HORNER HE959CNX116 Manual

OCS-I/O - CSCAN COMMUNICATION BASE
2 Flexible Inputs (Digital/Analog), 2 Digital Outputs,
TECHNICAL SPECIFICATIONS
1.1 General Specifications
Required Power (Steady State)
Required Power (Inrush)
Primary Power Range
Flex Inputs (Digital or Analog)
Digital Outputs per Module
Analog Inputs
Analog Outputs
Relative Humidity
Port Wiring
(Analog Inputs and Digital I/O)
Operating Air Temp
Storage Temp
Weight
Dimensions
Certifications
(UL/CE)
1.2 Connectivity
CAN Protocols
1.3 Universal Analog Inputs
Number of Channels
Input Ranges
0-10V / 0-20mA / 4-20mA /
0-60mV
%AI Full Scale
Thermocouple
Converter Type
RTD
RTD Excitation Current
Indianapolis, USA | Cork, Ireland | Calgary, Canada | Bangalore, India | Oakleigh, Australia | Tianjin, China | Esteio, Brazil
Please visit our website for a complete listing and to learn more about certified Horner Automation products.
This document is the property of Horner Automation Group, and is subject to change.
HE959CNX116
1 Universal Analog Input, 1 Analog Output
630mA @24VDC (<15W @ 24V)
24A @ 30 μS
10-30VDC
2
2
1
1
5-95% non-condensing
16-24 AWG / 0.2-1.4mm²
-40°C (-40°F) to 60°C (140°F)
-40°C (-40°F) to 85°C (185°F)
87g (3.05 oz)
76.5mm x 124.5mm x 19mm
3" x 4.9" x 0.75"
North America: https://hornerautomation.com/
certifications/
Europe: https://www.hornerautomation.eu/
support/certifications-2/
CsCAN - IN and OUT
1
0-10V / 0-20mA / 4-20mA / 0-60mV
16 Bit
0.20%
J / K / T / N / E / R / S / B
16-Bit ADC
PT100 / PT1000
.250mA
1.4 Digital Outputs
Inputs per Module
Commons per Module
Output Type
Absolute Max Voltage
Output Protection
Max Output per Point
Max. Total Out Current
Max. Output Supply Voltage
Min. Output Supply Voltage
Max Voltage Drop at rated Current
Min Load
OFF to ON Response
ON to OFF Response
I/O Indication
1.5 Analog Outputs
Number of Channels
Analog Outputs
Analog Output Data Ranges
Nominal Resolution
Minimum 10V Load
Maximum Current Load
Analog Output Halt State
1.6 Flexible Inputs - Digital / Analog
Number of Channels
Configured as Analog I/O
Analog Input Ranges
Analog Input Data Ranges
Alarm
Configured to Digital Inputs
Digital Input Ranges
Input Voltage Range
Absolute Max Voltage
Input Impedance
Custom Digital Input Ranges
OFF to ON Response
ON to OFF Response
Digital Input Active Mode
Connector Type
page 1 of 2
2
1
Sourcing with 10kΩ pull down
28VDC
Short Circuit
2A
4A
30VDC
10VDC
550mV
1mA
1ms
1ms
Status LED per Output
2 Analog
0-20mA / 4-20mA / 0-10V
0~4000 / -2000~2000 /
0~1000 / 0~2000/ 0~32000
12 Bit
500Ω
500Ω
Current / Minimum /
Maximum / Median
2 (Digital or Analog)
4-20mA / 0-10V
0~4000 / -2000~2000 /
0~1000 / 0~32000
Value / Register
24V / 12V / 5V / Custom
0 - 24VDC
+/- 30VDC
10kΩ
Threshold ON
Threshold OFF
1ms
1ms
Positive / Negative Logic
Phoenix Contact 2202234
MAN1175-01-EN
