Summary of Contents for Metacentre Y10META13.00
- Page 1 MANY1026A.EN – Kit, Enersoft PC Visualisation, Technical Manual Kit, Enersoft PC Visualsation...
- Page 2 Airmaster, the Airmaster logo, Metacentre, the damages arising here from. The fact that an Metacentre logo, Airbus485 and the Airbus485 logo organisation or website is referred to in this work as are trademarks or registered trademarks of a citation and/or a potential source of further Compressor &...
- Page 3 Technical Manual 1. Safety Precautions The product must only be operated at the supply voltage and frequency for which it is designed. ALWAYS EMPLOY SAFE WORKING When mains power is switched on, lethal voltages PRACTISE AND PROCEDURES are present in the electrical circuits and extreme caution must be exercised whenever it is necessary to carry out any work on the unit.
- Page 4 Kit, Enersoft PC Visualisation 2.2 RS 485 2. Installation To maintain the Type 2 rating, RS485 wiring 2.1 Location has to be routed through the cable glands. Type 12, 12 K or 13 cable glands, conduit or The Kit, Enersoft PC Visualisation enclosure is other cable entry fittings, must be used.
- Page 5 Technical Manual 2.3 RS485 Connection 2.5 Airbus485™ System Connection Remote RS485 Device (e.g. host PC) Airbus485™ field bus network Airbus 485™ RS485 RS485 Wire polarity is important Wire polarity is important Use 2-wire, 0.3-0.5mm , twisted pair, earth Use 2-wire, 0.3-0.5mm , twisted pair, earth shielded, and data cable with a total system shielded, and data cable with a total system...
- Page 6 Kit, Enersoft PC Visualisation 4. Operational Indications Airbus485™ Communications No valid communications with the Airbus485™ field bus network Airbus485™ ON; communicating OFF; no function OFF; no function Communications No valid communications with remote device ON; communicating At power on initialisation, or when power has been removed, all operational indicators will fast flash for several seconds.
- Page 7 Technical Manual RS485 data communications and other low voltage signals can be subject to electrical interference. This potential can result in intermittent malfunction or anomaly that is difficult to diagnose. To avoid this possibility always use earth shielded cables, securely bonded to a known good earth at one end.
- Page 8 Technical Manual 5. Parts List Kit, Enersoft PC Visualisation Item Part No. Description Y10META13.00 Kit, Enersoft PC RS485 Echo USB-Nano Visualisation Termi- nator Y01ENER03.00 CD, Enersoft Y10CM18.00 Gateway, DDE Y07CMB6.00 24VDC power supply Y07CM49.00 Gland, Set - Pg13.5 Y10CM20.00 Cable, interconnect,...
