lynx System Developers MYLAPS Quick Start Manual

MYLAPS BibTag Decoder
FinishLynx LapTime Integration QSG

Introduction

The following guide will walk you through the configuration of your MYLAPS BibTag decoder, to allow the
integration of laptime data into FinishLynx. If at any point you need additional help, please contact Technical
Support: support@finishlynx.com.

REQUIREMENTS

1. MYLAPS BibTag Decoder.
2. Ethernet cable (not included) connected to the Timing & Scoring/FinishLynx PC.
a. Alternative (advanced) - cloud (CCNet) connection:
i. MYLAPS CCNet account – send email request to
ii. SIM card with data plan – for example, from

Basic Configuration

1. Connect the BibTag decoder to AC power.
2. Turn on the BibTag decoder (press the red power button).
3. Use the Select and Scroll
4. Navigate to Communication > Network and set:
a. Automatic = OFF
b. IP Address = 192.168.0.151 (IP of decoder must be on the same subnet as FinishLynx PC)
5. Navigate to General > Clock and set:
a. Time Zone = your time zone
b. Daylight Savings = ON/OFF
6. Connect the BibTag decoder to your EasyMat or SideAntennas.
7. Connect the BibTag decoder to the FinishLynx network switch. The BibTag decoder is now ready to be added
in Timing & Scoring.

Alternative (Advanced) Configuration

1. Install the SIM card in the MYLAPS GPS Modem – follow the instructions in the
2. Turn on the BibTag decoder (press the red power button).
3. Use the Select and Scroll
4. Navigate to Communication > Server Communication and select GMS.
www.facebook.com/finishlynx
Quick Start Guide (v1.00)
buttons to navigate the menus.
buttons to navigate the menus.
L S
YNX YSTEM
info.americas@mylaps.com
hologram.io
BibTag Timing System Manual
D , I
EVELOPERS NC
www.finishlynx.com
.
