Custom Dynamics ProGLOW PG-575-B PG-575-C Installation Instructions

We thank you for purchasing the Custom Dynamics® 5.75" ProGLOW™ LED headlamp! Our products utilize
the latest technology and high quality components to ensure you the most reliable service. We offer one of the
best warranty programs in the industry and we back our products with excellent customer support, if you have
questions before or during installation of this product please call Custom Dynamics® at 1(800) 382-1388.
Part Number: PG-575-B PG-575-C
Package Contents:
- 5.75" ProGLOW™ LED Headlamp (1)
- Instructions
Fits:
2022-earlier Harley-Davidson® XL Sportster models,
2015-2021 XG Street Models, and 2017-Earlier Dyna models
(except Switchback). Fits most 2017-Earlier Softail models
with 5.75" OEM headlamp buckets including Softail Custom
(FXSTC), Cross Bones (FLSTSB), Deuce (FXSTD), Deuce
CVO™ (FXSTDSE), Springer (FXSTS), Heritage Springer
(FLSTS), and Springer Classic (FLSTSC). Also Fits 2013-
2014 Breakout CVO™ (FXSBSE) and 2016-2017 Pro Street
Breakout CVO™ (FXSE).
Note: Requires ProGLOW™ Bluetooth Controller (sold sepa-
rately) and ProGLOW™ App download for control of color
changing halo.
ATTENTION
Please read all Information below before Installation
Important: Due to the increased light output from this unit, it is recommended
you take the vehicle to a dealer to have the headlamp properly adjusted. Weight
and tire pressure can affect the position of the light.
Warning: To prevent possible electrical shock, disconnect the negative battery
terminal before installing this product.
1
Questions? Call us at: 1 (800) 382-1388
Custom Dynamics® 5.75" ProGLOW™
LED Headlamp
Installation Instructions
Installation:
1. Disconnect the vehicle battery negative [ - ] terminal.
2. Review detailed service manual for instructions on re-
placing factory headlamp.
3. Remove the factory headlamp trim ring and headlamp
from the headlamp bucket.
4. Drill a 5/8" hole in the back of the headlight bucket.
5. Route the ProGLOW™ wiring harness through the hole
in the headlamp bucket and install the grommet.
6. Connect the 5.75" LED headlamp to the existing factory
H4 plug.
7. Install headlamp and trim ring on the headlamp bucket.
8. Connect the ProGLOW™ wiring harness to Channel 1
of the ProGLOW™ Bluetooth Controller. Note: If the
Brake Signal Sync is turned on in the App, The Chan-
nel 1 Override will need to be turned ON as shown in
Photo1.
9. Secure all wiring harnesses to prevent them from be-
coming pinched or damaged.
10. Re-connect vehicle battery negative [ - ] terminal.
11. Test high and low beam functions of headlamp.
Low Beam is "ON" - High Beam is "OFF".
High Beam is "ON" - Both Low and High Beam are "ON".
11. If the Brake Signal Sync is turned on in the App, test
the Brake Sync Channel 1 Override to ensure the
Headlamp halo does not turn Red when the Brake is
applied.
12. Properly Aim the headlamp for maximum performance.
