Summary of Contents for Dodotronic Batango
- Page 1 Keyholder frequency division bat detector Batango Dodotronic Castel Gandolfo RM Italy VAT IT07343571001 www.dodotronic.com info@dodotronic.com...
- Page 2 SIDE VIEW FRONT VIEW The Batango is a frequency division (FD) bat detector. This device captures ultrasounds and divides the incoming frequency, to allow it to be audible to human ears. This is done by detecting the zero crossing signal and synthesizing a digital wave, with the same amplitude but a lower frequency.
- Page 3 QUICK GUIDE: FUNCTION ACTION TURNING ON SINGLE SHORT CLICK TURNS ON TURNING OFF SINGLE LONG CLICK TURNS OFF VOLUME SINGLE SHORT CLICK SHORT CHANGE WHEN POWER IS ON BLINKS DIVISION LONG DOUBLE CLICK FACTOR BLINKS POWER The device is turned on, with a single short click.
- Page 4 This is a low power device, that uses less 3.5 mA, utilizing a single coin cell battery. when in action. If no ultrasound is captured, then the Batango enters a Sleep mode, reducing current consumption. When unused for 30 minutes, it enters into a deep sleep mode, and power consumption is further reduced to only 10 µA.
- Page 5 HEADPHONES Every headphones with a standard 3.5mm jack connector can be used with Batango. There’s no internal loudspeacker. CONSIDERATIONS Heterodyne detectors and frequency division bat Detectors, are not recommended for sound recordings; because the original ultrasound has been modified and what we are...
- Page 6 Technical specifications Frequency division bat detector. Frequency range from 10KHz to 150 Khz. MEMS high sensitivity Surface Mount Wide-band Ultrasonic Acoustic Sensor High quality, and low noise analog amplification. 8 bit 32 MHz integrated microcontroller. Dimensions: 45 mm long x 35.5 mm. Weight 14.5 g.
- Page 7 Conformity declaration Serial number: year of manufacture: 2012 model: Batango Fiorentino A.M. declare under our responsibility that the Batango is in conformity with the protection and compliance requirements of the following EC Directives: – 2004/108/CE – 2006/95/CE Roma Fiorentino A.M. S.r.l.
