Gas Char Broilers
Improper installation, adjustment, alteration, service or Maintenance can cause property
damage, injury or death. Read the Installation, Operating and Maintenance Instructions
thoroughly before installing or servicing this equipment.
This equipment has been engineered to provide you with year round dependable service
when used according to the instructions in this manual and standard commercial kitchen
practices.
Instructions must be posted in a prominent location. All safety precautions must be
taken in the event the user smells gas. Safety information can be obtained from your
local gas supplier.
(914) 576-0200 Phone
(914) 576-0605 Fax
Get user manuals:
See SafeManuals.com
INSTALLATION AND OPERATING INSTRUCTIONS
Model:
INTENDED FOR OTHER THAN HOUSEHOLD USE
RETAIN THIS MANUAL FOR FUTURE REFERENCE
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
or liquids in the vicinity of this or any other appliance.
R
BAKERS PRIDE OVEN CO., INC
New Rochelle, NY 10801
SGBR and GG
WARNING
CERTIFIED
R
30 Pine Street
®
P/N U4010A
(800) 431-2745 US & Canada
www.bakerspride.com WebAddress
5/97
Advertisement
Table of Contents
Related Manuals for Bakers Pride SGBR
Summary of Contents for Bakers Pride SGBR
- Page 1 Safety information can be obtained from your local gas supplier. ® CERTIFIED P/N U4010A 5/97 BAKERS PRIDE OVEN CO., INC 30 Pine Street New Rochelle, NY 10801 (914) 576-0200 Phone (800) 431-2745 US & Canada (914) 576-0605 Fax www.bakerspride.com WebAddress...
- Page 2 TABLE OF CONTENTS 1. INSTALLATION INSTRUCTIONS SECTION PAGE " 2. OPERATING INSTRUCTIONS Get user manuals: See SafeManuals.com...
-
Page 3: Installation Instructions
1. INSTALLATION INSTRUCTIONS 1. INSTALLATION: USA, In Canada, 2. ACCEPTABLE CLEARANCES: MINIMUM CLEARANCE FROM NON-COMBUSTIBLE"CONSTRUCTION: 3. GAS CONNECTION: Get user manuals: See SafeManuals.com... - Page 4 For units using Propane Gas, supply lines with less than 1/2D (12.7 mm) inside diameter should not be used, even for a small unit. NOTE: Be sure plug is installed in the connection not being used. Be sure to cap whichever side is not connected. NOTE: 4.
-
Page 5: Assembly Procedures
NOTE: 5. ASSEMBLY PROCEDURES: a. Bottom Grates: b. Glo-Stones: c. Top Grates: d. Griddle Plates Get user manuals: See SafeManuals.com... -
Page 6: Lighting Procedure
CAUTION: THE PILOT BURNERS WILL STAY LIT UNTIL THE MAIN GAS SUPPLY TO THE UNIT IS TURNED "OFF". WAIT AT LEAST 5 MINUTES BEFORE ATTEMPTING TO RELIGHT. b. SGBR Series If any burner fails to light, turn the valve to "OFF", wait five minutes and repeat the above procedure. -
Page 7: Additional Installation Requirements
NOTE: CAUTION: 7. ADDITIONAL INSTALLATION REQUIREMENTS: 8. INSTALLATION WITH CASTERS: Get user manuals: See SafeManuals.com... -
Page 8: Maintenance
II. OPERATING INSTRUCTIONS 1. LIGHTING PROCEDURE: 2. BROILING PROCEDURE: BROILER TOP GRATES MUST BE HOT ENOUGH TO MAKE BLACK CHAR-MARKS WHEN STARTING TO BROIL. 3. MAINTENANCE: (a) SERVICE: Get user manuals: See SafeManuals.com... - Page 9 (b) CARE AND CLEANING OF TOP GRATES: Under no circumstances should the grates be placed in a dishwasher. Soap, water, or any detergent should never be used on the cast iron grates. NOTE: The following procedures should only be done when the unit is cold. “DO NOT” attempt steps c, d, or e when the unit is hot.
- Page 10 4. ILLUSTRATIONS FIG. 1 SGBR SERIES AIR MIXER CAP AND PILOT BURNERS ORIFICE HOLDER PILOT BURNERS VALVE HANDLE BURNER VALVE BURNER EXTENSION (STRAIGHT) AIR MIXER PILOT FLAME ADJUSTING SCREW MANIFOLD ORIFICE BURNER VALVE MANIFOLD VALVE EXTENSION (CURVED) FIG. 3 GG SERIES FIG.
- Page 11 FIG. 5 GG SERIES FIG. 6 SGBR SERIES Get user manuals: See SafeManuals.com...
- Page 12 BAKERS PRIDE Factory Authorized Service Center. This Warranty is in lieu of all other warranties, expressed or implied, and all other obligations or liabilities on the manufacturers part. BAKERS PRIDE shall in no event be liable for any special, indirect or consequential damages, or in any event for damages in excess of the purchase price of the unit. The repair or replacement of proven defective parts shall constitute a fulfillment of all obligations under the terms of this warranty.
