- Page 1 Model M3484 Industrial Line Noise Filter Module Customer Reference Manual ● ● Web: www.bonitron.com Tel: 615-244-2825 Email: info@bonitron.com...
- Page 2 Bonitron has seen thousands of products engineered since 1962 and welcomes custom applications. With engineering, production, and testing all in the same facility, Bonitron is able to ensure its products are of the utmost quality and ready to be applied to your application.
- Page 3 RIVE PTIONS In 1975, Bonitron began working with AC inverter drive specialists at synthetic fiber plants to develop speed control systems that could be interfaced with their plant process computers. Ever since, Bonitron has developed AC drive options that solve application issues associated with modern AC variable frequency drives and aid in reducing drive faults.
-
Page 4: Table Of Contents
Figure 8-2: 600W 3-Phase Line Filter ....................... 12 9. D ......................13 IMENSIONAL UTLINES Figure 9-1: M3484 NEMA 3R (F16) Enclosure Dimensions ................13 Figure 9-2: M3484 NEMA 12 (J21) 600 Watt Enclosure Dimensions............14 Figure 9-3: M3484 NEMA 12 (J21) 1200 Watt Enclosure Dimensions............15... -
Page 5: Preface
COPE OF ANUAL This manual is a user’s guide for the model M3484 industrial line noise filter module. It will provide the user with the necessary information to successfully install, integrate, and use the M3484 module in a variable speed AC drive system. -
Page 6: Safety Precautions
Model M3484 AFETY RECAUTIONS W AR N I N G ! H I G H V O L T A G E S M A Y B E P R E S E N T N E V E R A T T E M P T T O O P E R A T E T H I S P R O D U C T W I T H T H E E N C L O S U R E C O V E R R E M O V E D ... -
Page 7: Overview
User’s Manual VERVIEW Bonitron's model M3484 line filters are designed to be used in applications where power electronic devices experience problems from line harmonics, capacitor switching transients and DC drive notching. Typically, devices with these problems have over voltage faults. Usually, the problems are more severe when the devices are in a standby or lightly loaded mode. -
Page 8: General Specifications
Indicates if unit is off line due to thermal overload Thermal Overload: Disconnects from line at 160F heatsink temp UMBER REAKDOWN Figure 5-1: Example of M3484 Part Number Breakdown M3484D3 H 06 AS E O D E L Y S T E M... -
Page 9: Power Dissipation
User’s Manual OWER ISSIPATION The power dissipation capability is indicated by a numerical code. Table 5-2: Power Dissipation Capability DISSIPATION CODE (Watts) 600 W 1200 W RANCH APACITANCE The branch capacitance is indicated by an alpha-numeric code. Table 5-3: Branch Capacitance BRANCH CAPACITANCE CODE 50 uF... -
Page 10: Model Ratings
Model M3484 ODEL ATINGS NPUT OWER RANCH KVAR AT ODEL UMBER 60 H OLTS ISSIPATION APACITANCE M3484D3-L06C50-J21 230 VAC 600 W 50 µF 3 kvar 30 A M3484D3-L06C50-F16 230 VAC 600 W 50 µF 3 kvar 30 A M3484D3-L12C50-J21 230 VAC 1200 W 50 µF... -
Page 11: Wiring Diagrams
User’s Manual IRING IAGRAMS Figure 8-1: 1200W 3-Phase Line Filter... - Page 12 Model M3484 Figure 8-2: 600W 3-Phase Line Filter...
-
Page 13: Dimensional Outlines
User’s Manual IMENSIONAL UTLINES Figure 9-1: M3484 NEMA 3R (F16) Enclosure Dimensions... - Page 14 Model M3484 Figure 9-2: M3484 NEMA 12 (J21) 600 Watt Enclosure Dimensions...
- Page 15 User’s Manual Figure 9-3: M3484 NEMA 12 (J21) 1200 Watt Enclosure Dimensions...
- Page 16 D3484_CMAN_VALL_01a 08/09/2016 521 Fairground Court ● Nashville, TN 37211 ● USA Tel: (615) 244-2825 ● Fax: (615) 244-2833 ● Web: www.bonitron.com ● Email: info@bonitron.com...
