- Page 1 S3 Quick Start Guide Getting started with S3 For Support reach us at P: +1 (512) 817 0702 E: support@siera.ai Hours: M-F 9 am - 6 pm US CST...
- Page 2 Outline Introduction 3. Using S3 1.1. What is S3? 3.1 Setup 1.2. Components 3.2 Operator Login 3.3 Inspection Installation 3.4 End Shift 2.1. Gateway 3.5 Alerts & Warnings 2.2. Sensor 3.7 Customizing S3 2.3. Power Harness 3.6 Special Considerations 2.4.
- Page 3 INTRODUCTION What is S3? SIERA.AI Safety System S3 is a machine vision solution that constantly monitors for any obstructions around the vehicle. When an object or person comes within the defined distance an audible and visual alarm will notify the operator.
- Page 4 The gateway is the main part of the The sensor is the “eyes” of the The power harness provides power to S3 System. It holds the brains of the system. It detects objects and the entire S3 system. It connects the system.
- Page 5 The touchscreen should be easily accessible to the driver, while being out of the way of any moving components and remaining inside the vehicle. The gateway is mounted to the vehicle using a clamp and adjustment arm seen above. © SIERA.AI 2021...
- Page 6 (seen below). calibration. Warning: The sensor should be mounted in a safe spot that is out of the way of any moving parts and protected from external impact. © SIERA.AI 2021...
- Page 7 Upon start up, the system will calibrate at any angle that is set. If the camera’s orientation is changed drastically during operation, it will need to be restarted to properly recalibrate. © SIERA.AI 2021...
-
Page 8: Power Harness
Warning: The system is only compatible with lifts that have either a 12 or 24 volt battery. For 36V-60V batteries please use the provided DC-DC converter. For higher than 60V batteries please contact us for support. © SIERA.AI 2021... - Page 9 Be sure to twist lock the connectors in place and ensure the harnessing is out of the way of any moving parts. Sensor Connections © SIERA.AI 2021...
- Page 10 QR code. After login, select the worksite and asset for this device. Note: If you do not have a SIERA.AI account, please contact your customer USER QR CODE success representative.
-
Page 11: Operator Login
USING S3 Operator Login ENTER THE PIN To Login Enter Your PIN (or you can Scan User QR Code) Click Login (optional) SCAN USER QR CODE © SIERA.AI 2021... - Page 12 (Not Applicable) Once the inspection is completed successfully. You can drive the vehicle. Warning: S3 has a 90 second boot up time. It may take a brief moment for the system to detect objects after completing the inspection. © SIERA.AI 2021...
- Page 13 USING S3 End Shift Tap End Shift to Logout “End Shift” On ending the shift, the screen will go back to the ‘start-shift’ screen. The next user can now login and begin their shift. Note: Once the user completes their shift, they must click on the ‘End Shift’...
- Page 14 USING S3 Alerts & Warnings The sensor will show a different visual warning for pedestrians or objects. The default settings will warn drivers of objects within 750mm and pedestrians within 2000mm. OBSTACLE ALERT PEDESTRIAN ALERT © SIERA.AI 2021...
- Page 15 USING S3 Customizing S3 S3 Settings Tab To Change S3 Settings: Click System Settings Click S3 Settings Change camera detection zone settings for each camera CLICK HERE TO READ ARTICLE ON HOW TO CHANGE CAMERA SETTINGS System Settings Tab © SIERA.AI 2021...
-
Page 16: Special Considerations
USING S3 Special Considerations Lighting The system will not work in outdoor daylight. The system may be impacted if strong daylight is introduced indoors. Water & Dust The components shall not be sprayed down with water nor left outdoors. The system can handle moderately dusty environments.
