ROOM 707-709, JINDU MANSION, NO.277 WUXING RD. SHANGHAI,200030,CHINA
上海市吴兴路 277 号锦都大厦 707-709
Index
Brief Introduction
Technical Feature
Environment Requirements
Model Number
Technical data and Specification
RS232 Communication Interface
Wire Connection and Operation
Caution during operation
Installation Structure Drawing
I.
Brief Introduction
SU90 serial products are hand swipe operated magnetic card reading machine with RS232
interface, adopting high integrated magnetic card decoding chip. They have small electricity
consumption and strong interference resistance. They comply with ISO-7811、7812 magnetic card
decoding standard completely. It can read card bi-directionally, free to choose data with or without
enter key and has intelligent lights to alert if card data is read correctly. Exquisite magnetic
installation structure makes card reading more stable and reliable, which is our patented
technology. Reasonable product design makes products small and compact.
II. Technical Feature
Bi-direction card reading, high capacity program design, high card reading ability. Can
free to choose enter key between data of each track. Can customize tract starting character.
3-Dimensional magnetic head design makes magnetic head contact well with cards, and
ensures cards to have least abrasion.
Adopting arm suspension type magnetic head assembly method enables machine with
soft elasticity and good hand feel. Elasticity will not change in 10,000,000 times, which
greatly increases life span of magnetic head.
Installing magnetic head in the magnetic head box makes track position of magnetic
SU90 RS232 Interface Magnetic card reader
Shanghai Huayuan Smart Information Technology Co., Ltd
上 海 华 苑 斯 码 特 信 息 技 术 有 限 公 司
TEL: 86 21 64458052
FAX:86 21 64671155
Advertisement
Table of Contents
Summary of Contents for HUAYUAN SU90 Series
- Page 1 Shanghai Huayuan Smart Information Technology Co., Ltd 上 海 华 苑 斯 码 特 信 息 技 术 有 限 公 司 ROOM 707-709, JINDU MANSION, NO.277 WUXING RD. SHANGHAI,200030,CHINA 上海市吴兴路 277 号锦都大厦 707-709 TEL: 86 21 64458052 FAX:86 21 64671155...
-
Page 2: Environment Requirements
head more precise to ensure success card reading rate, and appearance of product looks more beautiful. Specific integrated circuits guarantee AMP 15% of the card can work properly. Dual-track static current of the whole machine is below 4mA/5V.Strong interference resistance. Precise electric circuit disposition can read high magnetic card at 4000Oe completely. -
Page 3: Rs232 Communication Interface
Model No. Length（mm） Width(mm) Height(mm) Weight（g） SU90 130g Subject Specification Track standard Comply with ISO7811 Decoding method F2F (FM) Starting character Track 1“%” Track 2“？” Track 3“+” Track 1 79 Track 2 40 Track 3 107 Card reading Data bit Characters (7-bit) Characters(5-bit) characters(5-bit) -
Page 4: Caution During Operation
Track 3 start character：＋ End character：？ Enter key is end character of the whole data packet. VII Wire Connection and Operation Wire connection refers to the below details information:. 1)Power connector, set the interface to the PC's keyboard interface (power DC5V) 2)Indicator: card swiping succeeds Light display data is being uploaded (If data is in uploading process, you must wait for data transfer is completed and then swipe card) - Page 5 VIIII Installation Structure Drawing SU90 series installation structure drawing...
