- Page 1 Atecpool Inox AISI 316 Stainless Steel Filter Instruction Manual Atecpool Zodiac Stainless Steel AISI 316 Filter Atecpool Classic Stainless Steel AISI 316 Filter atecpool.com...
- Page 2 Filter should be flushing when the it working pressure over 1.3kg/cm T he cleaning process is a reverse operation, reverse operation through the filter in the water, Drainage the dirty material into the sewer. atecpool.com...
- Page 3 1.Filters will be placed on the clean and flat ground; 2.Filter be fixed in the right location; 3.For the side mounted pool filter, it should assemble the valve handle. To sure the right connection for the valve and filter. atecpool.com...
- Page 4 T hen it would be cleaned by bellow methods: T he valve handle will turn to “backwash” and then turn on the valve. Turn on the water pump and keep working for 2 minutes. T he dirty substance will drain into the sewage through the backwash. atecpool.com...
- Page 5 B ecause the pump suction is large. used pump to pumping water, it must keep the enough water in the hair collector and whole sewage. B efore the waste operate, it must make sure the skimmer valve and clean valve in the closed status . atecpool.com...
- Page 6 “filtration “. T his setting will make sure the water in filter will drain into the sewage directly. C losed ---------------------------------------------------------------------------- It is stopped the water from filter to pump. In the meantime, the operation is opened the hair collector. atecpool.com...
- Page 7 Forbid to clean the filter cover with any chemical solvent. Otherwise, It will damage filter performance. R eplace the accessories which it is broken. Please make a necessary sand backwash depending on the instruction. A nd suggest to replace the sand each 2-3year just depend on your water quality. atecpool.com...
- Page 8 L ack of chlorine (water is it is filtering Increase chlorine green) Check leaking of hair Air in the water pump collector and suction pipe Pressure gauge Intense fluctuation。 Pump is in semi absorbing Check the inlet pipe status state. -10- atecpool.com...
- Page 9 Forbid to clean the filter cover with any chemical solvent. Otherwise, It will damage filter performance. It is not necessary to tight the nut too much after all the equipment connected. Avoid to destroy some PV C accessories . -11- atecpool.com...
- Page 10 M ulitway Valve set and pipeline Normal Filtration 4-Por ts Valve model 1 & 4 Open , 2 & 3 Closed B ackwash R ecirculate 2 & 3 Open , 1 & 4 Closed 3 & 4 Open , 1 & 2 Closed -12- atecpool.com...
- Page 11 5-Por ts Valve model B ackwash Normal Filtration 1 & 5 Open , 2 /3 /4Closed 2 & 4 Open , 1/3 /5Closed Flushing R ecirculate 4 & 5 Open , 1/2 /3Closed 1 & 3 Open , 2/4 /5Closed atecpool.com...
- Page 12 T he Coarse sand of bottom must be cover the bottom water distributor over 100mm. T he sand volume should be 70%-85% of the sand volume. Side mounted sand filter sand volume can’ t be cover the top water distributor. -14- atecpool.com...
