Summary of Contents for Vantron MOB-WBT-56
- Page 1 User’s Manual Product Name: Module Model Name: MOB-WBT-56 Hardware Manual Rev 2.1 2021/03/01 Chengdu Vantron Technology Co., Ltd.
-
Page 2: Revision Record
Revision record Rev. Date Change Description Editor Initial Version XJ.WU 2021-02-01... -
Page 3: Product Description
MOB-WBT-56 WiFi 11ac + Bluetooth V5.0 Product Description The device is Module, model name is MOB-WBT-56, Features ： • IEEE 802.11a/b/g/n/ac dual-band radio with virtual-simultaneous dual-band operation • Single-stream spatial multiplexing up to 433.3 Mbps data rate. • Supports 20, 40, 80 MHz channels with optional SGI(256 QAM modulation) •... -
Page 4: Front View
Front view Back view... -
Page 5: General Specification
General Specification ： Model name MOB-WBT-56 Product Support WI-FI/Bluetooth function Description 1Tx/1Rx 802.11ac/a/b/g/n WIFI+BT 5.0 Dimension L*W*H:12*12*1.5mm WIFI interface SDIO v2.0/v3.0 BT interface UART/PCM Operating -30℃ to 85℃ temperature Storage -40℃ to 125℃ temperature Humidity Operating humidity less than85% Non-condensing... - Page 6 Wi-Fi RF Specification 2.4GHz RF Specification ：...
- Page 7 Support 802.11b,802.11g,802.11n (20MHz) 5GHz RF Specification ： Support 802.11a,802.11n (20MHz,40MHz),802.11ac (20MHz,40MHz,80MHz)
-
Page 8: General Statements
General Statements 1. Antenna List: Antenna type: PIFA Antenna Connector Type: USS RFI BT/2.4GWIFI Antenna Gain: 2.66dBi 5GWIFI Antenna Gain: 5.04dBi Antenna impedance: 50 (Ω) Frequency range: 2400-2500MHz/5150-5850MHz 2. Any change of antenna type is not allowed. The module only used PIFA antenna. - Page 9 and users, and the transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed.
- Page 10 IC Warning This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 11 Requirement per KDB996369 D03 2.2 List of applicable FCC rules List the FCC rules that are applicable to the modular transmitter. These are the rules that specifically establish the bands of operation, the power, spurious emissions, and operating fundamental frequencies. DO NOT list compliance to unintentional-radiator rules (Part 15 Subpart B) since that is not a condition of a module grant that is extended to a host manufacturer.
- Page 12 following aspects: layout of trace design, parts list (BOM), antenna, connectors, and isolation requirements. a) Information that includes permitted variances (e.g., trace boundary limits, thickness, length, width, shape(s), dielectric constant, and impedance as applicable for each type of antenna); b) Each design shall be considered a different type (e.g., antenna length in multiple(s) of frequency, the wavelength, and antenna shape (traces in phase) can affect antenna gain and must be considered);...
- Page 13 the integration instructions shall inform the installer that unique antenna connector must be used on the Part 15 authorized transmitters used in the host product. The module manufacturers shall provide a list of acceptable unique connectors. Explanation: The EUT has a PIFA antenna, and the antenna used in the antenna is a replaceable connection antenna.
