PHOENIX 300 Operation & Service Instructions

1. Specifications................................................... 1

2. Operation .......................................................... 1

2.1 Transporting the Phoenix 300 ...................... 1

2.2 Location ........................................................ 1

2.3 Electrical Requirements ............................... 2

2.4 Condensate Removal ................................... 2

2.5 Ducting ......................................................... 2

2.6 Power Switch................................................ 2

2.7 Pump Purge Switch ...................................... 2

2.8 Pump Fail Light............................................. 2

2.9 Hour Meter.................................................... 2

2.10 Defrost Control Adjustment ......................... 2

2.11 Low Pressure Control .................................. 3

3. Maintenance ..................................................... 3

3.1 Air Filter ........................................................ 3

3.2 Blower Oiling ................................................ 3

3.3 Storage ......................................................... 3

4. Service .............................................................. 4

4.1 Warranty....................................................... 4

4.2 Technical description.................................... 4

4.3 Troubleshooting............................................ 4

4.4 Refrigerant Charging .................................... 5

4.5 Blower Replacement .................................... 5

4.6 Compressor/Capacitor Replacement ........... 5

4.6A Checking Compressor Motor Circuits ..... 5

4.6B Replacing a Burned Out Compressor ..... 6

4.6C Replacing a Compressor- Non-Burn Out ... 7

4.7 Defrost Thermostat & Timer......................... 7

4.8 Condensate Pump........................................ 7

4.9 Relay............................................................. 7

4.10 Time Delay .................................................. 7

5. Wiring Diagram................................................. 8

6. Service Parts List ............................................. 9

Serial No. ________________________________

Purchase Date ____________________________

Dealer's Name ____________________________

Therma-Stor Products

A Division of DEC International

Box 8050 Madison, WI 53708

Toll Free 1-800-533-7533

Local 1-608-222-5301

Read the operation and maintenance instructions

carefully before using this unit. Proper adherence to

these instructions is essential to obtain maximum

benefit from your Phoenix 300 dehumidifier.

1 Specifications

Model: PHOENIX 300 Dehumidifier

Electrical: 110-120 Vac, 12 Amps, grounded

Capacity: 176 pints per day @ 80°F, 60% RH

Operating Temp. Range: 33°F min., 105°F max.

Air Flow: 540 CFM without external ducting

Refrigerant Charge: 2 lbs., 5 oz. R-22

Optional Duct connection: 10" round outlet

Size: 45" high x 24" wide x 20" deep cabinet

46" high x 29" wide x 25" deep overall

Weight: 175 lbs.

2 Operation

2.1 Transporting the Phoenix

The Phoenix 300 must always be upright when

transported by vehicle. It may be tipped on to its handle

and back for loading and moving by hand.

2.2 Location

Note the following precautions when locating the

Phoenix 300:

• It is designed to be used INDOORS ONLY.

• If used in a wet area, plug it into a GROUND FAULT

INTERRUPTER.

• • • • DO NOT use the Phoenix 300 as a bench or table.

• It must always be used in the upright position.

• The air inlet on top & the side outlet must be at least

1 foot from walls and other obstructions to air flow.

• If the humid area is very large, dehumidification can

be improved by adding an outlet duct to circulate air

to stagnant areas (see Sec. 2.5).

Lit. No. TS-218B-0499

Table of Contents

Summary of Contents for DEC PHOENIX 300

Page 1: Table Of Contents
• If used in a wet area, plug it into a GROUND FAULT 4.10 Time Delay ..........7 INTERRUPTER. • • • • DO NOT use the Phoenix 300 as a bench or table. 5. Wiring Diagram..........8 • It must always be used in the upright position.
Page 2: Electrical Requirements
12 gauge conductors if 25 feet long or less 2.10 Defrost Control Adjustment and 10 gauge conductors if greater than 25 feet long. When the Phoenix 300 is used in a cool area, frost will 2.4 Condensate Removal form on the cooling coil as it dehumidifies. When...
Page 3: Low Pressure Control
center so that the pegs alternate with 2 toward the 2.10 Low Pressure Control center, then 2 out from the center, all the way around the dial except for the section now with 6 If the low side refrigerant pressure drops to 15 PSIG, pegs out in a row (see Fig.
Page 4: Maintenance
The Phoenix 300 is equipped with a 4” thick, 35% serious bodily injury, and/or property damage. Only efficient pleated fabric air filter that must be checked qualified service people should service this unit.
Page 5: Troubleshooting
Blower does not run. Compressor runs briefly but cycles on & off. 1. Loose connection in blower circuit (Fig. 3). 2. Obstruction prevents impeller rotation. 3. Defective blower (Sec. 4.5). Unit removes some water but not as much as expected. 1.
Page 6: Blower Replacement
4. Compressor terminals C and S: No continuity 4.5 Blower Replacement indicates an open start winding; the compressor must be replaced. The centrifugal blower has a PSC motor and internal thermal overload protection. If defective, the complete 5. Compressor terminals C and R: No continuity assembly must be replaced.
Page 7: C Replacing A Compressor- Non-Burn Out
could be toxic and highly acidic. If no acid odor is 4.6C Replacing a Compressor- Non-Burn present, skip down to the section on changing a non-burn out compressor. Remove the refrigerant from the system. Replace the 2. Remove and properly dispose of the system compressor and liquid line filter/drier.
Page 8: Relay
4.9 Relay 4.10 Time Delay (HP model only) The contacts of the single pole, single throw relay The HP model has a time delay relay in the complete the power circuit to the compressor. The compressor control circuit. This relay delays the contacts are closed when power is provided to the relay compressor start about 2 minutes after the power coil via the control circuit.
Page 9 Figure 3: Electrical Schematic of Phoenix 300...
Page 10: Wiring Diagram
SERVICE PARTS LIST: Phoenix 300 Dehumidifier ITEM PART NO. QTY. DESCRIPTION 4021818 Accumulator 4022636 Air Filter, Pleated, 2” x 20” x 20” (Grainger P/N 6B937) 4022614 Air Filter, Pleated, 4” x 20” x 20” (Grainger P/N 2W236) 4022624 Air Filter, Pleated, 4” x 20” x 20” (90-95% EFFICIENT)
