Operating Manual
including installation and assembly instructions
for incomplete machines as per Machinery Directive 2006/42/EC
Clamping- block
Sliding- clamp
08/ 2010 Printet in Germany subjekt to alteration
BA_2200_EN_0810
Type:
8.2202.xxxx
8.2203.xxxx
8.2204.xxxx
8.2205.xxxx
Hilma-Römheld GmbH
Schützenstraße 74
57271 Hilchenbach
Tel: 02733/281-0
Fax: 02733/281-169
E-Mail: info@hilma.de
www.hilma.de
1/7
Advertisement
Table of Contents
Summary of Contents for Römheld 8.2202 Series
- Page 1 Operating Manual including installation and assembly instructions for incomplete machines as per Machinery Directive 2006/42/EC Clamping- block Type: 8.2202.xxxx Sliding- clamp 8.2203.xxxx 8.2204.xxxx 8.2205.xxxx Hilma-Römheld GmbH Schützenstraße 74 57271 Hilchenbach Tel: 02733/281-0 Fax: 02733/281-169 E-Mail: info@hilma.de www.hilma.de 08/ 2010 Printet in Germany subjekt to alteration BA_2200_EN_0810...
- Page 2 O P E R A T I N G M A N U A L Table of contents General information. safety information and manufacturer's declaration General Field of application Operating characteristics Temperatures Important safety information Manufacturer's declaration Design and function Clamping block type 8.220x.1301 Sliding Clamp type 8.220x.2x50...
- Page 3 O P E R A T I N G M A N U A L -Keep hands and tools away from the clamping range when operating the hollow piston cylinders. Attention: Before putting the hollow piston cylinders into operation, the operator must be fully trained. Young people less than 16 years old are not allowed to operate the clamps.
- Page 4 O P E R A T I N G M A N U A L Clamping bars Clamping force depending on type 19 -78 kN Total stroke depending on type 6 - 12 mm Operating pressure 400 bar Clamping stroke depending on clamping edge design Max.
- Page 5 O P E R A T I N G M A N U A L movements must be sufficiently long (t>3s), in order to allow all functions to run smoothly. Depending on the design of the hydraulic system of the machine (pipe cross sections, hose lengths, pump position and delivery, etc.) the time may vary.
- Page 6 O P E R A T I N G M A N U A L When ordering spare parts, please indicate the type number engraved on the cylinder, the number and the designation of the component which are specified in the spare parts lists. Sparepartlist Clamping block 2200- Indication Housing...
- Page 7 O P E R A T I N G M A N U A L Declaration of incorporation as per Machinery Directive EC-RL 2006/42/EC dated June 9, 2006. Hilma- Römheld Schützenstrasse 74 57271 Hilchenbach, declare, that the incomplete machine and its variants: Clamping block, Sliding clamp Type 8.2202.xxxx 8.2203.xxxx...
