Summary of Contents for Pasdole WCS200
- Page 1 MODEL WCS200 15/16" Crown Stapler IMPORTANT! OPERATING MANUAL AND DO NOT DESTROY SCHEMATIC It is the customer’s responsibility to have all operators and service personnel read and understand this manual. © 2018 Illinois Tool Works Inc. 515552-1 7/18...
- Page 2 Paslode WCS200 16G Wide Crown Stapler 515800 All parts sold as single items unless described as a set etc., or forms part of an assembly (multiple items defined within a box). A part with no item number is only available in an assembly.
- Page 3 PARTS LEGEND PASLODE WCS200 16G STAPLER 515800 720478 1 Bolt UH 720420 1 Trigger, Sequential (Grey) FW050120B-10 1 Washer, Flat 515735 1 Bumper 720408 1 Cover, Exhaust 515739 NP Seal, Driver 2 Washer, Wave 720482 919017 1 O-Ring (RPLS 720461) ...
