Section
1
Disassembly Procedures Outline
Fixture for disassembly
Disassembly components
2
Disassembly battery
Disassembly RAM
Disassembly HDD
Disassembly keyboard
Disassembly ODD
Disassembly K/B cover
Disassembly LCD ASSY
Disassembly Bottom
Disassembly Thermal VGA
Disassembly ASSY Thermal CPU
Disassembly CPU
Disassembly W-LAN moudle
Disassembly Motherboard
Disassembly PWBA touchpad
VGN-FExx series Disassemble Instruction
Table of contents
Title
1
Page
2
4
4
5
6
6
6
7
10
10
11
11
12
12
12
Advertisement
Related Manuals for Sony VGN-FE Series
Summary of Contents for Sony VGN-FE Series
- Page 1 VGN-FExx series Disassemble Instruction Table of contents Section Title Page Disassembly Procedures Outline Fixture for disassembly Disassembly components Disassembly battery Disassembly RAM Disassembly HDD Disassembly keyboard Disassembly ODD Disassembly K/B cover Disassembly LCD ASSY Disassembly Bottom Disassembly Thermal VGA Disassembly ASSY Thermal CPU Disassembly CPU Disassembly W-LAN moudle Disassembly Motherboard...
- Page 2 VGN-FExx series Disassemble Instruction Fixture needed for Disassembly SIZE POSITION KB COVER M2*L1.8 M2xL2 M2xL2 M2*L3 LCD bracket M2*L3 LCD ANTENNA M2*L3 CAMERA BOARD PWBA TOUCHPAD M2xL3 REINFORCEMENT L M2xL3 Speaker M2xL3 M2xL3 KEYBOARD M2xL3 BLUETOOTH CABEL EXPRESS CARD M2xL3 PCMCIA SOCKET M2xL3 MODEM CARD...
- Page 3 VGN-FExx series Disassemble Instruction Fixture needed for Disassembly SIZE POSITION PCcard slot (inside) M2xL5 M2xL5 LCD HOUSING THERMAL SINK VGA/NB M2xL7 M2xL7 ASSY CABINET BOTTOM M2xL7 M2xL7 BOTTOM PCMCIA SOCKET M2*L7 RAM DOOR M2*L10 HDD BRACKET M2*L10 M3xL3 HDD BRACKET ASSY LCD M3xL6 BOTTOM...
- Page 4 VGN-FExx series Disassemble instructions 1. Remove the battery 2. Disassemble the RAM door and RAM Step 1.To prevent any kind of cosmetic damages and scratches; place your PC upside on top of a soft surface. Remove the battery in the direction of the arrow and set aside. Step 2.
- Page 5 VGN-FExx series Disassemble instructions Disassemble the HDD door and HDD Step 5. Using a screwdriver, remove the Step 6. Remove hard drive access door and set aside. screw . Step 7. Using a screwdriver remove the Step 8. Gently pull out HDD in the direction of the arrow and set aside. marked screw.
- Page 6 VGN-FExx series Disassemble instructions 1. Disassemble ODD 2. Disassemble the K/B cover and keyboard Step 9. Using a screwdriver, remove the Step 10. Remove the ODD in the direction of arrow and set aside. marked screw. Step 11. Using a screwdriver, remove the Step 12.
- Page 7 VGN-FExx series Disassemble instructions Disassemble the LCD ASSY Step 15.Gently pull out the marked cable. Step 16. Using a screwdriver, remove the marked screw...
- Page 8 VGN-FExx series Disassemble instructions Disassemble the LCD ASSY Step 17. Gently remove the LCD in the direction of arrow and set aside. Step 18.Gently remove the LCD rubber round and use a screwdriver to remove the marked screw. Step 19. Gently scratch the LCD bezel.
- Page 9 VGN-FExx series Disassemble instructions Disassemble the LCD ASSY Step 21.Using a screwdriver, remove the screw. Step 20.Gently pull out the connecter of the inverter as shown. Step 22. Gently remove the Hinge and LCD panel. Step 23. Gently pull out the cable. Step 24.Using a screwdriver, remove the marked screw.
- Page 10 VGN-FExx series Disassemble instructions 1. Disassemble the BOTTOM 2. Disassemble the ASSY Thermal VGA Step 25. Remove the cover thermal outlet in the direction of arrow and set aside. Step 26. Using a screwdriver remove the Step 27. Gently remove the bottom and set aside. screw.
- Page 11 VGN-FExx series Disassemble instructions Disassemble the ASSY Thermal CPU and Step 30. Gently remove the ASSY Step 31. Using a screwdriver, remove the Step 32. Gently remove the ASSY Thermal CPU cable. marked screw. Thermal CPU and set aside. Step 33. Unlock the CPU socket in the direction of arrow then remove the CPU. Step 34.
- Page 12 VGN-FExx series Disassemble instructions 1. Disassemble the W-LAN module 2. Disassemble the Motherboard 3. Disassemble the PWBA touchpad Step 37. Remove the WLAN card and set Step 36. Turn around the WHU and unlock aside. the socket as shown. PICT4957 Step 38.
