Halco Lighting Technologies warrants its LED in-ground light fixtures to be free from defects in
material and workmanship, under normal use, conditions and service, from the date of purchase
and warrants its products as follows:
Norcross, Georgia
© 2020 Halco Lighting Technologies. All rights reserved. ProLED
All registered and trademarked brands and names are the property of their respective companies. JJ16607. REV. 050420
JJ16607_Halco_ProLEDPoolNichelessLight_16 pages_self .indd 1
JJ16607_Halco_ProLEDPoolNichelessLight_16 pages_self .indd 1
®
is a trademark of and manufactured by Halco Lighting Technologies.
®
®
Halco ProLED
Nicheless LED
®
Pool & Spa Light
RGB
IMPORTANT SAFETY INSTRUCTIONS
READ, FOLLOW AND SAVE THESE INSTRUCTIONS
TECHNICAL SUPPORT
Halco ProLED
Pool Customer Service at:
®
800.374.1927
Installation and
Operation Guide
RGB-W
WHITE
5/21/20 5:02 PM
5/21/20 5:02 PM
Advertisement
Table of Contents
Related Manuals for Halco ProLED FLCN
Summary of Contents for Halco ProLED FLCN
- Page 1 Installation and Operation Guide ® Halco Lighting Technologies warrants its LED in-ground light fixtures to be free from defects in Halco ProLED Nicheless LED ® material and workmanship, under normal use, conditions and service, from the date of purchase and warrants its products as follows: Pool &...
-
Page 2: Table Of Contents
® Nicheless LED Lights ................5 - Preparing the Light Fixture for Installation ....................5 - Installing the Light Fixture ...........................6 Wiring Options for Controlling Halco ProLED Nicheless LED Lights ..........7 ® - Wire Gauge and Length ............................8 - Wiring to a Switch..............................9 - 12VAC Installation ..............................9... -
Page 3: Important Safety Precautions And Warnings
Read Important Safety Precautions and Instructions. Before beginning any electrical wiring, Before installing this product, read and follow all warning notices and instructions be sure to read and carefully follow ALL Safety Instructions. Installation of the Halco ProLED accompanying this product. Failure to follow warning notices and instructions may result Nicheless Light should be performed by a qualified professional electrician or pool serviceman. -
Page 4: Installation Of The Halco Proled Nicheless Led Lights
INSTALLATION OF THE HALCO PROLED ® 12 VAC Class 2 Transformer or Junction Box. NICHELESS LED LIGHT 48” min. Check local city and state for other j-box requirements. Use the chart below to determine the appropriate minimum required pipe length for your installation. -
Page 5: Wiring Options For Controlling Halco Proled
RISK OF ELECTRIC SHOCK OR ELECTROCUTION. should not exceed 150 ft... in length. This includes the primary run from the Which could result in serious injury or death. The Halco ProLED® Nicheless LED Lights are only Junction Box (J-Box). available for 12VAC power. For supply connection, use only an isolating low voltage power supply with Multiple Halco ProLED ®... -
Page 6: Wiring To A Switch
Color Lock (13) and Return (14) feature which allows you to “lock” the light on a Line Black Black color shown during an active light show and can return to the last locked color effect. Halco 120 volts to 12VAC Neutral White... - Page 7 ® 8. BLUE: Solid Deep Blue switch off/on as many times needed to match the desired solid color’s specified number. Example: If you are on (6) SUNSET and want to display (11) Halco ProLED ® White, 9. GREEN: Solid Deep Green...
- Page 8 *If during the first twelve (12) months of the warranty period, the LED Module fails to operate that the correct wire gauge is being used due to a defect in material or workmanship, Halco will, at its option, repair or replace fixture between the transformer and the j-box.
