FP Mailing Solutions SP1360 Quick Start Manual

www.fp-usa.com

SP1360 Laser Printer

Quick Start Guide

Guide to install the HCF and HCC on SP Series of printers.

Step 1 -

Remove Lid and top foam of Packaging

Step 2 -

Tilt the HCF/HCC out of the packaging and Remove plastic Wrap from equipment.

Step 3 -

Remove all blue packaging material holding down the media guides and

protecting the equipment.

Step 4 -

Located in the base of the HCF/HCC is the accessories box.

Page 1

Table of Contents

Need help?

Do you have a question about the SP1360 and is the answer not in the manual?

Page 1 Tilt the HCF/HCC out of the packaging and Remove plastic Wrap from equipment. Step 3 - Remove all blue packaging material holding down the media guides and protecting the equipment. Step 4 - Located in the base of the HCF/HCC is the accessories box. © 2022 FP Mailing Solutions Page 1...
Page 2 E clip located on the non operators side of the tray, circled in yellow Step 8 - Adjust the Leveling casters on the HCF until the arrows on the feeders depth standoffs are in the green zone of the feeder height guide decals. © 2022 FP Mailing Solutions Page 2...
Page 3 Step 11 - Give Attention to the brass hold down limiter on the registration board. It should be screwed down till it touches the hold down but not applying pressure to the metal strap. © 2022 FP Mailing Solutions Page 3...
Page 4 If it is pulling doubles you need to adjust tighter or adjust looser if the media is not feeding at all. © 2022 FP Mailing Solutions Page 4...
Page 5 Attach the Media Stop to the end of the conveyor with the two thumb screws already attached to the HCC Step 17 - Roll conveyor to the output of printer and set the conveyor speed setting to the standard 3 setting. Installation is Complete © 2022 FP Mailing Solutions Page 5...
