User Manual
ADAM-3600-C2G
iRTU User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADAM-3600-C2G and is the answer not in the manual?

Questions and answers

Summary of Contents for Adam ADAM-3600-C2G

  • Page 1 User Manual ADAM-3600-C2G iRTU User’s Manual...
  • Page 2 Acknowledgements ADAM is a trademark of Advantech Co., Ltd. IBM and PC are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners.
  • Page 3 Declaration of Conformity The ADAM-4000 series developed by Advantech Co., Ltd. has passed the CE test for environmental specifications when operated within an industrial enclosure (ADAM- 4950-ENC). Therefore, in order to protect the ADAM modules from being damaged by ESD (Electric Static Discharge), we strongly recommend that the use of CE-com- pliant industrial enclosure products when using any ADAM module.
  • Page 4 ADAM-3600 Series User Manual...

  • Page 5: Table Of Contents

    Figure 1.1 iRTU Application Architecture........2 Chapter Specifications ........3 Product Key Features ................4 ADAM-3600-C2G Specification..............5 2.2.1 ADAM-3600-C2G Specification of Main Unit ........ 5 2.2.2 Expansion Module Specifications ..........7 LED Indicators................... 8 Figure 2.1 LED Indicator.............. 8 2.3.1 System LED .................. 9 2.3.2...
  • Page 6 Figure 4.35Project Download ............. 43 4.3.3 Password Settings ..............44 Figure 4.36Password Information..........44 Figure 4.37Password Settings............ 44 Appendix A ADAM-3600 Naming Rules ....45 ADAM-3600 Naming Rules..............46 Figure A.1 ADAM-3600 Naming Rules ........46 ADAM-3600 Series User Manual...
  • Page 7 Appendix B Interface Definition ......47 Interface Definitions ................48 B.1.1 Communication Ports..............48 B.1.2 I/O Interface Definition ..............50 ADAM-3600 Series User Manual...
  • Page 8 ADAM-3600 Series User Manual viii...

  • Page 9: Chapter 1 Introduction

    Chapter Introduction...

  • Page 10: Product Concept &Target Market

    Product Concept &Target Market The ADAM-3600-C2G is an Intelligent Remote Terminal Unit / iRTU, mainly for the oil & gas and water industries. Intelligent network nodes in loT can control the down- stream field devices to complete delivery tasks, transfer data to upstream devices wired or wirelessly.

  • Page 11: Chapter 2 Specifications

    Chapter Specifications...

  • Page 12: Product Key Features

    High performance low-power CPU/RAM The ADAM-3600-C2G comes with a 32-bit Cortex A8 600MHz CPU and DDR3 mem- ory chips, which greatly improves the processing speed and efficiency. Based on these advantages and its unique low-power design, customers could take their time to tackle complex logic programs.

  • Page 13: Adam-3600-C2G Specification

    NodeID as identification facilitate remote batch configuration ADAM-3600 has a six bit DIP-switch on board which can be identification for 64 devices on the field. Through an ordinary cable, it could download configuration doc- uments into RTU devices (with a maximum of 64), and customers could find out the sources of faults through ID codes when variations encountered in the performance of RTU.
  • Page 14 Rated Current 200mA(max.load) Over Voltage Protection +40V Pulse Output Frequency 1KHz Isolation Voltage 2000V 2.2.1.3 Environmental Specifications  Operating Temperature: -40~70°C  Storage Temperature: -40~85°C  Operating Humidity: 20~95% (non-condensing)  Storage Humidity: 0 ~ 95% (non-condensing) ADAM-3600 Series User Manual...

  • Page 15: Expansion Module Specifications

    2.2.2 Expansion Module Specifications ADAM-3600-C2G support four slots expansion can support different type I/O mod- ules in one integrated unit. 2.2.2.1 ADAM-3617 (4-ch AI) Channel 4, differential Input Type Voltage, Current Voltage/Current Range ±10V, ±2.5V, 0~20mA, 4~20 mA Resolution 16-bit...

  • Page 16: Led Indicators

    2.2.2.4 ADAM-3651 (8-ch DI/ PI ) Channel Input Type Sink (Wet Contact)/ Counter Wet Contact Input Logic0: 0 ~ 5 V Logic 1: 11~30V Rated Voltage 12/24 V Rated Input Current >5mA@12V >10mA@24V Input Filter Programmable, Default: 3ms Pulse Input Frequency...

  • Page 17: System Led

    Link1 Orange Light on, LAN1 is connected with Ethernet Act1 Green Blinking, LAN1 is sending data to Ethernet Link2 Orange Light on, LAN2 is connected with Ethernet Act2 Green Blinking, LAN2 is sending data to Ethernet ADAM-3600 Series User Manual...

  • Page 18: Irtu Dimensions

    Dimensions Figure 2.2 ADAM-3600 Dimensions ADAM-3600 Series User Manual...

  • Page 19: Chapter 3 Wiring And Installation

    Chapter Wiring and Installation...

  • Page 20: Wiring

    C power supply. Figure 3.1 Power Supply Wiring 3.1.2 3-1-2Input / Output Wiring 3.1.2.1 Analog Input Wiring ADAM-3600-C2G equips with 8 channels AI with differential wiring type, wire as shown below: Figure 3.2 Analog Input Wiring ADAM-3600 Series User Manual...

  • Page 21: Serial Port Wiring

    3.1.2.2 Digital Input Wiring The ADAM-3600-C2G is equipped with 8 channels DI, follow the below diagram for wiring. The pin “COM” is for positive voltage wiring and provides a pull high voltage to the unwired pins. Normally user can leave it empty, and consider wiring while the field interference is significant.

  • Page 22: Installation

    Installation 3.2.1 Wall-mounted and DIN-Rail Installation The ADAM-3600-C2G supports two types of installation: Wall-mounted and DIN-Rail Installation. For wall-mounted installation, users can fix the device on the wall with 4 screws as shown below. Figure 3.6 Wall-mounted Installation For DIN-Rail installation, follow the below diagram to put the device on the DIN-Rail, and lock the 3 lock to fix the device on the DIN-Rail Figure 3.7 DIN-Rail Installation...

  • Page 23: Wireless Module Installation

    Figure 3.8 Wireless Module Installation 3.2.3 Expansion Input/Output Module Installation The ADAM-3600-C2G has four expansion slots named A, B, C and D with a black cover. The following is the installation methods when customers need to plug expan- sion modules.

  • Page 24: Writeable Label

    3.2.5 SD Card Installation The ADAM-3600-C2G supports two types of SD cards used as storage. One is Micro-SD, which carries the OS. The other is a Standard SD for storing data. It is available for users to choose and configure. The installation location of Standard SD...

  • Page 25: Sim Card Installation

    SIM Card Installation When customers install a 3G/GPRS module, they need to insert a SIM card, follow below diagram to install the SIM card. The SIM card is micro-SIM (3FF) type. Figure 3.13 SIM Card Installation ADAM-3600 Series User Manual...

  • Page 26: Jumper/Switch Settings

    Jumper/Switch Settings 3.3.1 DIP Switch Settings ADAM-3600-C2G IO has two DIP switches as follows: Figure 3.14 DIP Switch Setting Name Meaning Description Node ID 6-bit: supports 0~63 devices ON-1/ OFF-0 1 is for high bit, 6 is for last bit, ex:...

  • Page 27: Jumper Settings

    3.3.2 Jumper Settings The ADAM-3600 CPU has two Jumpers as follows: Figure 3.15 Jumper Settings Name Meaning Descriptions CN14 COM1 DB9 Port select RS-232 or RS-485 RS-485 RS-232 CN15 Watchdog Enable Jumper ON- Enable OFF- Disable ADAM-3600 Series User Manual...
  • Page 28 ADAM-3600 Series User Manual...
  • Page 29 Chapter Advantech iRTU Studio...
  • Page 30  With regard to network communications, user can complete the settings for Ethernet, Wi-Fi, 3G and GPRS via iRTU Studio. ADAM-3600 provides Modbus/RTU, Modbus/TCP and DNP3.0 servers, and  customers can flexibly choose protocol services according to their own needs.
  • Page 31 4.2.1.3 Copying Devices To reduce the complexity of configure a lot of ADAM-3600 on the field, iRTU Studio supports the ability to copy device information within a project. Users can right-click on the device name and choose “copy”. The copied device will have the same configuration as the original device, but user still need to be modify the name, NodeID or IP as well as the description according to the project planning.
  • Page 32 After adding a device, there will be an item "Data Center" under the added device. It is a place for user to manage data acquisition, which is an important functionality for a RTU. Through this interface, user can manage all the ADAM-3600 resources which are able to fetch data from the field site.
  • Page 33 4.2.2.1 OnBoard I/O Configuration The ADAM-3600-C2G is equipped with 8-ch AI, 8-ch DI, and 4-ch DO ports which users can map the real input signals to the IO tag. The configuration method of analog and discrete input is different and the specific configuration method is as follows: ...
  • Page 34 The PWM period is the sum of duration of high level and low level, namely PWM_HI+ PWM_LO. The PWM frequency is 1/ (PWM_HI+ PWM_LO). The PWM duty cycle is the ratio of duration time of high level and PWM period, namely PWM_HI/ (PWM_HI+ PWM_LO). ADAM-3600 Series User Manual...
  • Page 35 4.2.2.2 Serial I/O Device Configuration The ADAM-3600 has three serial ports including 1x RS232/RS485, 2 x RS485. iRTU Studio can edit, delete and add device on these three ports. Right click the “Data Center” on the left-side tree view, and select “Add Port”...
  • Page 36 4.2.2.3 Ethernet I/O Device Configuration ADAM-3600 is equipped two Ethernet ports; user can edit, delete and add devices through iRTU Studio. Double click or right click the “TCP” item under the “Data Center” in the left side tree view and choose “edit” as shown in the following figure to edit the port.
  • Page 37 In the “Type” field of "New Port" page, select “TCPIP”, and input the related parameters for the serial port. Then click button “Apply”, a new TCP port will be created. Figure 4.13 Adding and Editing TCP Ports ADAM-3600 Series User Manual...
  • Page 38 4.2.2.4 Zigbee Wireless I/O Device Configuration A Zigbee wireless communication module can be added to the ADAM-3600 from COM port or USB port on PCIe-mini card socket. To get data from the Zigbee Wireless Meter, use the fol- lowing steps: Right click the “Data Center”...
  • Page 39 Double click the “I/O Tag” item to edit the tag to map with the data from Zigbee wireless meter. Figure 4.16 ZigBee Meter I/O Configuration To delete a Zigbee port or a meter, right click to the select the target item and select “Delete”. ADAM-3600 Series User Manual...
  • Page 40 Firstly select the acquisition tag, represented by A, B, C, D…, respectively. Figure 4.17 Adding the acquisition tag Determine the expression according to the requirements. Then select the “Appli- cation” button to add the computing tag. Figure 4.18 Adding the computation tag ADAM-3600 Series User Manual...
  • Page 41 In a word, all of these user tags will fulfill user's demands for data. iRTU Studio supports user tag configuration. Users can configure step by step into RTU as shown in the following: Figure 4.19 User Tag Configuration ADAM-3600 Series User Manual...
  • Page 42 USB backup function. In this way, users can directly insert the USB into the ADAM-3600-C2G to copy the historical data in SD card. PROM indicator will always be blinking until finishing the process of copying. The historical data is stored in the form of SQLite.
  • Page 43 To connect with WebAccess, users should click WebAccess WhereIAm. Make sure that the physical IP address with WebAccess is right. The parameter definition as below: IP Address: physical IP address with WebAccess; Port: default TCP port for WebAccess; Period (s): for connecting with WebAccess Center; ADAM-3600 Series User Manual...
  • Page 44 4.2.5 Connectivity Configuration The ADAM-3600-C2G is an Intelligent Remote Terminal Unit and acts as an intelligent net- work node in IoT. It can control the downstream field devices to complete delivery tasks and transfer data to upstream devices wired or wirelessly. As a key device, the connecting func- tion of ADAM-3600-C2G is very important.
  • Page 45 Escape rules of the sender: fe => fd ee fd => fd ed Escape rules of the receiver fd ee => fe ADAM-3600 Series User Manual...
  • Page 46 4.2.6.1 I/0 Settings The ADAM-3600-C2G is equipped with 8 AI channels, 8 DI channels, and 4 DO channels. Besides, there are four I/O expansion slots which can integrate various I/O modules into the main unit. In the Studio, for both on-board I/O and expansion I/O, user can set mode, I/O range, integration time as well as calibration.
  • Page 47 Please follow the instruction to finish the calibration. Note! The analogue I/O is default well calibrated and we do not recommend user do the calibration by one-self. Once the calibration is needed, we suggest sending back to RMA for calibration service. ADAM-3600 Series User Manual...
  • Page 48 User has to configure the network environment in this section. Cable Network Settings The ADAM-3600-C2G has two Ethernet ports and users can configure them respectively. Under the concomitances that Ethernet ports supports IPv4 and IPv6, users can set RTU as DHCP or fixed IP.If users select RTU as DHCP mode, RTU will provide a default IP address...
  • Page 49 Figure 4.32 GPRS Script Setting 4.2.6.3 LED Configuration The ADAM-3600-C2G has many system status indicators. Users can configure LED indica- tors through iRTU Studio to make it blink according to users’ definition. Figure 4.33 LED configuration ADAM-3600 Series User Manual...
  • Page 50  RUN Indicators Configuration ADAM-3600-C2G has two functions: data acquisition and control. When users only need data acquisition, just select “Data Collection” button. RUN indicator will blink if data acquisition function is normal. When users need data acquisition and control function, select “Data Col- lection + Softlogic”.
  • Page 51 “Project Download”, user can download the whole project to all the devices on line by one click. If users only click and activate one target device on the tree view, the “Project Download” will only download the project to the selected device. Figure 4.35 Project Download ADAM-3600 Series User Manual...
  • Page 52 4.3.3 Password Settings For security, the ADAM-3600-C2G has a default password "00000000", and iRTU Studio also sets it as the default password for RTU devices. Figure 4.36 Password Information To change the password, follow the steps below: iRTU Studio connects with the RTU device, and it has been identified.
  • Page 53 Appendix ADAM-3600 Naming Rules...
  • Page 54 ADAM-3600 Naming Rules The ADAM-3600 includes two types of products that are ADAM-3600-A1F and ADAM-3600-C2G, which shows a difference as far as their design and features. In this Manual, we focus on the introductions of ADAM-3600-C2G. Figure A.1 ADAM-3600 Naming Rules Examples: ADAM-3600-C2GL1AE: Cortex A8 iRTU for Oil &...

  • Page 55: Appendix B Interface Definition

    Appendix Interface Definition...

  • Page 56: Interface Definitions

    RS-232 Signal RS-485 Signal DATA- DATA+ B.1.1.2 COM 2 & COM3: RS-485  Connection: Terminal Block Baud rate: 1200~921.6k bps  RS-485 signals: DATA+, DATA-   Communication Isolation: 2000V RS-485 Signal DATA2+ DATA2- DATA3+ DATA3- ADAM-3600 Series User Manual...
  • Page 57 USB signals: Vcc, Data-, Data+, GND USB Signal Data- Data+ B.1.1.4 LAN1 and LAN2: Ethernet Port  Connection: RJ-45 Base-T 1800 connect  Transfer rate: 10/100Mbps  LAN signals: TD+, TD-, RD+, RD- Signal TD‐ RD‐ ADAM-3600 Series User Manual...

  • Page 58: I/O Interface Definition

    B.1.2 I/O Interface Definition ADAM-3600 Series User Manual...
  • Page 59 ADAM-3600 Series User Manual...
  • Page 60 www.advantech.com Please verify specifications before quoting. This guide is intended for reference purposes only. All product specifications are subject to change without notice. No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher.
