Summary of Contents for BIOTREND KOALA
- Page 1 QUICK USER GUIDE BABY MONITOR Model: KOALA Manufactured by: Apexar Technologies S.A. Uruguay 2887 - Victoria Buenos Aires - Argentina...
-
Page 2: Indications Of Use
KOALA User Manual 1. Indications of use The physiological baby monitor Koala is a device that allows to perceive sounds close to the baby and has a base-sensor dedicated to the prevention and warning of episodes where the physiological indications SpO2, hearth rate, temperature and body position leave the expected values . - Page 3 3. Precautions The Koala is an accessory and is not a substitute of adult supervision. In case of premature babies, with supplemental oxygen or with a health condition, please consult with the professional to indicate if the Koala is the right device for your child.
-
Page 4: Content Of The Box
It also has an ambient microphone to listen to what happens in your baby's environment. Also, It is the element that will produce the wireless charge of the Koala sensor (QI) when placing it in the sector for that purpose. - Page 5 USB CABLE: The base is powered through a USB cable like that for cell phones and must remain powered for the system to work. KOALA SENSOR: It is the device that senses the different parameters through the BIOTREND SAT technology widely tested in medical environments with its Biotrend BPO250 pulse oximeters.
- Page 6 GRIP FABRIC: It is a synthetic fabric accessory, totally antiallergenic and widely used in medical products in contact with the skin that ensures the maintenance of the sensor in a safe position in order to avoid false alarms due to changes in the position of it.
- Page 7 Instructions for use 6.1. Before placing on the baby Before using the Koala for the first time, proceed to charge the device and connect it to the WIFI network. Put the sensor in the base in the existing depression for this purpose.
- Page 8 • The first time you charge it, there will be a synchronization between the sensor and the base. During this process of approximately 30 seconds, the indicator ring of the base will blink in white indicating the action. Once completed this will light up in blue color slowly rising and falling its intensity.
- Page 9 6.2.1. Important details in the sensor position • Functional scheme of the sensor • The emitter and receiver should be as aligned as possible. A better alignment implies a more reliable measurement. • Do not place the sensors on the toes. This will generate bad readings.
- Page 10 • Try to keep the electronics as close to the skin as possible. Adjust with the grip fabric gently. • If the base does not turn green on its indicator ring once the sensor is placed and it is flashing yellow, verify that the sensor is positioned correctly.
- Page 11 6.3. Alarms and visual and acoustic indicators The physiological baby monitor Koala consists of a medical device (Sensor + Base) and a smartphone application that adds listening functionality of the baby environment. The base is the element that charges the battery of the sensor wirelessly and establishes the communication with it when it is placed on the baby's foot.
-
Page 12: Physiological Alarms
6.3.1. Physiological Alarms EVENT DESCRIPTION LIGHT ACOUSTIC INDICATOR INDICATOR Sensor placed correctly, pulse can not be measured for 20 seconds and no 10 tones that on / off movement is detected repeat every 10 PULSE LOST 2 times per during that time. seconds second. - Page 13 6.3.2. Technical Failure Indicators EVENT DESCRIPTION VISUAL AUDIO INDICATOR INDICATOR The sensor is correctly positioned and happens to be not positioned or YELLOW 1 tone each 30 SENSOR incorrectly positioned. It constantly on seconds FAILURE requires attention, not necessarily immediately. The sensor is not communicating with the base - Connection...
- Page 14 6.3.3. Indications EVENT DESCRIPTION LIGHT AUDIO INDICATOR INDICATOR The synchronization SUCCESSFUL between the base and BIRUBIP SYNCHRONIZA the sensor is completed TION (Paired) The sensor is correctly BLUE - slowly low placed in the base for SENSOR and rise its —...
- Page 15 No shutdown is required for adding the application. Download the Biotrend Koala APP from Play Store or App Store and install it in your smartphone Android or IOS. 6.5. Associate the KOALA base with WIFI at...
- Page 16 6.5.1. Router with wps Wi-Fi Protected Setup™ (WPS) is a feature that lets you easily connect WPS-supported client devices, such as wireless printers, to your router wirelessly. The koala Base has available this kind of configuration. Push the wps button in your router •...
- Page 17 • You will be asked for a password, by default it is 1234. This key protects your base from being accessed by another user with the Koala application. • Go to menu/networks. Add by touching + the wifi of the house.
- Page 18 6.7. Basic operation with the application Once the base and the application are connected, it allows parents to listen to all the ambient sounds in their child's environment by touching the play button. When the sensor is not connected, the application is automatically placed as a baby monitor, playing the ambient sounds at the request of the parents.
- Page 19 at the app for the case in which the parents are at a greater distance where they do not perceive the indications of the base. More information about the application can be consulted in its help section. 6.8. Sensor turning on and off •...
-
Page 20: Technical Specifications
Technical specifications 7.1. Base Power supply USB adaptor 100 - 240 V, 50-60 hz Dimensions (HxWxD) 68 x 68 x 16 mm Weight 300 g Connectivity Bluetooth v4.2 BLE WIFI - 802.11 b/g/n WEP/WPA/WPA2 Indications Visuals and auditories 7.2. Sensor Power supply Rechargeable battery - QI (wireless charging)
