Audiodesign PRO M2.12W/L Owner's Manual

Detailed instructions
The speaker has 3 groups of inputs, with separate volume control.
1) Wired and wireless microphones (with tone control and echo / repeat function) (Jack 6.3 Mono)
2) AUX input, to connect an instrument or a base (6.3 mono jack).
3) multimedia area, that is: USB / SD / MMC or micro SD reader, Bluetooth connection, Line input (RCA stereo
L + R), FM tuner with tone control
(*) Battery management:
Before and after each use, charge the battery, preferably for at least 12 hours.
The battery should normally be charged with the speaker off.
In case of prolonged non-use, charge the battery every 3 months.
When the battery, during use, reaches too low a voltage, the speaker goes into protection and the LOW
LED lights up
(*) Multimedia area functions:
Premises: wait for the required functions to be performed before pressing other keys !!!!
The Instructions for USB are the same for SD / MMC / Micro SD
Pressed in sequence selects USB / Line / BT or FM Radio. If pressed for a long time, it inserts or
removes the voice instructions function.
In USB mode, it activates the single repeat or full repeat of all tracks.
Press to activate the REC function (which affects only the Mic and AUX inputs) or to play back recordings
In USB / BT mode, short press skips to the previous track. In USB mode fully pressed back fast.
Short Press: Pause. Long press: selects the language (Chinese or English)
In USB / BT mode, short press: skips to the next track. In USB mode Long pres: fast forward
To listen a recorded file, open the REC folder by pressing
up to reading F01 on the display. Then press the button
Accessories
For this enclosure, on request are available:
- 2 Body packs that operate in the same frequencies of the hand held
microphones included in the package. Of course for each frequency only
one transmitter can be used to avoid interferences.
Cod. M2 HS1 677 Mhz
Cod. M2 HS2 660 Mhz
- 2 hand held TOP QUALITY microphones, that operate in the same
frequency of the 2 hand held microphone included.
Of course for each frequency only one transmitter can be used to avoid interferences.
Cod. M2 Top Mic1 677 Mhz
Cod. M2 Top Mic2 660 Mhz
PROFESSIONAL SPEAKERS, AMPLIFIERS AND ACCESSORIES
Audiodesign Srl
Via dell'industria, 28 - 42025 CAVRIAGO (RE)
+39 0522 941444
www.audiodesign-pro.com
info@audiodesign.it
High Power Battery active enclosures, serie M1 - M2
up to read USB and the the button
to listen the recorded file in loop mode.
Battery Active enclosure Mod M2.12W/L
Owner Manual
