- Page 1 Instructions Guide Broad Band Accelerator (BBA) 3.0 Calculator Use Guide Document No. 520R710001E Revision No. A04 Feb 2016...
-
Page 2: About
VBA 3.0 LP ER Actelis BBA Flash tool (PN 503RG4080) can be optionally used for diagnosis and troubleshooting of BBA installations. Page 2 March 2016 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED... -
Page 3: Preface Material
BBA Single and Dual Slot Enclosure, cards and modules, accessories kits, this manual or any related materials. Actelis Networks reserves the right to revise this publication from time to time and to make changes in the content hereof without obligation to notify any person of such revisions or changes. - Page 4 Internet: Visit the Actelis Networks World Wide Web site at http://www.actelis.com • Email: techsupport@actelis.com • for technical support. Customer support: Contact Actelis Networks Customer Support directly at one of the following • numbers: • Belgium: (0) 800 71180 • Denmark:...
-
Page 5: Table Of Contents
Copyright, Patents, Warranties and Disclaimers ............3 HOW TO USE THE DATA ..................6 GENERAL VIEW....................6 INSTRUCTIONS ....................7 Contacts......................14 BBA 3.0 Calculator Instructions v1.5 Page 5 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED... -
Page 6: How To Use The Data
Actelis website. 2 GENERAL VIEW General Setting EWL Sum Pane Comment Pane Environmental Data Output Pane Copper loop Data Operational Pane Page 6 March 2016 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED... -
Page 7: Instructions
Optional EWL pane and Comment panes, if required can be enabled for additional • information and input area (by default these areas are omitted). BBA 3.0 Calculator Instructions v1.5 Page 7 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED... - Page 8 Current DSL link performance for Downstream and Upstream. Using “Current info“ the calculator can offer a higher level of accuracy in predicting the performance with the BBA Page 8 March 2016 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED...
- Page 9 Range: Range can be provided per segment in either kft or km (based on the unit • selected at the top of the general settings and applicable for all settings). BBA 3.0 Calculator Instructions v1.5 Page 9 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED...
- Page 10 • Calculation results will be provided with the error, as shown on the example below: An Error message would be presented Page 10 March 2016 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED...
- Page 11 If the user entered ‘current performance’ rates (and it is within the expected range) the current performance as entered by the user would be presented. BBA 3.0 Calculator Instructions v1.5 Page 11 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED...
- Page 12 The Left Y-axis represents the DS rate and the Right Y-axis represents the US rate. DS Y axis US Y axis Page 12 March 2016 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED...
- Page 13 Generate Report button to save HTML report in PDF format BBA 3.0 Calculator Instructions v1.5 Page 13 Proprietary & Confidential Property of Actelis Networks. Copyright ©2016 Actelis Networks®, Inc. ALL RIGHTS RESERVED...
-
Page 14: Contacts
Visit the Actelis Networks web site at www.actelis.com E-mail techsupport@actelis.com Customer Support Contact Actelis Networks Customer Support directly at one of the following numbers: Belgium: (0) 800 71180 • Denmark: 80 887 771 •...
