to the digital camera as possible. The flash will always fire regardless of the surrounding brightness.

  • Page 29: Setting Focus

    Setting Focus Images can be captured with the focus determined automatically using auto focus. You may over-ride the auto focus and specify [ ] macro or [ 1. Rotate the mode dial to 2. Press the power switch to turn on the power. 3.

  • Page 30: Capture Mode

    Capture Mode Burst This mode is used for continuous shooting. 3 pictures are taken continuously once the shutter release button is pressed. Secure the camera to a tripod or place it on a stable surface. 1. Rotate the mode dial to 2.

  • Page 31: Auto Bracket

    Auto Bracket In this mode, the camera automatically changes the exposure within a set range to take three shots after you press the shutter release button once. Auto Bracket settings can be combined with exposure compensation settings to extend the adjustment range. 1.

  • Page 32: Self-Timer

    Self-Timer The self-timer can be used in situations such as group shots. When using this option, you should either mount the camera on a tripod (recommended) or rest it on a flat, level surface. 1. Secure the camera to a tripod or place it on a stable surface. 2.
  • Page 33 The table below will help you choose the appropriate self-timer mode: Self-timer mode Description 2 sec. Self-timer The image is captured about 2 seconds after the shutter is pressed. This mode is useful for preventing camera shake. 10 sec. Self-timer The image is captured about 10 seconds after the shutter is pressed.

  • Page 34: Adjusting The Exposure (Ev Compensation)

    Adjusting the Exposure (EV Compensation) You can manually adjust the exposure determined by the digital camera. Use this mode when the proper exposure cannot be obtained, for example, when the contrast (difference between bright and dark areas) between the subject and the background is extremely high. The EV compensation value can be set from -2.0EV to +2.0EV.

  • Page 35: Setting White Balance

    Setting White Balance This feature lets you make adjustments to compensate for different lighting types according to your shooting conditions. 1. Rotate the mode dial to 2. Press the power switch to turn on the power. 3. Press the button. [Mode1] is displayed. 4.

  • Page 36: Using The Mode Dial

    USING THE MODE DIAL Auto Mode [ (Auto) mode is the simplest way which allows you to take still pictures without having to set special functions or manual adjustments. The camera sets the optimal focusing and exposure. 1. Rotate the mode dial to the power switch.

  • Page 37: Portrait Mode

    Portrait Mode [ Select this mode to make people stand out with the background out-of-focus. 1. Rotate the mode dial to the power switch. 2. Compose your subject within the focus frame. 3. Press the shutter release button to capture the image. Landscape Mode [ This mode allows you to take photographs of distant scenery or landscapes.

  • Page 38: Sport Mode

    Sport Mode [ This mode allows you to shoot fast moving objects. 1. Rotate the mode dial to the power switch. 2. Compose your subject within the focus frame. 3. Press the shutter release button to capture the image. Night Mode [ This mode allows you to take photographs of people against a dusk or night-time background.

  • Page 39: Playback Mode - The Basics

    PLAYBACK MODE - THE BASICS Viewing Images You can display the still images one by one. 1. Rotate the mode dial to your camera on by pressing the power switch. 2. Press the button. The last recorded image appears on the LCD monitor screen. Basic information is shown by indicators on the LCD monitor screen.

  • Page 40: Magnifying Images

    Magnifying Images While reviewing your images, you may enlarge a selected portion of an image. This magnification allows you to view fine details. The zoom factor displayed on the screen shows the current magnification ratio. 1. Press the button. The last recorded image appears on the LCD monitor screen. To view the previous image, press the four-way controller ( ).

  • Page 41: Thumbnail Display

    Thumbnail Display This function allows you to view 9 thumbnail images on the LCD monitor screen simultaneously so you may search for a particular image. 1. Press the button. The last recorded image appears on the LCD monitor screen. 2. Press the button once.

  • Page 42: Slideshow Display

    Slideshow Display The slideshow function enables you to play your images back automatically in sequential order. This is very useful and entertaining feature for reviewing recorded images and for presentations. 1. Press the button. The last recorded image appears on the LCD monitor screen. 2.

  • Page 43: Resizing An Image

    Resizing an Image You can change the image size of a captured image to one of the following sizes: 2272 x 1704 pixel, 1600 x 1200 pixel and 640 x 480 pixel. 1. Press the button. The last recorded image appears on the LCD monitor screen. 2.

  • Page 44: Movie Mode

    MOVIE MODE Recording Movie Clips This mode allows you to record movie clips with sound via built-in microphone. 1. Rotate the mode dial to the power switch. 2. Press the shutter release button to start recording. 3. To stop recording, press the shutter release button again. The optical zoom function (3X) can be activated before you start recording the movie clips The digital zoom function can be activated before and during the recording.

  • Page 45: Playing Back Movie Clips

    Playing Back Movie Clips You can play back the recorded movie clips on the LCD monitor screen. However, the sound recorded with movie clips can only be played back on a TV or on a computer. 1. Press the button. 2.

  • Page 46: Playback Mode - Advanced Features

    NTSC/PAL system to match the video output system of the video equipment you are going to connect to the digital camera, then turn off all devices to be connected. 1. Connect one end of the AV cable to the AV terminal of the digital camera.

  • Page 47: Deleting Images/Movie Clips

    Deleting Images/Movie Clips Use this function to delete one or all images/movie clips stored in SD memory card or the internal memory. Please note that the deleted images or movie clips cannot be recovered. Exercise caution before deleting a file. 1.

  • Page 48: Protecting Images/Movie Clips

    Protecting Images/Movie Clips Set the data to read-only to prevent images from being erased by mistake. 1. Press the button. The last recorded image appears on the LCD monitor screen. 2. In the mode, use the four-way controller ( desired images. To view the previous image, press the four-way controller ( ).

  • Page 49: Setting The Dpof

    Setting the DPOF DPOF (Digital Print Order Format) allows you to embed printing information on your SD memory card. By using DPOF, you can select an image to be printed and then specify how many prints or which image you would like.
  • Page 50 4. Use the four-way controller ( press the button. [Quantity]: Allows you to select image quantity (0~10). Use the four-way controller ( [Date]: The date of recording can be printed directly on the images. Select [Yes] or [No] with the four-way controller ( 5.

  • Page 51: Transferring Files From Your Digital Camera To Computer

    TRANSFERRING FILES FROM YOUR DIGITAL CAMERA TO COMPUTER After using USB cable to establish a USB connection between the camera and your computer, you can use your computer to share recorded images or video clips with your family or friends via e-mail or post them on the Web.

  • Page 52: Step 1: Install The Usb Driver

    Follow the on-screen instructions to complete the installation. 3. After the USB driver has been installed, restart your computer. Installation on MAC OS 9.0 For Mac OS 9.0 or higher, the computer will automatically recognize the digital camera and load its own USB drivers. EN-52...

  • Page 53: Step 2: Connect The Digital Camera To Your Computer

    Step 2: Connect the digital camera to your computer 1. Rotate the mode dial to the power switch. 2. Press the four-way controller ( ) to select the [Set-up2] menu, then use the four-way controller ( ) to select [USB Mode].

  • Page 54: Step 3: Download Images Or Movie Clips

    Step 3: Download images or movie clips When the digital camera is turned on and connected to your computer, it is considered to be a disk drive, just like a floppy disk or CD. You can download (transfer) images by copying them from the “Removable disk”...

  • Page 55: Editing Software Installation

    EDITING SOFTWARE INSTALLATION Installing Photo Explorer Ulead Photo Explorer provides a simple and efficient way to transfer, browse, modify and distribute ® Acquire photos, video or sound clips from various digital device types and easily browse or add personal descriptions; make timely modifications; or distribute the media through the medium of your choice: E-mail, Print, Slideshow Presentations.

  • Page 56: Installing Photo Express

    Installing Photo Express ® Ulead Photo Express is complete photo project software for digital images. The step-by-step workflow, program interface, and in-program help assist users in creating exciting photo projects. Acquire digital photos effortlessly from digital cameras or scanners. Organize them conveniently with the Visual Browse mode. Use hundreds of ready-to-use templates such as albums, cards, posters, slideshows, and more.

  • Page 57: Using The Digital Camera As A Pc Camera

    USING THE DIGITAL CAMERA AS A PC CAMERA Your digital camera can act as a PC camera, which allows you to videoconference with business associates, or have a real-time conversation with friends or family. To use the digital camera for videoconferencing, your...

  • Page 58: Step 2: Connect The Digital Camera To Your Computer

    4. Use the four-way controller ( button. 5. Connect your camera and the computer via the supplied USB cable. 6. Position the digital camera steadily on top of your computer or use a tripod. monitor EN-58 and turn your camera on by pressing...

  • Page 59: Step 3: Run Your Application Software (I.e. Windows Netmeeting)

    Step 3: Run your application software (i.e. Windows NetMeeting) To use Windows NetMeeting for videoconferencing: Start Programs Go to program. 2. Click the Start Video button to view live video. 3. Click the Place Call button. 4. Type the e-mail address or the network address of the computer that you are calling. 5.

  • Page 60: Menu Options

    MENU OPTIONS Camera Menu This menu is for the basic settings to be used when capturing still images. Aut uto Auto Image Si Image Size ge Size Quality Quality Quality Retu Return : eturn n : Select : Select : Select : 1.
  • Page 61 In the Mode Item Functional Description Image Size Sets the size of the image that will be captured. Refer to the section in this manual titled "Setting Image Resolution and Quality" (EN-26) for further details. 2816x2112 2272x1704 1600x1200 640x480 Quality Sets the quality (compression rate) at which the image is captured.
  • Page 62 In the , or Mode1 settings Item Functional Description Image Size Refer to the section in this manual titled “Setting Image Resolution and Quality” (EN-26) for further details. Quality Refer to the section in this manual titled “Setting Image Resolution and Quality” (EN-26) for further details.
  • Page 63 Mode2 settings Item Functional Description Metering You can select the metering mode that sets which part of the subject to measure to determine the exposure. Center-weighted: Averages the light metered from the entire frame, but gives greater wieght to the subject matter at the center. Spot: The exposure is determined by the small area in the center of the screen only.
  • Page 64 Mode3 settings Item Functional Description Color Sets the color of the image that will be captured. Full Color Black & White Sepia Sharpness Sets the level of image sharpness. High Medium Saturation To capture an image, your camera offers you three different degrees of color to match with your preference.

  • Page 65: Movie Menu

    Movie Menu This menu is for the basic settings to be used when recording movie clips. Video Vide ideo Color Color Color Digital Zoom Digital Zoom Digital Zoom Return : Retu eturn n : Select : Select : Select : 1.

  • Page 66: Playback Menu

    Playback Menu In the menu, set the settings used for playback. Playback1 Playba Playback1 Playba Playback2 Playback2 Slide Show Slide Show Slide Sh Protect Protec otect DPOF DPOF DPOF Return : Retu eturn n : Select : Select : Select : 1.
  • Page 67 Playback1 Item Functional Description Slide Show You can play back recorded images in order with a selected interval time. This function is useful for checking your images or for presentations, etc. Refer to the section in this manual titled “Slideshow Display” (EN-42) for further details. 3 Sec.
  • Page 68 Economy Copy to Card Allows you to copy your files from the digital camera’s internal memory to an SD memory card. You can only do this if you have an SD memory card installed and some files in internal memory.

  • Page 69: Setup Menu

    Setup Menu This feature allows you to set up the default settings by preference for using your camera. Set-up1 Set-up1 Set-up1 Set-up2 Set-up2 Set-up2 Set-up3 Set-up3 Set-up3 Format Format Beeper Beeper Beeper Louder Louder Louder Date & Time Date & Tim te &...
  • Page 70 Set-up1 settings Item Functional Description Format Erases all images and reformats the SD memory card loaded in your camera. Protected images are also erased. SD memory card cannot be formatted if it is write-protected. Refer to the section in this manual titled “Formatting an SD Memory Card or Internal Memory”...
  • Page 71 Set-up2 settings Item Functional Description USB Mode Selects to choose one of the following modes for further settings. PC / PC CAM Sets video output of the camera for matching the video output system of the equipment that you are going to connect to the camera. PAL / NTSC This sets the brightness of the LCD monitor screen.
  • Page 72 0001. If you want to reset the file number, be sure that no images are recorded in the internal memory or the SD memory card. Set to Default Returns all basic settings to the digital camera's default settings. The time setting will not be reset. Version This displays the current firmware version of the camera.

  • Page 73: Connecting The Digital Camera To Other Devices

    CONNECTING THE DIGITAL CAMERA TO OTHER DEVICES AV Cable USB Cable SD Card Reader SD Card Reader PCMCIA Adapter Notebook Computer Printer EN-73...

  • Page 74: Specifications

    SPECIFICATIONS Item Description Image Sensor Effective pixels 6.0 Mega pixels Image size Still image: 2816x 2112, 2272 x 1704, 1600 x 1200, 640 x 480 Movie clip: 320 x 240 Image quality Still image: Fine / Normal / Economy Movie image: QVGA Recording media Approx.
  • Page 75 Item Description Self-timer 10 sec self-timer, 2 sec self-timer, 10+2 sec self-timer Exposure compensation -2.0EV~ +2.0EV (in 1/3 EV increments) White balance Auto, Daylight, Cloudy, Tungsten, Fluorescent Auto, 64, 100, 200 Interface DC input terminal, PC/AV terminal Power 2 x AA (alkaline or Ni-MH rechargeable) batteries AC-DC Adapter (3V/2.5A) (Optional) Dimension Approx.

  • Page 76: Appendix

    APPENDIX Troubleshooting Guide Symptom Possible causes Power does not turn * The batteries have run out. * The batteries are not oriented correctly. * The battery cover is not closed properly. * The AC adapter (optional) is Camera suddenly * The function of [Auto Shut Down] in the powers down.
  • Page 77 Symptom Possible causes Flash does not fire. * Flash off is selected in flash mode. * 10+2 sec. Self-timer is selected in self-timer mode. * The [Capture Mode] is set to [Burst] or [AEB]. * The camera is in the Continuous shooting is * The capacity of the built-in memory or not possible.
