Duinotech XC4631 User Manual

Raspberry pi 3.5in touchscreen with stylus & enclosure
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Raspberry Pi 3.5in Touchscreen with Stylus & Enclosure
Perfect for prototyping or a setting up a portable machine, the 3.5in touchscreen LCD display
requires minimal setup. Includes a handy stylus and protective case.

Specifications

LCD Type
LCD Interface
Touch Screen Type
Touch Screen Controller
Colours
Backlight
Resolution
What's Included
1 x LCD Touchscreen
1x Stylus
1x Enclosure

Essential Accessories

XC9001 – Raspberry Pi 3B+

Installation

To setup the screen, the drivers will need to be downloaded & installed using the following
commands in their respective order. You can either use the HDMI out on the Raspberry Pi or SSH for
the setup process.
git clone https://github.com/jaycar-electronics/XC4631
cd XC4631/XC4631
sudo chmod +x LCD35-show
sudo ./LCD35-show
Distributed by: TechBrands by Electus Distribution Pty. Ltd. 320 Victoria Rd, Rydalmere NSW 2116 Australia Ph: 1300 738 555
Int'l: +61 2 8832 3200
Fax: 1300 738 500
www.techbrands.com
Made in China
XC4631
User Manual
TFT
SPI
Resistive
XPT2046
65536
LED
480 x 320 Pixel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XC4631 and is the answer not in the manual?

Questions and answers

Summary of Contents for Duinotech XC4631

  • Page 1 To setup the screen, the drivers will need to be downloaded & installed using the following commands in their respective order. You can either use the HDMI out on the Raspberry Pi or SSH for the setup process. git clone https://github.com/jaycar-electronics/XC4631 cd XC4631/XC4631 sudo chmod +x LCD35-show sudo ./LCD35-show...
  • Page 2 Step 1 Use the screws provided to attach the base plate firstly, to the Raspberry Pi. There are 4 such points.
  • Page 3 Step 2 The sides lock into each other, and start first with the any side except side with cut-out for connectors. We will add this in the next step. And then build the other sides.
  • Page 4 Step 3 Now add the side with cut-out for Pi connectors, and be careful to watch the display cable if you have already installed the display. Suggested approach is to install the screen as last step.
  • Page 5 Step 4 As a last step, install the screen on the Pi board, and aligning with the GPIO connector Final Build :...
