INSTRUCTION MANUAL
TM
DIGIVAC
Model 2L760
Digital Vacuum Gauge
YOU MUST READ THIS MANUAL BEFORE USE
Readings from 1 – 760 Torr
1-1013 mbar
NOTE: The DigiVac Model 2L760 has been discontinued. However, we are able to service, calibrate and/or repair
existing Models in the market at this time. If you require a replacement gauge, we recommend the StrataVac
775i see web page
here
that has added features and benefits compared to this model.
TM
The DIGIVAC
Company
1020 Campus Drive
Morganville NJ 07751
www.DIGIVAC.com
(732) 765-0900
(732) 765-1800 FAX
sales@digivac.com
Advertisement
Table of Contents
Related Manuals for DigiVac 2L760
Summary of Contents for DigiVac 2L760
- Page 1 Readings from 1 – 760 Torr 1-1013 mbar NOTE: The DigiVac Model 2L760 has been discontinued. However, we are able to service, calibrate and/or repair existing Models in the market at this time. If you require a replacement gauge, we recommend the StrataVac...
-
Page 2: Table Of Contents
1.0 Description and Principle of Operation. 2.0 Construction. 3.0 Unpacking and Inspection. 4.0 Installation. 5.0 Operation. 6.0 Servicing and Calibration. 7.0 Notes on Calibration. 8.0 Understanding Microns, Torr, and Absolute Pressure. 9.0 Accessories and Modifications. 10.0 Terms & Conditions. DIGIVAC 2L760 Instruction Manual Page 2... -
Page 3: Description And Principle Of Operation
This result is an output voltage which is linearized, temperature compensated, scaled and amplified. The voltage is displayed on the DIGIVAC 760 as 0 to 760 Torr or 0 to 1013 mbar. The instrument features large, bright LEDs visible from a distance with a hard, vinyl clad metal enclosure. The straight forward design yields a low power instrument, that is simple to build and simple to operate. -
Page 4: Operation
The RS232 connection can be made to a PLC or computer via a male DB9 cable connection to the female jack on the DIGIVAC. The DIGIVAC acts as a DCE, so a straight serial connection is appropriate. Please use the supplied 5V AC adapter with your instrument. This adapter provides clean short protected power to protect and insure accuracy of the internal circuitry. - Page 5 Your 2L760 should be set by default with the IP address 192.168.0.200. Surf over to http://192.168.0.200 (or whatever your IP address was set to) and say “yes” to security screens authorizing a DIGIVAC applet to run in your browser. You should see a screen that looks like:...
- Page 6 Feel free to connect to the IP address:10001 with HyperTerminal, putty or your favorite communication tool to communicate directly with the device. To use the 2L760 web terminal capability, highlight Display ►Terminal DIGIVAC 2L760 Instruction Manual Page 6...
- Page 7 Press return or enter to submit the query or change the set point. Note that while the web terminal is open, the main 2L760 screen will not update. If at any time the web terminal or the main 2L760 applet window becomes unresponsive, close the.
-
Page 8: Notes On Calibration
8.0 UNDERSTANDING TORR. The 2L760 and many similar instruments are calibrated in microns or "millitorr." Microns are not really a measure of vacuum at all, but rather of absolute pressure. It will be recalled that the pressure of the atmosphere is 14.696 or approximately 14.7 pounds per square inch at sea level. -
Page 9: Accessories And Modifications
COMPATIBILITY WITH OTHER GAUGE TUBES. On special order, DIGIVAC Instruments can be provided to use with most other vacuum gauge tubes. AC and DC excitation are available. Gauges have been provided for Hastings, Varian, Thermionics, Veeco, VRC, and Fredericks gauge tubes. - Page 10 EXCLUSIVE OBLIGATION: The DIGIVAC product you are purchasing has been designed for a specific use within a set of suitable operating conditions, as set forth in its User Manual, or as indicated otherwise by DIGIVAC. Any use of the DIGIVAC Product for any purpose or under any conditions, other than those specified, shall render any limited warranty void, and shall expressly invalidate any liability of DIGIVAC for damages as a result of such misuse.
