DEZCTOP DA-CUPSHR-BK1 User Manual

C PU H O LDE R
U SE R G U I DE
I NS TALLATI ON ON
DEZCT OP BIFR OST DB160 /D160 DESK
02 -
Fa st en the cup ho l der o nt o
tw o of side- mounting po r ts un d er
th e tab le t op by M6 Cros s Screw s .
I NS TALLATI ON DE SKS
01 -
The cup holder is fo ld ab l e
a n d re quire s a cl earanc e fo r
t h e f ront hol der. Choo s e a n
a p p rop r iat e posit ion under th e
t a b l e t op f or inst all ation .
C OMP ONENT LIS T
A
Cup Holder with Coaster x 1
STO R E D
U SIN G
B
M6 Cross Screws x 2
C
M3.5 Self-Tapping Screw x 2
ST O RE D
USIN G
INSTALLATION ON
DEZCTOP BIFROST DB 160 /D16 0 D ESK
01 -
Th ere are 3 re s erved s ide- mo un tin g ports both at le ft an d righ t side
u nder th e ta bl et op. Ch o ose favo rit e s ide for in sta ll atio n .
A
B
Si d e- Mo u n ti n g Po r t s
