ROBO RB-EXTGE-102H User Manual

Gigabit poe extender ip52 outdoor rated
Hide thumbs
1
2

Advertisement

Table of Contents

Maximum Distance Reach for Power Sources

Multiple PoE Extenders can be connected every 100 meters to obtain
greater distances. The actual figures depend on operating conditions.
The range mentioned is for cables 24 AWG or heavier Cat-5e or Cat-6
cable except where specified.
Examples for medium power PoE Devices (that are PoE Class 2, or
require under 6 watts)
PoE Source
PoE switch
15W mid-span
(802.3af, output
(802.3af, output
voltage 50V)
voltage 50V)
Maximum Distances
300m
300m
Examples for full power PoE Devices (that are PoE Class 0 or 3, or
require under 12 watts)
PoE Source
PoE switch
15W mid-span
(802.3af, output
(802.3af, output
voltage 50V)
voltage 50V)
Maximum Distances
200m
200m
Examples for PoE+ Devices (that are PoE Class 4, under 22 watts or
802.3at compliant)
PoE Source
PoE switch
15W mid-span
(802.3af, output
(802.3af, output
voltage 50V)
voltage 50V)
Maximum Distances
Not applicable
Not applicable
RB-EXTGE-102H
Gigabit Power-over-Ethernet Extender
PoE+ switch
30W mid-span
(802.3at, output
(802.3at, output
voltage 50V)
voltage 50V)
400m
400m
PoE+ switch
30W mid-span
(802.3at, output
(802.3at, output
voltage 50V)
voltage 50V)
300m
300m
PoE+ switch
30W mid-span
(802.3at, output
(802.3at, output
voltage 50V)
voltage 50V)
200m
200m
4
Gigabit PoE Extender
IP52 outdoor rated
RB-EXTGE-102H
www.robofiber.com
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RB-EXTGE-102H and is the answer not in the manual?

Questions and answers

Summary of Contents for ROBO RB-EXTGE-102H

  • Page 1 RB-EXTGE-102H Gigabit Power-over-Ethernet Extender Maximum Distance Reach for Power Sources Gigabit PoE Extender Multiple PoE Extenders can be connected every 100 meters to obtain greater distances. The actual figures depend on operating conditions. The range mentioned is for cables 24 AWG or heavier Cat-5e or Cat-6 IP52 outdoor rated cable except where specified.
  • Page 2 185mm x 85mm x 40mm both Cat-5e or Cat-6 cables. Mounting Wall or shelf With the RB-EXTGE-102H PoE Extender, PDs (such as IP Security Cameras, Environmental Conditions Operating Ambient Temperature: -20 to 55℃ Operating Humidity: Maximum 90%, Non- wireless access points) can be installed at greater distances. By...
