Neutra-Safe
Vertical/Horizontal Condensate Neutralizer
®
CN2-220V
Installation, Operation and Maintenance Manual
/
"
1
2
1
/
"
Inlet
3
8
WARNING
• Neutra-Safe condensate neutralizers should only be installed by a qualified professional.
• Read all instructions before installing. Perform steps in the order given. Failure to comply could result in substantial property
damage, severe personal injury, or death.
• Do not allow flue gases to vent through condensate neutralizer. All condensate drain lines must have a gas trap before
entering the neutralization unit. Failure to comply could result in substantial property damage, severe personal injury
or death.
• Neutra-Safe neutralizers should only be connected to a condensate outlet that is installed per the appliance manufacturer's
instructions. Failure to comply could result in substantial property damage, severe personal injury or death.
IMPORTANT
• All piping should be in accordance with relevant building and mechanical codes, as well as any local, state or federal
regulations.
• Do not connect more than one appliance to each neutralizer.
• Neutralizer should be installed below all traps and condensate outlets.
• Do not use pipe dope on threaded fittings—use only Teflon tape. Neutra-Safe Model CN2-220V may be installed in the
vertical or horizontal position. Refer to page 2 for installation diagrams.
• It is recommended that the neutralizer be installed before the condensate pump.
• All condensate traps should be primed before commencing operation of the appliance.
• Neutra-Safe condensate neutralizer media should be replaced at least annually or when pH falls below local regulations.
MOUNTING OPTIONS
• It is recommended that Neutra-Safe condensate neutralizers be installed as close as possible to the outlet of the gas trap.
Refer to page 2 for installation diagrams.
• Use brackets provided for mounting neutralizer.
LIMITED WARRANTY
All Neutra-Safe products are warranted against defects in materials and workmanship for ONE YEAR.
The warranty does NOT cover issues that result from misuse, improper installation, and/or failure to replace the media.
CN2-220V
2
/
"
3
8
14
/
"
3
4
All dimensions ±
220,000 Btu/h
2
/
3
/
"
1
8
Neutrasafe, LLC
neutrasafe.com
421 Page Street, Suite 1
Stoughton, MA 02072
/
"
1
2
"
4
Outlet
1
/
"
3
8
Advertisement
Table of Contents
Summary of Contents for Neutrasafe CN2-220V
- Page 1 • Neutra-Safe neutralizers should only be connected to a condensate outlet that is installed per the appliance manufacturer’s instructions. Failure to comply could result in substantial property damage, severe personal injury or death. IMPORTANT • All piping should be in accordance with relevant building and mechanical codes, as well as any local, state or federal regulations. • Do not connect more than one appliance to each neutralizer. • Neutralizer should be installed below all traps and condensate outlets. • Do not use pipe dope on threaded fittings—use only Teflon tape. Neutra-Safe Model CN2-220V may be installed in the vertical or horizontal position. Refer to page 2 for installation diagrams. • It is recommended that the neutralizer be installed before the condensate pump. • All condensate traps should be primed before commencing operation of the appliance. • Neutra-Safe condensate neutralizer media should be replaced at least annually or when pH falls below local regulations. MOUNTING OPTIONS • It is recommended that Neutra-Safe condensate neutralizers be installed as close as possible to the outlet of the gas trap. Refer to page 2 for installation diagrams. • Use brackets provided for mounting neutralizer.
- Page 2 Note: If using flexible tubing, be sure to use hose clamps at barb fittings. Note: It is recommended that PVC pipe be used wherever possible as this will reduce any risk of tube kinking. CN2-220V includes: (2) - ½" MPT x FPT 90’s (2) - ½” MPT x Slip Adaptors (2) - ½”...
