- Page 1 GSZ67...
- Page 2 1) Read these instructions. 2) Keep these instructions. 3) Read all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
- Page 3 FCC Warning Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 4 Note: It is very important to use a top quality RJ45 8/8 crimper tool. We strongly suggest using a cat 5 / RJ45 electronic tester to verify the wire conductors.
- Page 6 Note: While most speaker manufacturers follow industry convention of using red terminals for positive connections and black terminals for negative, some manufacturers may vary from this configuration. To ensure proper phase connections, and optimal performance, consult the identification plate on our speaker terminals, or the speaker’s manual to verify polarity.
- Page 9 Note: It is very important to use a top quality RJ45 8/8 crimper tool. We strongly suggest using a cat 5 / RJ45 electronic tester to verify the wire conductors. future use brown future use white/brown Infrared orange ground white/blue +12 vdc blue future use white/orange SDA green...
- Page 11 1. Room or zone keypad identification. Now that the system has been installed and powered up it is time to let the amplifier and keypads know which rooms are which. Go to the first keypad connected to room #1. (Keypad is connected to KEY1 and speakers are connected to SPEAKERS 1).
- Page 12 Each keypad must be programmed individually and it will save the label names even if the keypad is disconnected from the systems. The MR164 keypad labels can be programmed offsite if desired. Note: All of the MR164 keypads in this system have to be programmed with the same labels and in the same source order.
- Page 13 Press the UP or DOWN buttons next to the INPUT buttons to set the bass level. When the correct level is displayed press the INPUT button to confirm this choice. The LCD display then displays Press the UP or DOWN buttons next to the INPUT buttons to set the treble level. When the correct level is displayed press the INPUT button to confirm this choice.
