Summary of Contents for The Handy THDSH
- Page 1 OPERATOR’S MANUAL AND PARTS LIST Deluxe Saw Horse - THDSH Spares & Support: 01793 333212 www.thehandy.co.uk Before use please read & understand this manual, paying particular attention to the safety instructions. 09/08/2013...
- Page 2 Instructions Assemble the Saw Horse as shown in the parts list. Place the log onto the rear support stand. Ensure that the log is no longer than 4M and 250mm diameter. If the log is 4M long, then 1.5M of the log should be on the other side of the strap, so that it is balanced, as shown below.
- Page 3 Parts Diagram and List Part No. Description TH201-01 Main Support Frame TH201-02 Rear Support Stand TH201-03 Ratchet TH201-04 Belt TH201-05 Allen Key TH201-06 Butterfly Nut TH201-07 Hex Bolt (8x60mm) TH201-08 Bolt (8x70mm) TH201-09 Bolt (8x45mm) TH201-10 TH201-11 Washer TH201-12 Support Feet...
- Page 4 GUARANTEE This product is guaranteed against manufacturing defects for a period of 12 months. This does not cover the product where the fault is due to misuse, abuse, use in contravention of the instructions, or where the product has been the subject of unauthorised modifications or alterations.
