MP enclosure that have the middle eight truss head screws. Figure 1 shows the optional router front cover (MP-RFC). Figure 2 shows a router mounted on the front of an MP enclosure using the optional router front cover.
Page 2
2. Remove the four truss head screws (Step B below) that secure the top cover to the front cover. 3. Replace the top cover with the MP-RFC (Step C below), and re-attach to the front cover with the four truss head screws removed in Step 2.
