16oz Laserable Pint Glass- For use on the Flux Beamo
16OZ LASERABLE PINT GLASS – Flux Beamo Laser Cutter & Engraver / HOBBY Laser
Engraving/Cutting
SSPGMB | SSPGWH | SSPGBL | SSPGBU | SSPGOR | SSPGPK | SSPGRD | SSPGSE
GENERAL LASER ENGRAVING PROCESS
Recommended Equipment & Accessories
• Flux Beamo Desktop Laser Cutter & Engraver with rotary attachment, or HOBBY CO2 Laser Engraver
• Hobby Laser cutter & engraver with rotary attachment if available
• Clean Towel
• Isopropyl Alcohol
• Kitchen Degreaser Cleaner
Sept-22
Desktop Laser Cutter & Engraver
Advertisement
Table of Contents
Summary of Contents for Johnson Plastics Plus SSPGMB
- Page 1 Desktop Laser Cutter & Engraver 16OZ LASERABLE PINT GLASS – Flux Beamo Laser Cutter & Engraver / HOBBY Laser Engraving/Cutting SSPGMB | SSPGWH | SSPGBL | SSPGBU | SSPGOR | SSPGPK | SSPGRD | SSPGSE GENERAL LASER ENGRAVING PROCESS Recommended Equipment & Accessories •...
- Page 2 Recommended Settings- Flux Beamo Laser Engraving with Rotary Attachment 30W laser Laser Power 25-30% Laser Speed 205 mm/s Resolution (DPI/PPI) 500 (High) Recommended Settings- HOBBY Laser Engraving 30-40W lasers Laser Power 25-30% Laser Speed 65-75% Resolution (DPI/PPI) 500-600 Flux Beamo Laser Engraving Instructions •...
- Page 3 • After cutting out the elevation spacer disk for the 16oz Laserable Pint Glass, the rotary extension may be installed. o For instructions on installing the Rotary Extension for Flux Beamo, see the Tech Docs/Downloads tab of the Rotary Extension for Flux Beamo product page, found on JPPlus.com. Using the Rotary Extension for Flux Beamo •...
- Page 4 • Use the roller adjustment knob on the rotary attachment to adjust the spacing of the rollers, so that the bottom edge of the mouth of the pint glass is approximately 0.34”-0.36” above the floor of the rotary attachment. o Tip: Stacking 3 pieces of 1/8” thick material together and placing under the mouth of the pint glass can be used as an approximate gauge for setting the optimal roller position.
- Page 5 • Move the laser head over to the pint glass and position in directly above the highest point of the side of the pint glass. • Rotate the clear acrylic focus tool to the downward position and loosen the laser focus set screw to adjust the focus of the laser head to the highest point on the pint glass side.
- Page 6 • Move the laser head to the right to ensure that the side of the pint glass is still in focus towards the bottom of the glass. • When finished, tighten the set screw to lock the focus position. Rotate the acrylic focus tool back to the upward position.
- Page 7 General HOBBY Laser Engraving Instructions/Flux Beamo Engraving Instructions WITHOUT the rotary attachment • Place the pint glass onto the laser bed and align to the zero point on the laser bed. o For best results, utilize a jig to help hold the pint glass level and in place during engraving. o Flux Beamo: Position the pint glass on the laser bed.
- Page 8 Templates and Images • Visit jpplus.com to find the product page for this item. The product template may be found under the Tech Docs and Downloads area of the page. To order more of this product, see similar products and much more, please visit jpplus.com. For additional product support and troubleshooting, please contact JPPlus Advanced Support Team: •...
